Table 5-4
Filter Data
Panel-Type Filters
Unit Model (Note 1)
Qty Size of each
S_HF-C20 & 12 20 X 20 X 2
C25
S_HF-C30 16 20 X 20 X 2
S_HF-C40 16 20 X 25 X 2
S_HF-C50 & 20 20 X 25 X 2
C55
S_HF-C60, 35 16 X 20 X 2
C70 & C75
S_HG-C90 & 25 24 X 24 X 2
S_HG-D11
S_HG-D12 & 25 24 X 24 X 2
S_HG-D13
Notes:
1. Dimensions shown for "Panel-Type Filters"apply to "Throw away", "Cleanable Wire Mesh",
and "High Efficiency Throw away" Filters.
2. S_HF units ordered with "Bag-Type Filters" or "Cartridge Filters" (box-type) include a bank
of "Panel-Type Prefilters".
3. The same "Panel-Type Prefilters" are used with "Bag-Type" and "Cartridge (box-type)" filters.
Table 5-5
"Wet Heat" Coil Fin Data
Coil
Model Type
SLHF-C20, WC
C25 & C30 Prima Flo
(hot water)
SLHF-C40, WC
C50 & C55 Prima Flo
(hot water)
SLHF-C60, WC
C70 & C75 Prima Flo
(hot water)
SLHG-C90, WC
D11, D12 Prima Flo
& D13 (hot water)
SSHF-C20, NS
C25 & C30 (steam)
SSHF-C40, NS
C50 & C55 (steam)
SSHF-C60, NS
C70 & C75 (steam)
SLHG-C90, NS
D11, D12 (steam)
& D13
Note: To determine unit heating capacity (i.e., "low heat" or "high heat"),
see Digit 9 of the model number stamped on the unit nameplate.
Bag-Type Filters
(Note 2)
Qty. Size of each
4 12 X 24 X 19
3 24 X 24 X 19
2 12 X 24 X 19
6 24 X 24 X 19
5 12 X 24 X 19
6 24 X 24 X 19
3 12 X 24 X 19
9 24 X 24 X 19
6 12 X 24 X 19
8 24 X 24 X 19
3 12 X 24 X 19
15 24 X 24 X 19
3 12 X 24 X 19
15 24 X 24 X 19
Total Coil
Coil Face Area
Rows (sq.ft.)
2 13.75
2 19.25
2 26.25
2 17.5 (2)
1 13.75
1 13.75 (1)
5.5 (1)
1 18.75 (1)
7.5 (1)
1 17.5 (2)
104
Service & Maintenance (Continued)
Cartridge Filters Panel-Type Prefilters
(box-type) (Note 2)
Qty. Size of each
4 12 X 24 X 12
3 24 X 24 X 12
2 12 X 24 X 12
6 24 X 24 X 12
5 12 X 24 X 12
6 24 X 24 X 12
3 12 X 24 X 12
9 24 X 24 X 12
6 12 X 24 X 12
8 24 X 24 X 12
3 12 X 24 X 12
15 24 X 24 X 12
3 12 X 24 X 12
15 24 X 24 X 12
Fins Fins
per per
Foot Foot
80 110
80 110
80 110
80 110
42 96
42 96
42 72
52 96
(Note 3)
Qty. Size of each
4 12 X 24 X 2
3 24 X 24 X 2
2 12 X 24 X 2
6 24 X 24 X 2
5 12 X 24 X 2
6 24 X 24 X 2
3 12 X 24 X 2
9 24 X 24 X 2
6 12 X 24 X 2
8 24 X 24 X 2
3 20 X 24 X 2
15 24 X 24 X 2
3 20 X 24 X 2
15 24 X 24 X 2
