Char-Broil 12301782 Product Manual

14” tabletop charcoal grill
Hide thumbs

Advertisement

Quick Links

Download this manual
14" Tabletop
Charcoal Grill
Product Guide
Model 12301782
Tools needed for assembly:
Phillips Screwdriver
Adjustable Wrench
(Tools not provided)
IMPORTANT: Fill out the product record information below.
Date Purchased
CAUTION:
Read and follow all safety statements, assembly
instructions, and use and care directions before
attempting to assemble and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
WARNING:
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off
carbon monoxide, which has no odor. NEVER burn
charcoal inside homes, vehicles, or tents.
MADE IN CHINA
Importador: EVANS POWER EQUIPMENT, S.A. DE C.V.
Camino a Cóndor # 399, Col. El Castillo C.P.45680
El Salto, Jalisco, Mexico Tel. 0133 3668 2500
FOR OUTDOOR USE ONLY
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges! Wear
protective gloves if necessary.
If you have any questions or Need
help during the Assembly, call 01800
00EVANS
42804829 - 12/16/11

Advertisement

loading

Related Manuals for Char-Broil 12301782

Summary of Contents for Char-Broil 12301782

  • Page 1: Product Record Information

    14” Tabletop Charcoal Grill Product Guide Model 12301782 Tools needed for assembly: Phillips Screwdriver Adjustable Wrench (Tools not provided) IMPORTANT: Fill out the product record information below. Date Purchased FOR OUTDOOR USE ONLY CAUTION: WARNING: Read and follow all safety statements, assembly Failure to follow all manufacturer’s instructions could...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING Product Record Information ......1 FAILURE TO READ AND FOLLOW INSTRUCTIONS FOR Safety Symbols.

  • Page 3: Grilling

    GRILLING Charcoal is recommended, however, wood or a combination of both may be used as the fuel source for grilling with the fuel source placed and ignited on the charcoal grate. Do not build too large of a fire. We recommend starting a fire with no more than 10 briquettes and adding more as needed during cooking.
  • Page 4 Know When Your Fire is Ready Successful charcoal grilling depends on a good fire. The general rule for knowing when your coals are ready for grilling is to make sure that 80 percent or more of the coals are ashy gray. If you have less than that, the coals are not ready, and if all of them are glowing red hot, the fire is probably too hot.
  • Page 5 Direct and Indirect Grilling Direct Grilling - For most grilling, the ignited coals are spread in a single layer under the food. This is called direct grilling and is appropriate for relatively quick-cooking items such as hamburgers, steaks and most seafood. The single layer of coals emits even, steady heat, whether the grill lid is open or closed, and represents the way most people grill.

  • Page 6: Warranty

    EVANS POWER EQUIPMENT, S.A. DE C.V. Camino a Cóndor # 399, Col. El Castillo C.P.45680 El Salto, Jalisco, Mexico Tel. 0133 3668 2500 www.evans.com.mx Producto / Product: Asador de carbon / Charcoal grill Modelo(s) / Model (s): EVANS POWER EQUIPMENT, S.A. DE C.V. garantiza este producto por el término de 90 dias en todas sus partes y mano de obra contra cualquier defecto de fabricación y funcionamiento a partir de la fecha de la compra bajo las siguientes condiciones: 1.

  • Page 7: Parts List/ Parts Diagram

    PARTS LIST / DIAGRAM Description TOP LID LID HANDLE DAMPER F/ LID FIREBOWL ASH CATCHER DAMPER F/ ASH CATCHER LEG SUPPORT COOKING GRATE CHARCOAL GRID NOT Pictured … HARDWARE PACK … ASSEMBLY MANUAL, ENGLISH … ASSEMBLY MANUAL, SPANISH HARDWARE LIST SCREW M6 X 11 - 2 PIECES SCREW WITH WASHER M5 X 7 - 4 PIECES SCREW M5 X 7 - 1 PIECE...
