American Standard One Deck Mount Tub Filler 2064.900 Specification Sheet

2064.901 Shown
9-1/2"
(240mm)
6-3/4"
(170mm)

GENERAL DESCRIPTION:

Durable brass spout with built-in diverter (on 2064.901).
Rigid brass and copper waterway below deck provided for 12"
installations (can be cut for 8" installations). Brass valve
bodies with 3/4" NPT inlets. 1/4 turn washerless ceramic disc
valve cartridges. Personal shower features a 6-1/2' long hose
(1-1/2' heavy duty hose and 5' decorative hose.) 2.5
gpm/9.5L/min. maximum flow rate.
SUGGESTED SPECIFICATION:
Two handle deck-mount tub filler shall feature brass construction with brass and copper waterway. Shall also feature 1/4
turn washerless ceramic disc valve cartridges. Fitting shall be American Standard Model #2064.___.___
© 2008 AS America Inc.
2" D.
(52mm) D.
9-3/4"
(247mm)
MOUNTING
SURFACE
79mm
(1-1/8") D.
102mm
(4")
(H)
3/4-14 MALE
N.P.T. INLETS
27mm
(1-1/16") D.
MODEL NUMBER:
2064.901 Deck-Mount Tub Filler
Personal shower. Metal Lever handles.
2064.900 Deck-Mount Tub Filler
Less personal shower. Metal Lever handles.
165mm to 305mm
(6-1/2 to 12) ADJ.
3-1/4" D.
(82mm) D.
76mm
(C)
305mm
(12") MAX

PRODUCT FEATURES:

Brass Construction:
with water. Provides the finest surface for application of all
finishes.
Ceramic Disc Valve Cartridges:
drip-free performance.
Exclusive Handle Alignment System:
tuning of handle position.
Choice of Finishes:
Satin Nickel (PVD).
B51
DECK-MOUNT TUB FILLER
2-1/16" D.
(52mm) D.
2-3/4"
(71mm)
(3")
30mm
(1-3/16") D.
Durable. Ideal for prolonged contact
Assures a lifetime of
Available in Polished Chrome or
ONE
32mm
(1-1/4")
MAX.
Allows fine
