Exos® E 2U12, 2U24, 5U84 Series
Hardware Installation and
Maintenance Guide
Abstract
This guide describes initial hardware setup for Seagate Exos E 2U12, 2U24, 5U84 Series controller enclosures and disk
enclosures. It also describes removal and installation of customer-replaceable components. The guide is intended for
use by storage system administrators familiar with servers and computer networks, network administration, storage
system administration and configurations, storage area network management, and relevant protocols.
Part Number: 204380800-00
Revision: A
Published: December 2022
Advertisement
Table of Contents
Related Manuals for Seagate Exos E 2U12 Series
Summary of Contents for Seagate Exos E 2U12 Series
- Page 1 Maintenance Guide Abstract This guide describes initial hardware setup for Seagate Exos E 2U12, 2U24, 5U84 Series controller enclosures and disk enclosures. It also describes removal and installation of customer-replaceable components. The guide is intended for use by storage system administrators familiar with servers and computer networks, network administration, storage system administration and configurations, storage area network management, and relevant protocols.
- Page 2 © 2022 Seagate Technology LLC or its affiliates. All rights reserved. Seagate, Seagate Technology, and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Exos is a trademark of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Contents 1 Introduction Knowledge prerequisites Product documentation and support Intended audience 2 System overview Expansion enclosure components Expansion enclosure chassis 2U enclosure components 5U enclosure components Optional components 3 Initial install preparations Installation checklist Complete installation prerequisites 4 Installation of 2U enclosures Unpack and prepare the 2U enclosure Install the 2U rackmount rail kit Mount the 2U enclosure into the rack cabinet... - Page 4 Interpret system LEDs Interpret 2U12 and 2U24 operator's panel LEDs Interpret SAS 12Gb/s expansion input/output module LEDs 7 Operation of 5U enclosures Apply power to the 5U enclosure Remove power from the 5U enclosure Set the unit identification number Interpret system LEDs Interpret 5U enclosure operator's panel LEDs Interpret drawer LED panels Interpret SAS 12Gb/s expansion input/output module LEDs...
- Page 5 Figures Figure 1 2U12 and 2U24 front panel area Figure 2 2U12 and 2U24 rear panel area Figure 3 5U84 front panel area Figure 4 5U84 rear panel area Figure 5 Profile and top views of fully populated 5U84 drawers Figure 6 2U12 and 2U24 expansion enclosure packaging, shown without plastic for clarity Figure 7 2U enclosure outer rail components Figure 8 Attachment of front mount bracket to front rack cabinet posts...
- Page 6 Figure 39 5U84 operator's panel fault LEDs Figure 40 5U84 drawer fault LEDs on drawer LED panel Figure 41 Drive fault LED on carrier bezel Figure 42 SAS 12GB expansion module fault LEDs Figure 43 Fan cooling module fault LEDs Figure 44 Power supply unit fault LEDs Figure 45 2U12 and 2U24 fault LEDs on carrier bezel Figure 46 Removal of 2U12 and 2U24 drive in carrier...
- Page 7 Tables Table 1 Expansion enclosure variations Table 2 Installation checklist tasks Table 3 Fault LED prioritization Table 4 Fault LED prioritization Table 5 2U enclosure non-fault conditions Table 6 5U enclosure non-fault conditions Table 7 2U enclosure corrective action for fault conditions Table 8 5U enclosure corrective action for fault conditions Table 9 2U enclosure time limits for FRU replacement Table 10 5U enclosure time limits for FRU replacement...
