2. Remove the PCH heat sink by lifting straight up (2).
NOTE:
system board components, it may be necessary to move the heat sink from side to side to
detach it.
NOTE:
the system board components each time the heat sink is removed. Replacement thermal material is
included with the base enclosure, heat sink, processor, and system board spare part kits.
Reverse this procedure to install the PCH heat sink.

Processor

NOTE:
The processor spare part kit includes replacement thermal material.
Description
Intel Core i7-3632QM (2.2 GHz, SC turbo up to 3.1 GHz, 1600MHz/6 MB L3 cache, quad
core, 35 W)
Intel Core i5-3230M (2.6 GHz, SC turbo up to 3.1 GHz, 1600 MHz/3 MB L3 cache, dual core,
35 W)
Intel Core i5-3210M (2.5 GHz, SC turbo up to 3.1 GHz, 1600 MHz/3 MB L3 cache, dual core,
35 W)
Intel Core i3-3130M (2.6 GHz, 1600 MHz/3 MB L3 cache, dual core, 35 W)
Intel Core i3-3120M (2.5 GHz 1600 MHz/3 MB L3 cache, dual core, 35 W)
Intel Core i3-3110M (2.4 GHz 1600 MHz/3 MB L3 cache, dual core, 35 W)
Intel Core i5-2450M (2.5 GHz, SC turbo up to 3.10 GHz, 1333 MHz/3 MB L3 cache, dual
core, 35 W)
Intel Core i3-2370M (2.4 GHz, 1333 MHz/3 MB L3 cache, dual core 35 W)
84 Chapter 4 Removal and replacement procedures
Due to the adhesive quality of the thermal material located between the heat sink and
The thermal material must be thoroughly cleaned from the surfaces of the heat sink and
Spare part number
701658-001
711903-001
680645-001
713163-001
700627-001
682417-001
676359-001
677152-001
