Summary of Contents for Chauvet LED PAR 38-18UVB
-
Page 1: User Manual
LED PAR 38-18UVB Snapshot Use on Dimmer Outdoor Use Sound Activated Master/Slave Auto-ranging Power Supply Replaceable Fuse User Serviceable Duty Cycle User Manual 5200 NW 108th Avenue, Sunrise, FL 33351 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
ABLE OF ONTENTS 1. BEFORE YOU BEGIN ............................... 3 ....................................3 HAT IS NCLUDED ..................................3 NPACKING NSTRUCTIONS ..................................3 ANUAL ONVENTIONS ........................................3 CONS ..................................4 AFETY NSTRUCTIONS 2. INTRODUCTION ................................5 ......................................5 EATURES ..................................5 DDITIONAL EATURES .................................. -
Page 3: Before You Begin
Manual Conventions CHAUVET manuals use the following conventions to differentiate certain types of information from the regular text. EANING... -
Page 4: Safety Instructions
Safety Instructions Please read these instructions carefully. It includes important information about the installation, usage and maintenance of this product. • Please keep this User Manual for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. -
Page 5: Introduction
2. I NTRODUCTION Features • 2-channel DMX LED black light PAR can • Manual dimming with or without DMX controller • Built-in automated programs via master/slave or DMX with variable speed • Built-in sound activated programs via master/slave or DMX Additional Features •... -
Page 6: Product Overview
Product Overview Control Panel Power Output Fuseholder Power Input Microphone Attachment Bolt (not meant to be adjusted) Bracket Adjustment Knob Audio Adjustment Knob DMX In DMX Out Gel Frame Hanging/mounting Release (13 mm hole) Gel Frame Power Input Light Output Power Output Bracket Adjustment Knob... -
Page 7: Setup
Additional power link out The power linking shown in this document is for the Chauvet® North American version ONLY! Therefore, it is the customer’s responsibility to check with the Dealer/Distributor regarding power linking on the local version of the product. Connections and availability may change, depending on the power requirements and/or regulations of each country/region. -
Page 8: Orientation
Mounting Orientation The LED PAR 38-18UVB may be mounted in any safe position provided there is adequate room for ventilation. Rigging Be sure that the structure can support the weight of the fixture. Please see the “Technical Specifications” section of this manual for a detailed weight listing. Mount the fixture securely. -
Page 9: Operating Instructions
In addition, you should note the starting address selected for future reference. The LED PAR 38-18UVB fixture uses two DMX channels. If this is your first time using DMX, we recommend reading the “DMX Primer” section in the “Appendix”. -
Page 10: Dmx Operation
DMX Operation This is the operating mode which will allow for control with an external DMX controller. You must set the starting address for this mode. If this is your first time using DMX, then it is recommended that you refer to the “DMX Primer”... -
Page 11: Custom Static Intensity
Custom Static Intensity This fixture has the ability to accept custom static intensity. This is accessed via the control panel. Please see the instructions below for further explanation. Press <MENU> until appears on the LED screen. Using <UP> and <DOWN>, select the desired intensity value, from lowest to highest ( By selecting , the output will remain off. -
Page 12: Appendix
Maximum recommended number of fixtures on a serial data link: 32 Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET® certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 13: Dmx Data Cable
DMX Data Cable Use a Belden© 9841 or equivalent cable which meets the specifications for EIA RS-485 applications. Standard microphone cables cannot transmit DMX data reliably over long distances. The cable must have the following characteristics: Type: shielded, 2-conductor twisted pair Maximum capacitance between conductors: 30 pF/ft Maximum capacitance between conductor and shield:... -
Page 14: General Troubleshooting
Products returned without the RMA # will be refused. Call CHAUVET® and request an RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. Be sure to pack fixture properly;... -
Page 15: Technical Specifications
PHOTO OPTIC Coverage Angle .................................. 23° THERMAL Maximum ambient temperature ......................... 104° F (40° C) ORDERING INFORMATION LED PAR 38-18UVB (Black) ........................LEDPAR3818UVB WARRANTY INFORMATION Warranty .............................. 2-year limited warranty Contact Us W o r l d W i d e General Information CHAUVET®...