-
Page 8: Introduction
1 Introduction Seagate Exos E expansion enclosures combine strong performance with high reliability, flexibility, and manageability. Powerful and compact, the series expandable storage solution supports business with high-capacity and high-availability options. The system is designed for high availability (HA), with no single point of failure for data or power. Input/output modules (IOMs) are Storage Bridge Bay (SBB) v2.1 compatible for interconnects, power budgets and rails, form factors, and footprints. -
Page 9: Intended Audience
Intended audience This guide is for software integration providers, storage installation professionals, and system administration personnel. Chapter 1 Introduction... -
Page 10: System Overview
2 System overview The Seagate Exos E expansion series enclosures consist of a sheet metal chassis that contains an integrated midplane and module runner system. You can mount the expansion enclosure into a standard 19-inch rack cabinet, occupying either two (2U) or five (5U) EIA rack space units. -
Page 11: Expansion Enclosure Chassis
Expansion enclosure chassis Chassis sheet metal is bonded and riveted together and free from non-conductive coatings. Each chassis is designed specifically for mounting in a rack cabinet. 2U enclosure components The front panel area hosts an operator's panel and the drive modules. 2U12—... -
Page 12: Figure 1 2U12 And 2U24 Front Panel Area
1 2 3 4 5 Item Description Function Input button Selects and sets UID when combined with system Locate command Drive 0 Responds to commands for drive logically numbered "0" Release latch, drive module Allows drive module insertion onto and removal from the midplane and slot Anti-tamper lock, drive module Prevents drive module removal when locked Drive 3... -
Page 13: 5U Enclosure Components
The rear panel area hosts modules designed for power, thermal cooling, and host connectivity. Item Description Function Power cooling module (PCM) Provides redundant regulation of power, temperature, and airflow PCM release latch Latches or unlatches PCM from midplane Input/output module (IOM) Provides data redundancy, acts as the nerve center of the expansion enclosure Inverted IOM Inverted PCM status LEDs... -
Page 14: Figure 3 5U84 Front Panel Area
Item Description Function Operator's (ops) panel Connects to midplane, provides users with expansion enclosure information and status Drawer left sideplane indicators Registers activity for the related drive in its carrier (DDIC) and controller for the drawer's left sideplane Left pull handle in recessed Provides user access to DDICs contained in drawer pocket Drawer left side anti-tamper lock Prevents drawer access when locked... -
Page 15: Figure 4 5U84 Rear Panel Area
The rear panel area provides you access to modules designed for power, thermal cooling, and host connectivity. Item Description Function Input/output module (IOM) Provides data redundancy and is the nerve center of the expansion enclosure IOM release latch Provides full contact with midplane or releases IOM for inspection and service IOM release latch and handle Fan cooling module (FCM) Provides redundant regulation of temperature and airflow... -
Page 16: Optional Components
9 10 Item Description Function Drawer front with keyed anti-tamper lock and 2 Prevents or provides access to DDICs, contains dual drawer panel LEDs for drive drawer latches activity and fault status Right sideplane Registers DDIC activity and fault conditions for the primary host path Top drawer: Drawer 1 Contains slots logically numbered from 0 to 41 Operator's (ops) panel on left rack ear flange... - Page 17 Carrier blank— For 2U enclosures not fully populated, occupies any empty drive slot to secure proper airflow Controller blank— For 2U enclosures configured with a single controller, occupies the empty controller slot to secure proper airflow Chapter 2 System overview...
-
Page 18: Initial Install Preparations
3 Initial install preparations Each expansion enclosure installation requires the same amount of preparation to successfully mount it into your industry- standard rack cabinet of up to 1.2m in depth. WARNING! Heed all warnings and cautions on labeling and throughout this guide to reduce risk of personal injury or damage to equipment. -
Page 19: Complete Installation Prerequisites
Site preparation 1. Use the installation checklist. 2. Clear the site for installation and secure a static-protected area. Before enclosure installation 1. Unpack the enclosure in a clear area, using appropriate safety precautions. 2. Temporarily set aside all drives in carriers (DDICs) into a static-protected area, regardless of how your enclosure or drives ship. - Page 20 c. Tested, good cables for host connection that meet enclosure requirements d. The provided power cords, which meet power specifications 2. Familiarize yourself with system configuration requirements and the enclosure components. 3. Obtain the following: a. An anti-static wrist or ankle strap for handling static-sensitive components b.
