- Page 1 7E8 SATA Product Manual Standard 512N models ST6000NM0235 100804238, Rev. A October 2017...
- Page 2 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. PowerChoice and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 S.M.A.R.T. commands............. . 30 Seagate Exos 7E8 Serial ATA Product Manual, Rev. A...
-
Page 5: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate Exos 7E8 Serial ATA Product Manual, Rev. A... -
Page 6: Introduction
• Supports latching SATA cables and connectors. • Top Cover Attached motor for excellent vibration tolerance • Worldwide Name (WWN) capability uniquely identifies the drive. Seagate recommends validating the configuration with the selected HBA/ Note RAID controller manufacturer to ensure use of full capacity is supported. -
Page 7: Drive Specifications
(below mean sea level, max) (–1000 ft to 40,000+ ft) Operational Shock (max at 2 ms) Read 70 Gs / Write 40 Gs Non-Operational Shock (max at 2 ms) 250 Gs Seagate Exos 7E8 Serial ATA Product Manual, Rev. A... - Page 8 *One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. **During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Seagate Exos 7E8 Serial ATA Product Manual, Rev. A...
-
Page 9: Formatted Capacity
Maximum Sustained data transfer rate (MiB/s) I/O data-transfer rate (MB/s max) 600 (Ultra DMA mode 5) Start/stop times Power-on to Ready (sec) (typ/max) 23/30 Standby to Ready (sec) (typ/max) 23/30 Ready to spindle stop (sec) (max) Seagate Exos 7E8 Serial ATA Product Manual, Rev. A... -
Page 10: Power Specifications
0.46 0.63 Maximum DC (peak) 0.53 1.82 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels Seagate Exos 7E8 Serial ATA Product Manual, Rev. A... - Page 11 2.5.1.1 Typical current profiles Figure 1. 6TB Typical 5V startup and operation current profile Figure 2. Typical 12V startup and operation current profile Seagate Exos 7E8 Serial ATA Product Manual, Rev. A...
-
Page 12: Conducted Noise
• Reports the current power state of the drive Identify Device Command • EPC Feature set supported flag • EPC Feature enabled flag is set if at least one Idle power condition timer is enabled Seagate Exos 7E8 Serial ATA Product Manual, Rev. A... - Page 13 Disable EPC Feature Set PowerChoice Supported Extended Power Condition Identifiers Power Condition Identifiers Power Condition Name Standby_z 01 - 80 Reserved Idle_a Idle_b Idle_c 84 - FE Reserved All EPC Power Conditions Seagate Exos 7E8 Serial ATA Product Manual, Rev. A...
-
Page 14: Environmental Limits
Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. HDA Temp. -
Page 15: Shock
The maximum non-operating vibration levels that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation are specified below. 10–500 Hz 5.0 Grms ref Linear Random Seagate Exos 7E8 Serial ATA Product Manual, Rev. A... -
Page 16: Acoustics
Test for Prominent Discrete Tones (PDTs) Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 17: Reliability
Seagate drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with all relevant regulatory requirements and standards for the drives, Seagate cannot guarantee that all system-level products into which the drives are installed comply with all regulatory requirements and standards applicable to the system-level products. -
Page 18: Canada Ices-003
2.11.7 Morocco Commodity Mark To satisfy our OEM customers, Seagate has added the Moroccan Commodity Mark to the drives provided to the OEM for the sale of Customer Kits produced by our OEM customers that are intended to be incorporated into the OEM's finished system-level product by an end user. -
Page 19: Environmental Protection
2.12.1.1 Restriction of Hazardous Substances in Electrical and Electronic Equipment Seagate drives are designed to be compliant with the European Union RoHS "Recast" Directive 2011/65/EU (RoHS 2) as amended by Directive (EU) 2015/863. The RoHS2 restricts the use of certain hazardous substances such as Lead, Cadmium, Mercury, Hexavalent Chromium, Polybrominated Biphenyls (PBB) and Polybrominated Diphenyl Ether (PBDE), BisBis(2-Ethylhexyl) phthalate (DEHP), Benzyl butyl phthalate (BBP), Dibutyl phthalate (DBP), and Diisobutyl phthalate (DIBP) in electrical and electronic equipment (EEE). -
Page 20: Taiwan Requirements - Taiwan Rohs
The useful life of any electronic equipment may be extended by replacing materials near circuitry with sulfide-free alternatives. Seagate recommends that data centers be kept clean by monitoring and controlling the dust and gaseous contamination. Gaseous contamination should be within ANSI/ISA S71.04-2013 G2 classification levels (as measured on copper and silver coupons), and dust contamination to ISO 14644-1 Class 8 standards, and MTBF rated conditions as defined in the Annualized Failure Rate (AFR) and Mean Time Between Failure (MTBF) section. -
Page 21: Reference Documents
Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure. -
Page 22: Configuring And Mounting The Drive
• Do not overtighten the mounting screws (maximum torque: 6 in-lb). • Do not cover breather hole on top cover. Figure 5. Breather hole location - top cover Seagate Exos 7E8 Serial ATA Product Manual, Rev. A... -
Page 23: Mechanical Specifications
26.11 MM .142±.015 2 2.000 C L OF DRIVE Figure 6. Mounting configuration dimensions (6TB models) The image is for mechanical dimension reference only and may not represent the actual drive. Note Seagate Exos 7E8 Serial ATA Product Manual, Rev. A... -
Page 24: Serial Ata (Sata) Interface
There are three power pins for each voltage. One pin from each voltage is used for pre-charge when installed in a blind-mate backplane configuration. All used voltage pins (V ) must be terminated. Seagate Exos 7E8 Serial ATA Product Manual, Rev. A... -
Page 25: Supported Ata Commands
Sanitize Device - Overwrite Ext / 0014 Sanitize Device - Freeze Lock Ext / 0020 Sanitize Device - Status Ext / 0000 Security Disable Password Security Erase Prepare Security Erase Unit Seagate Exos 7E8 Serial ATA Product Manual, Rev. A... - Page 26 Write DMA FUA Extended Write FPDMA Queued Write Log DMA Ext Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Uncorrectable Seagate Exos 7E8 Serial ATA Product Manual, Rev. A...
-
Page 27: Identify Device Command
137GB). Drives with capacities over 137GB will have 0FFFFFFFh in this field and the actual number of user-addressable LBAs specified in words 100-103. This is required for drives that support the 48-bit addressing feature. Obsolete 0000 Seagate Exos 7E8 Serial ATA Product Manual, Rev. A... - Page 28 84, bit 8 is set to 1 indicating 64-bit WWN support. a unique value. 112–118 ATA-reserved 0000 Commands and feature sets supported 41DE Commands and feature sets supported or enabled 409C 121-127 ATA-reserved 0000 Seagate Exos 7E8 Serial ATA Product Manual, Rev. A...
- Page 29 Ultra DMA mode 0 is supported. Ultra DMA mode 1 is supported. Ultra DMA mode 2 is supported. Ultra DMA mode 3 is supported. Ultra DMA mode 4 is supported. Ultra DMA mode 5 is supported. Seagate Exos 7E8 Serial ATA Product Manual, Rev. A...
-
Page 30: Set Features Command
Enable read look-ahead (read cache) feature (default). Report full capacity available At power-on, or after a hardware or software reset, the default values of the features are as indicated above. Note Seagate Exos 7E8 Serial ATA Product Manual, Rev. A... -
Page 31: Commands
S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x 04 (abort) is written to the Error register. Seagate Exos 7E8 Serial ATA Product Manual, Rev. A... - Page 32 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100804238, Rev. A...
