▶ ESATA Port
The ESATA (External SATA) port is for attaching the ESATA hard drive.
▶ USB 3.0 Port
USB 3.0 port is backward-compatible with USB 2.0 devices. Supports data transfer rate
up to 5 Gbit/s (SuperSpeed).
Important
If you want to use a USB 3.0 device, you must use the USB 3.0 cable to connect to
the USB 3.0 port.
▶ LAN
The standard RJ-45 LAN jack is for connection to
the Local Area Network (LAN). You can connect a
network cable to it.
LED Color LED State
Left Yellow Off
On(Steady state)
On(brighter & pulsing)
Right Green Off
On
Orange On
▶ Audio Ports
These audio connectors are used for audio devices. It is easy to differentiate between
audio effects according to the color of audio jacks.
■ Line-In (Blue) - Line In, is used for external CD player, tape-player or other
audio devices.
■ Line-Out (Green) - Line Out, is a connector for speakers or headphones.
■ Mic (Pink) - Mic, is a connector for microphones.
■ RS-Out (Black) - Rear-Surround Out in 4/ 5.1/ 7.1 channel mode.
■ CS-Out (Orange) - Center/ Subwoofer Out in 5.1/ 7.1 channel mode.
■ SS-Out (Gray) - Side-Surround Out 7.1 channel mode.
Yellow
Condition
LAN link is not established.
LAN link is established.
The computer is communicating with another computer on the LAN.
10 Mbit/sec data rate is selected.
100 Mbit/sec data rate is selected.
1000 Mbit/sec data rate is selected.
MS-7522 MS-7522
Green/ Orange
2-13