-
Page 21: Installation Of 2U Enclosures
4 Installation of 2U enclosures Sequentially follow the installation checklist to install the 2U enclosure, which guides you through the related topics. Unpack and prepare the 2U enclosure CAUTION Do not operate an expansion enclosure outside the manufacturer's intended use. Storage enclosures are suitable for connection to intra-building or non-exposed wiring or cabling only. -
Page 22: Install The 2U Rackmount Rail Kit
5. Complete the following actions to prepare the 2U enclosure chassis for installation: a. Facing the chassis front, grasp the right rack flange cover, work the cover free, and set it aside in a safe location. b. Grasp the left rack flange cover, gently work the cover free, and set it aside in a safe location. Install the 2U rackmount rail kit The 2U enclosure requires rackmount hardware for installation into a standard 1.2m rack and occupies 2 EIA units of rack space (8.9cm or 3.50 inches) per unit. -
Page 23: Figure 7 2U Enclosure Outer Rail Components
To install the 2U rackmount rail kit: 1. Remove both outer rail assemblies from their packaging. Item Description Item Description Left front mount bracket Set screw, front Left front outer rail Set screw, rear Left rail slides Left rear mount bracket Figure 7 2U enclosure outer rail components 2. -
Page 24: Figure 8 Attachment Of Front Mount Bracket To Front Rack Cabinet Posts
Figure 8 Attachment of front mount bracket to front rack cabinet posts 8. Extend the length of the rail until fully mating the rear mount bracket pins in the mirror location on the rear rack post. Figure 9 Adjustment of rail length to fit rack cabinet 9. -
Page 25: Mount The 2U Enclosure Into The Rack Cabinet
Figure 10 Attachment of rear mount bracket to rear rack cabinet posts 11. Hand tighten firmly against the rack post using an 8mm nut driver or a Philips screwdriver. 12. Facing the front of the rack cabinet, hand tighten the Phillips-head M5 x 15 screw using an 8mm nut driver or a Philips screwdriver so that the hex head flange is flush with the front rack post. -
Page 26: Figure 11 Alignment Between 2U Chassis And Rails (Removed Rear Components For Clarity)
Required equipment Identification Mechanical lift Expansion enclosure with attached inner rails Rack cabinet with installed outer rails #2 Phillips-head screwdriver, 6-in length Panhead screw, M5 x 8, #2 Phillips-head screw, M5 x 15, 8mm hex flange To mount the 2U enclosure into the rack cabinet: 1. -
Page 27: Populate The 2U Enclosure
4. Complete the following actions to insert the 2U chassis into the rack cabinet: a. Facing the front of the enclosure, carefully exert even pressure on both sides of the 2U enclosure front, inserting the 2U enclosure until the rack ear flanges are flush with the front rack posts. b. -
Page 28: Test Enclosure Electrical Earth Connection
IMPORTANT Use only Cat-6 or above cables with RJ-45 connectors for Base-T connections. IMPORTANT Use only Seagate approved HD mini-SAS (SFF-8644) x4 data cables that are at least .5m (1.64 feet) in length and do not exceed 3m (9.84 feet) in length to connect to the SAS ports on each input/output module. -
Page 29: Route 2U Enclosure Host Cables And Expansion Data Cables
Route 2U enclosure host cables and expansion data cables Each 2U enclosure supports SAS cabling and several methods for connectivity to a switch or the host system. Select data cables that best align with your host environment. Fault tolerance and performance are key factors in determining how to best optimize your particular system and cabling configuration. -
Page 30: Route 2U Enclosure Power Cords
Figure 13 Sample reverse cabling method among the host system and 2U expansion modules Figure 14 Sample invalid loop (in red) among the host system and 2U expansion modules Route 2U enclosure power cords This basic task connects the supplied power cords to the redundant power cooling modules (PCMs) and then to independent power distribution units (PDUs) that are connected to an uninterruptible power system. -
Page 31: Figure 15 2U Power Cord Routing To Independent Power Distribution Units
power source that has a safety electrical earth connection. CAUTION Use only power cords supplied in the installation kit or those that meet product specifications. CAUTION Adhere to power source and power connection requirements to avoid harm to equipment. Only connect the power cooling module (PCM) to power sources that comply with product specifications and labels. Always remove all power connections before you remove a PCM from the storage or expansion enclosure. -
Page 32: Installation Of 5U Enclosures
5 Installation of 5U enclosures Sequentially follow the installation checklist to install the 5U enclosure. Unpack and prepare the 5U enclosure CAUTION Do not operate an expansion enclosure outside the manufacturer's intended use. Storage enclosures are suitable for connection to intra-building or non-exposed wiring or cabling only. Storage enclosures are suitable for installation in locations where the National Electrical Code (NEC) applies but are not suitable for Outside Plant (OSP) installations. -
Page 33: Install The 5U Rackmount Rail Kit
4. Locate three people to assist in moving the 5U enclosure in its plastic bag onto the mechanical lift, using an appropriate safe lifting technique to perform the following actions: a. Position one person at the front to grip the front belt strap securely by both loops, not by any portion of the front or rear panel areas. - Page 34 6. Locate lighter 5U enclosures above heavier ones to maximize stability. 7. Remove 5U enclosures from the top of the rack cabinet to the bottom when emptying it. Required equipment Identification Outer rails, properly oriented #2 Phillips-head screwdriver, 6-in length (Optional) 8mm nut driver, 6-in length Phillips-head screw, M5 x 15, 8mm hex flange To install the 5U rackmount rail kit:...
