- Page 5 USB 2.0 Hub and/or to the connected devices. Congratulations and thank you for purchasing the Belkin 4-Port USB 2.0 Hub (the Hub). The Hub provides four downstream USB ports that are compatible with both USB 1.1 (low- and full-speed) devices, as well as with USB 2.0 (high-speed) devices.
- Page 6 P73889ea-B_F5U221_man_5-02.qxd 10-10-2003 17:06 Page 2 Features •Compliant with Universal Serial Bus specification 2.0 (data rate 1.5/12/480Mbps) •Backward-compatible with Universal Serial Bus Specification 1.1 (data rate 1.5/12Mbps) •Compatible with Windows® 98SE, Me, 2000, and XP •Approved by USB Implementers Forum (USB-IF) •Supports Plug-and-Play specifications •Supports “hot swapping”...
-
Page 7: Technical Specifications
P73889ea-B_F5U221_man_5-02.qxd 10-10-2003 17:06 Page 3 Technical Specifications Upstream Ports: Downstream Ports: Per-Port Voltage: DC +5V Per-Port Current: 500mA (max.) Power Mode: Self-powered Operation Temperature: 5°C~40°C Storage Temperature: -20°C~60°C Enclosure: Plastic Power Supply: Output: DC 6V 2.5A Plug Size: 5.5mm (outer) 2.1mm (center) Plug Polarity: center positive... - Page 8 P73889ea-B_F5U221_man_5-02.qxd 10-10-2003 17:06 Page 4 Technical Specifications (continued) Main Power LED Color Definitions: Not operational Steady Red Operational Port-Status LED Color Definitions Not operational Amber Error condition Steady Green Fully operational Blinking Off/Green Software attention Blinking Off/Amber Hardware attention...
-
Page 9: Product Detail
P73889ea-B_F5U221_man_5-02.qxd 10-10-2003 17:06 Page 5 Product Detail Figure 1 Power LED Per-Port Status LED Upstream Port Downstream DC 6V 2.5A Ports Power Jack... -
Page 10: Hardware Installation
P73889ea-B_F5U221_man_5-02.qxd 10-10-2003 17:06 Page 6 Hardware Installation 1. Plug the AC adapter into a wall outlet or surge suppressor. Plug the DC connector into the DC power jack found on the back of the Hub (See Figure 1). 2. Plug the USB-A cable connector into the downstream port of your computer, or downstream port of another hub. - Page 11 P73889ea-B_F5U221_man_5-02.qxd 10-10-2003 17:06 Page 7 Hardware Installation (continued) USB-A Connector USB-B Connector Figure 2 Figure 3 Port 1 Port 2 Upstream Port Port 3 Port 4 Figure 4...
-
Page 12: Fcc Statement
Belkin Components warrants this product against defects in materials and workmanship for its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product. - Page 13 Belkin Components, Ltd. 7 Bowen Cresent • West Gosford NSW 2250 • Australia Tel: +61 (2) 4372 8600 Fax: +61 (2) 4372 8603 © 2002 Belkin Components. All rights reserved. All trade names are registered trademarks of respective manufacturers listed.
