Trane INTELLIPAK Installation Operation & Maintenance page 42

Table 3-7 (Continued)
Electrical Service Sizing Data (20 through 130 Ton)
Unit 200/60/3, Nominal
Component(s) (180-220V Utiliz.)
Electric Heat FLA (3)
(SEHF Only):
30 Kw 83.3
50 Kw 138.8
70 Kw 194.3
90 Kw 249.8
110 Kw 305.3
130 Kw -n/a-
150 Kw -n/a-
170 Kw -n/a-
190 Kw -n/a-
Combustion FLA
Blower Motor
(SFHF Only):
235, 350, 500 MB 2.1
850 & 1,000 MBh 2.8
Unit Tonnage
20 Ton Std and Hi-Capacity
25 Ton Std and Hi-Capacity
30 Ton Std and Hi-Capacity
40 Ton Std and Hi-Capacity
50 Ton Std and Hi-Capacity
55 Ton Std and Hi-Capacity
60Ton Std and Hi-Capacity
70 / 75 Ton Std
75 Ton Hi-Capacity
90 Ton Std and Hi-Capacity
105 Ton Std and Hi-Capacity
115 Ton
130 Ton
230/60/3, Nominal
(207-253V Utiliz.)
FLA (3)
72.2
120.3
168.4
216.5
264.6
-n/a-
-n/a-
-n/a-
-n/a-
FLA
1.8
2.4
No. of Compressors Tonnage
Two 9 - Ton
One 14 - Ton
One 9 - Ton
Two 14 - Ton
Four 9 - Ton
Two 14 - Ton
Two 9 - Ton
Four 14 - Ton
Four 14 - Ton
Four 9 - Ton
Two 14 - Ton
Four 10 - Ton
Two 15- Ton
Two 10 - Ton
Four 15 - Ton
Six 15 - Ton
Four 15 - Ton
Four 10 - Ton
Eight 14 - Ton
460/60/3, Nominal 575/60/3, Nominal
(414-506V Utiliz.) (517-633V Utiliz.)
FLA (3)
36.1
60.1
84.2
108.3
132.3
156.4
180.4
204.5
228.5
FLA
0.9
1.2
Type Designation
Scrolls A & B
Scroll B
Scroll A
Scrolls A & B
Scrolls 1A, 1B, 2A, 2B
Scrolls 1B & 2B
Scrolls 1A & 2A
Scrolls 1A, 1B, 2A, 2B
Scrolls 1A, 1B, 2A, 2B
Scrolls 1A, 1B, 2A, 2B
Scrolls 1 C & 2C
Scrolls 1A & 2A, 1B & 2B
Scrolls 1C, 2C
Scrolls 1A & 2A
Scrolls 1 ,2B & 1,2C
Scrolls 1,2A, 1,2B, 1,2C
Scrolls 1,2A & 1,2B
Scrolls 1,2C & 1,2D
Scrolls 1,2A, 1,2B, 1,2C, 1,2D
42
FLA (3)
28.9
48.1
67.4
86.6
105.9
125.1
144.3
163.6
182.8
FLA
0.7
1