-
Page 35: Figure 17 5U Left And Right Rail Components
Item Description Item Description Item Description Item Description Left front mount bracket Rail slide set screw Rear mount Rack pin Left rail shelf Left rear tail Right front mount bracket Right rear mount bracket Figure 17 5U left and right rail components 3. -
Page 36: Figure 18 Insertion Of 5U Front Mount Bracket Screw
Figure 18 Insertion of 5U front mount bracket screw 6. Extend the length of the rail until the rear mount bracket pins in the mirror location on the rear rack post. 7. Verify that the rails are level at the same height on both rack posts, and that all location pins fully seat in the rack posts. 8. -
Page 37: Mount The 5U Enclosure Into The Rack Cabinet
Mount the 5U enclosure into the rack cabinet WARNING! Serious injury and mechanical failure can result if you do not adhere to rack cabinet safety precautions. To avoid risk of death or injury from tipping the rack, follow all rack installation guidelines, securing the rack cabinet to the floor with a concrete anchor kit. -
Page 38: Figure 20 Alignment Between 5U Chassis And Rails, Minus Rear Components For Clarity
Figure 20 Alignment between 5U chassis and rails, minus rear components for clarity 4. Complete the following actions to properly secure the 5U chassis on its rails: a. Keep the 5U chassis stationary on the mechanical lift. b. Conduct a visual inspection of both sides to verify the bottom of the 5U enclosure chassis rests squarely on the front of the bottom shelf of the outer rail and that the direction is straight in, not at an angle. -
Page 39: Figure 21 Secure Chassis Operator's Panel To Rack Posts
Figure 21 Secure chassis operator's panel to rack posts d. Slide the ops panel cover over the left rack ear flange until flush with the rack post. e. Repeat the process for securing the right rack ear flange and replacing the right rack ear cover. f. -
Page 40: Access A Drawer
Access a drawer Each tamper-resistant drawer contains 42 slots for drives in carriers (DDICs). The drawer supports its DDIC contents and own weight when partially or fully open. A safety latching mechanism prevents access to more than one drawer at a time. CAUTION Only open a drawer for no more than 10 minutes, or you will compromise airflow and cooling. -
Page 41: Populate The 5U Enclosure
Populate the 5U enclosure After successfully mounting the 5U chassis into the rack cabinet, populate the 5U enclosure. CAUTION If you partially populate the expansion enclosure with drives in their carriers (DDICs), you must comply with several additional requirements. You must install a minimum of DDICs. Populate in rows, DDICs at a time, from front to back of the drawer, and alternate between drawers. -
Page 42: Test Enclosure Electrical Earth Connection
IMPORTANT Use only Seagate approved HD mini-SAS (SFF-8644) x4 data cables that are at least .5m (1.64 feet) in length and do not exceed 3m (9.84 feet) in length to connect to the SAS ports on each input/output module. -
Page 43: Route 5U Enclosure Host Cables And Expansion Data Cables
Route 5U enclosure host cables and expansion data cables Fault tolerance and performance are key factors in determining how to best optimize your system and cabling configuration. This topic assumes a fault-tolerant reverse cabling method, since it provides a method of maintaining access to all enclosures in the chain, even if one of the enclosures fails or requires removal. -
Page 44: Route 5U Enclosure Power Cords
Figure 27 Sample reverse cabling method among the 5U host system and expansion modules Figure 28 Sample invalid loop (in red) among the 5U host system and expansion modules Route 5U enclosure power cords This task provides direction to connect supplied power cords to the redundant power supply units (PSUs) connected to an uninterruptible power system. -
Page 45: Figure 29 5U Power Cord Routing To Independent Power Distribution Units
CAUTION Use only power cords supplied in the installation kit or those that meet product specifications. CAUTION Adhere to power source and power connection requirements to avoid harm to equipment. Only connect the power supply unit (PSU) to power sources that comply with product specifications and labels. Always remove all power connections before you remove a PSU from the storage or expansion enclosure. -
Page 46: Operation Of 2U Enclosures
