Seagate Constellation ES.1 Serial ATA Product Manual page 5

Figure 1. Typical 2TB model 5V & 12V startup and operation current profile . . . . . . . . . . . . . . . . . . . . 12
Figure 2. Typical 1TB model 5V & 12V startup and operation current profiles . . . . . . . . . . . . . . . . . . . 13
Figure 3. Location of the HDA temperature check point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Figure 4. Attaching SATA cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Figure 5. Mounting dimensions-top, side and end view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 6. Example of FIPS tamper evidence labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Constellation ES.1 Serial ATA Product Manual, Rev. B
List of Figures
iii