6 Operation of 2U enclosures CAUTION Only operate the expansion enclosure in a dust-free environment to meet temperature control and airflow requirements. Before you power on the 2U enclosure, you must take the following actions: 1. Review the installation checklist, confirming the successful completion of the entire sequence. 2. -
Page 47: Remove Power From The 2U Enclosure
Remove power from the 2U enclosure The 2U enclosure relies on main power provided through separate, independent power distribution. If you lose main power for any reason, the 2U enclosure automatically restarts after power restoration. You must quiesce all data exchange before removing power to the 2U enclosure. To remove power from the 2U enclosure: CAUTION Never remove power from a redundant ... -
Page 48: Table 3 Fault Led Prioritization
3. Amber LED: Indicates a critical fault 4. Blue LED: Indicates system component identification, so is not a fault or critical condition Since an amber fault LED uses fast or slow flashes to cover multiple conditions, this is the priority for simultaneous indications: Table 3 Fault LED prioritization Priority Flash rate... -
Page 49: Figure 30 2U12 And 2U24 Operator's Panel Leds
Type Color State Status 2U enclosure power is on Power on or standby Green 2U enclosure power off 2U enclosure drive module fault, when paired with drive fault LED Module fault Amber Module fault in rear panel area, when paired with a module fault LED 2U enclosure functioning properly Flashing 2U enclosure unit identification (UID) request active... -
Page 50: Figure 31 Sas 12Gb/S Expansion Input/Output Module Leds
С Type Color State Status Ops panel undergoing 5s test Rear panel area fault: IOM, fan, PSU Drive module hardware fault, paired with drive module fault LED Module fault Amber Unknown, invalid, or mixed module type Flashing* Vital product data (VPD) configuration error or 1²C bus failure Rear panel area modules ... - Page 51 7 Operation of 5U enclosures CAUTION Only operate the expansion enclosure in a dust-free environment to meet temperature control and airflow requirements. Before you power on the 5U enclosure, you must take the following actions: 1. Review the installation checklist, confirming the successful completion of the entire sequence. 2.
- Page 52 Remove power from the 5U enclosure The 5U enclosure relies on main power provided through separate, independent power distribution. If you lose main power for any reason, the 5U enclosure automatically restarts after power restoration. You must quiesce all data exchange before removing power to the 5U enclosure. To remove power from the 5U enclosure: CAUTION Never remove power from a redundant ...
-
Page 53: Table 4 Fault Led Prioritization
3. Amber LED: Indicates a critical fault 4. Blue LED: Indicates system component identification, so is not a fault or critical condition Since an amber fault LED uses fast or slow flashes to cover multiple conditions, this is the priority for simultaneous indications: Table 4 Fault LED prioritization Priority Flash rate... -
Page 54: Figure 32 5U84 Operator's Panel Leds
Type Color State Status Unit identification (UID) of 5U enclosure (0 to 99) Unit ID Green Flashing (1s on, 1s off) SCSI enclosure services (SES) controlled UID or locate active Green 5U enclosure power is on Power on or Amber 5U enclosure has AC power and is on standby as enclosure comes online standby None... -
Page 55: Figure 33 5U84 Drawer Led Panel
LED Type Color State Status Power and Drawer power on and sideplane hardware functioning properly sideplane Green Power to drawer off Drawer module fault condition for drawer sideplane or drive Drawer module Amber Flashing (1s on, 1s off) Unit identification (UID) or locate active for drawer sideplane or drive fault Drawer modules functioning properly Drive hardware fault condition... -
Page 56: Figure 34 Sas 12Gb/S Expansion Input/Output Module Leds
С Type Color State Status Ops panel undergoing 5s test Rear panel area fault: IOM, fan, PSU Drive module hardware fault, paired with drive module fault LED Module fault Amber Unknown, invalid, or mixed module type Flashing* Vital product data (VPD) configuration error or 1²C bus failure Rear panel area modules ... - Page 57 IMPORTANT Do not use this section for configured systems already interacting with production data. For the kind of assistance you need in such cases, contact Seagate for technical support. Address initial start-up issues You must successfully complete the installation tasks in the identified sequence. You must use the power cords provided with the system and install interface cables that meet system requirements.
-
Page 58: Figure 35 2U12 And 2U24 Operator's Panel Fault Leds
6. Complete the following actions if the enclosure does not report as much capacity as expected: a. Verify you correctly installed the drive modules, and they are all latched to the baseplane connectors. b. Verify all installed drive module carriers display green LEDs, rather than fault LEDs. See "Replace a 2U enclosure drive module in its carrier"... -
Page 59: Figure 36 2U12 And 2U24 Fault Leds On Carrier Bezel
Color State Status The drive module has a hardware fault, so replace as soon as possible The power control circuit has a hardware fault Fast flash (1s on, 1s off) Unit identification (UID) bit is set Amber Slow flash*(3s on, 1s off) Failed array Drive is functioning normally No AC power is present... -
Page 60: Figure 38 Power Cooling Module Fault Leds
Power cooling module fault LEDs The 580W power cooling module (PCM) has 4 LEDs to identify various states. When no LEDs are on, there is no AC power to the PCM. The asterisk (*) indicates a fault condition. Status Type AC fault PCM OK Fan fault DC fault Color... -
Page 61: Figure 39 5U84 Operator's Panel Fault Leds
Type Color State Status Ops panel completing 5s test 5U enclosure rear panel area module fault: IOM, fan, or PSU when paired with module fault LED Drive fault, when paired with drive fault LED Module fault Amber Unknown, invalid, or mixed module type, such as drive or PSU Flashing* VPD configuration error or 1²C bus failure 5U enclosure rear panel area modules functioning properly... -
Page 62: Figure 40 5U84 Drawer Fault Leds On Drawer Led Panel
Type Color State Status Component within drawer fault condition¹ Drive fault¹ Drawer module fault Amber Flashing* Unit ID (UID) or locate is active for drawer sideplane or drive Drawer modules functioning properly Drive hardware fault condition Logical fault Amber Flashing* One or more arrays impacted by drive hardware fault conditions Drive hardware functioning properly Cable from rear panel to drawer fault condition²... -
Page 63: Figure 42 Sas 12Gb Expansion Module Fault Leds
Expansion module fault LEDs The expansion module has a number of ports, some with independent status LEDs. The amber LEDs listed below are the only ones that provide fault condition status. The asterisk (*) indicates a fault condition. С Type Color State Status... -
Page 64: Figure 43 Fan Cooling Module Fault Leds
Type Color State Status FCM hardware functioning properly FCM OK Green Off* FCM hardware fault: over temperature, over voltage, over current Fan speed is out of tolerance FCM fault Amber Communication with input/output module (IOM) lost FCM hardware functioning properly Figure 43 Fan cooling module fault LEDs Power supply unit fault LEDs Each power supply unit (PSU) has three status LEDs. -
Page 65: Table 5 2U Enclosure Non-Fault Conditions
Identify 2U enclosure fault conditions Fault conditions do not necessarily cause the 2U enclosure to cease functioning. Fault conditions do require a system administrator to take an appropriate action to clear the fault condition. The input/output modules (IOMs) allow you to choose from multiple fault isolation methods. This section provides the basic methodology used to locate faults within a storage system, then identify the affected FRUs. -
Page 66: Table 6 5U Enclosure Non-Fault Conditions
When performing fault isolation and troubleshooting steps, select the option or options that best suit your site environment. Use of any one of the following options is not mutually exclusive to the use of another option. The order for the options is based on frequency of use. - Page 67 CAUTION When you suspect a drive module or connection is the fault, halt all input and output operations to the disk group or groups from all hosts as a data protection precaution. Make sure your regularly scheduled backup is good and that you conduct another backup at the time of failure as an additional data protection precaution.
-
Page 68: Table 7 2U Enclosure Corrective Action For Fault Conditions
Take corrective action for 2U enclosures After you follow the process above and isolate the fault to an area of the 2U enclosure or to a particular module, use the following chart to determine the type of corrective action you should take. Table 7 2U enclosure corrective action for fault conditions Symptom Cause... -
Page 69: Table 8 5U Enclosure Corrective Action For Fault Conditions
Table 7 2U enclosure corrective action for fault conditions (continued) Symptom Cause Recommended action Module fault LED is on Internal temperature 1. Confirm you have met ambient temperature requirements identified in the exceeds the present Environmental Requirements section and that the air flow moves from the threshold for the front to the rear of the enclosure. - Page 70 Table 8 5U enclosure corrective action for fault conditions (continued) Symptom Cause Recommended action Module fault LED is on A fault condition related 1. Inspect the drawer panel for a fault amber LED that is on. to the hardware or system 2.
- Page 71 4. If the PSU is still failing, remove it, wait 1 minute, then reseat it. 5. If the PSU is still failing, replace it within the specified 6 minutes. 6. If the power fault condition persists, contact Seagate for support. Chapter 8 Hardware installation and configuration issues...
- Page 72 Table 8 5U enclosure corrective action for fault conditions (continued) Symptom Cause Recommended action Module fault LED is on A fault condition related 1. Restart the expansion module with a command.. to the hardware in the 2. Confirm the redundant IOM module is properly functioning. rear panel area 3.
-
Page 73: Table 9 2U Enclosure Time Limits For Fru Replacement
9 In-service field maintenance for 2U enclosures You may service the identified 2U enclosure FRUs and still maintain continuous operation during the replacement, but with two very important qualifiers: You must determine whether your system allows for continuous operation during service replacement of the 2U enclosure drive modules in their carriers (DDICs) without interrupting access to enclosure file systems. -
Page 74: Figure 45 2U12 And 2U24 Fault Leds On Carrier Bezel
g. When removing a FRU, immediately place it in anti-static packaging. h. Avoid touching pins, leads, or circuitry. Replace a 2U enclosure drive module in its carrier The operator's (ops) panel registers either a logical fault or a hardware fault or both. The drive module in its carrier (DDIC) uses an amber LED to identify various states and fault conditions. -
Page 75: Figure 46 Removal Of 2U12 And 2U24 Drive In Carrier
To replace a 2U enclosure drive module in its carrier: 1. Complete the following actions to remove a faulty DDIC: a. Facing the front of the 2U enclosure, locate the DDIC with a fault condition. b. Using a thumb and forefinger, squeeze the carrier release latch to release the connection to the midplane. c. -
Page 76: Figure 47 Replacement With Open 2U12 And 2U24 Carrier Handle
a. Using a thumb and forefinger, squeeze the carrier release latch to release the carrier handle. Figure 47 Replacement with open 2U12 and 2U24 carrier handle b. Use one hand to support the weight of the DDIC and the other to holding it against the bottom of the slot. c. -
Page 77: Figure 48 Sas 12Gb/S Expansion Input/Output Module Leds
С Type Color State Status Ops panel undergoing 5s test Rear panel area fault: IOM, fan, PSU, when paired with IOM fault Drive module hardware fault, paired with drive module fault LED Module fault Amber Unknown, invalid, or mixed module type Flashing* Vital product data (VPD) configuration error or 1²C bus failure Rear panel area modules ... -
Page 78: Figure 49 Input/Output Module Removal, Upper
С С Figure 49 Input/output module removal, upper b. Pull the handle outward to lever the IOM away from the midplane. c. Use one hand to support the weight of the IOM and the other to gently withdraw the IOM from its slot. d. - Page 79 CAUTION Never remove power from a power cooling module if the partner power cooling module amber LED is lit. The 580W AC PCM input voltage range is from 100V to 240V AC with an input frequency of 50Hz to 60 Hz. Each PCM uses 4 LEDs to identify various states.
-
Page 80: Figure 51 Power Cooling Module Removal
within the identified time limit, you void the product warranty and the expansion enclosure might overheat, causing equipment failure and possible data loss. To replace a power cooling module: 1. Retrieve the new PCM in its static-protected container, ready to immediately replace the faulty one. 2. - Page 81 4. Verify that the PCM OK LED is lit green on the replaced PCM after properly inserting and seating it in the empty slot. 5. Facing the front of the expansion enclosure, verify that the Power On LED is green and there are no fault conditions. Chapter 9 ...
-
Page 82: Table 10 5U Enclosure Time Limits For Fru Replacement
10 In-service field maintenance for 5U enclosures You may service the identified 5U enclosure FRUs and still maintain continuous operation during the replacement, but with two very important qualifiers: You must determine whether your system allows for continuous operation during service replacement of the 5U enclosure drive modules in their carriers (DDICs) without interrupting access to enclosure file systems. -
Page 83: Figure 53 Drive Fault Led On Carrier Bezel
f. Use conductive field service tools. g. When removing a FRU, immediately place it in anti-static packaging. h. Avoid touching pins, leads, or circuitry. Replace a 5U enclosure drive module in its carrier The operator's (ops) panel registers either a logical fault or a drawer hardware fault or both. You must locate a faulty drive in its carrier (DDIC) within the related drawer by its amber fault condition LED. -
Page 84: Figure 54 Operator's Panel
Figure 54 Operator's panel Figure 55 Drawer panel b. If the anti-tamper lock is engaged, use a T20 Torx driver to unlock both drawer pull handles. c. Simultaneously press both drawer latches inward and hold them there while exerting even outward pressure until all three rows are visible and the drawer slide latch locks in the open position. -
Page 85: Figure 57 Carrier Latch Features
a. Locate the DDIC with a fault condition. Item Description Item Description Top portion of carrier latch Bottom portion of carrier latch Release latch, release latch arrow, open state 4 Fault condition LED Figure 57 Carrier latch features b. Using a thumb, press the DDIC release latch arrow to the right to release the DDIC from its seated position. c. -
Page 86: Figure 59 Replacement Of Drive In Its Carrier
Figure 59 Replacement of drive in its carrier c. Push the DDIC down until the top is flush with the top of the slot. d. While holding it against the bottom of the slot, slide the top latch toward the rear of the drawer until it locks into place and the DDIC ... -
Page 87: Figure 62 Safety Lock To Release Left Drawer Slide Rail Of Lower Drawer
4. Complete the following actions to close the related drawer: a. Press and hold the safety lock latches with the blue touchpoint at the front of both extended drawer slide rails. Figure 62 Safety lock to release left drawer slide rail of lower drawer b. -
Page 88: Figure 63 Sas 8Gb/S Input/Output Module Leds
The IOM has a number of ports, each with independent status LEDs. Those items in the state column with an asterisk (*) indicate a fault condition. С Type Color State Status Ops panel undergoing 5s test Rear panel area fault: IOM, fan, PSU Drive module hardware fault, paired with drive module fault LED Module fault Amber... -
Page 89: Figure 64 Input/Output Module Removal, Left
С С Figure 64 Input/output module removal, left c. Pull the handle outward to lever the IOM away from the midplane. d. Use one hand to support the weight of the IOM and the other to gently withdraw the IOM from its slot. e. -
Page 90: Figure 66 Fan Cooling Module Fault Leds
4. Verify that the LED is lit green on the replaced IOM after properly inserting and seating it in the empty slot. 5. Facing the front of the 5U enclosure, verify that the Power On LED is green and there are no fault conditions. Replace a 5U fan cooling module Fan cooling modules (FCMs) provide cooling to the 5U enclosure modules and components. -
Page 91: Figure 67 Fan Cooling Module Removal
С С Figure 67 Fan cooling module removal c. Place it in a static-protected location. 3. Complete the following actions to replace the faulty FCM with a tested, good one: a. Orient the new FCM with the latch to the right. Figure 68 Replacement fan cooling module b. -
Page 92: Figure 69 Power Supply Unit Fault Leds
Status Type PSU fault AC fault PSU OK Color Amber Amber Green AC power not present PSU present, but not supplying power Flashing Firmware download to PSU in progress AC power present, power switch is on, providing power Flashing AC power present, PSU on standby, other PSU providing power State Communication with input/output module (IOM) lost PSU hardware fault... -
Page 93: Figure 70 Power Supply Unit Removal
2. After you complete the proper shut down of the application and when you are ready to power down the expansion enclosure, face the rear of the rack cabinet and switch off the power for the faulty PSU. 3. Disconnect each power connector from the power distribution unit (PDU). 4. - Page 94 7. Facing the front of the 5U enclosure, verify that the Power On LED is green and there are no fault conditions. 94 Chapter 10 In-service field maintenance for 5U enclosures...
-
Page 95: Table 11 Expansion Enclosure Dimensions
A Technical specifications Table 11 Expansion enclosure dimensions Dimension type 2U12, 2U24 5U84 Metric units Imperial units Metric units Imperial units Height 87.90mm 3.46 in 220.00mm 8.65 in Width, excluding rails 483.00mm 19.01 in 483.00mm 19.00 in Depth, excluding cables 630.00mm 24.80 in 933.00mm... -
Page 96: Table 14 Power Specifications
Table 14 Power specifications Type Description Input power 100V to 240V AC, 50Hz to 60Hz 200V to 240V AC, 50Hz to 60Hz requirements Voltage Max output: 580W Max output: 2200W Range: 100V to 240V AC, rated Range: 200V to 240V AC, rated Frequency: 50Hz to 60Hz Frequency: 50Hz to 60Hz Hot-... -
Page 97: Table 15 Standard And Approvals
B Standards and regulations International standards The expansion enclosure complies with the requirements of the following agencies and latest editions of these standards: Table 15 Standard and approvals Type Specification UL 60950-1; UL & cUL to UL 62368-1 2nd Ed CAN/CSA-C22.2 No. - Page 98 Index drive module access 10-11, 13-14 2U12 carrier (DDIC) 27, 59, 62, 73-74, 82-83, large form factor (LFF) enclosure 10-11, 73, 82, carrier latch fault 49-50, 54-56, 59, 61-62, 68, 70, 74-75, 77, 2U24 fully latched, 2U small form factor (SFF) enclosure 10-11, 73, 82, fully latched, 5U large form factor (LFF) mixed type, invalid, unknown 50, 54,...
