Paper Detailed Settings Dialog Box - Canon imagePROGRAF iPF6400 User Manual

iPF6400
•
The job name when printing the adjustment pattern is "Original Image Name + Pattern-Print". For example, the print job
name for the image "ABC.jpg" is "ABC_Pattern-Print.jpg".
Note

Paper Detailed Settings Dialog Box

Paper Detailed Settings Dialog Box

This dialog box appears when you click the Advanced Settings button on the Main Sheet. You can set Drying Time
and Roll Paper Margin for Safety by media type.
• Drying Time
Between Pages
This sets the wait time for the ink to dry between each completely printed sheet and the output of the sheet.
Setting
Printer Default
None
30sec. / 1min. / 3min. / 5min. /
10min. / 30min. / 60min.
Between Scans
This sets the wait time between line scans during printing.
Setting
Printer Default
None
1sec. / 3sec. / 5sec. / 7sec. / 9sec.
• Roll Paper Margin for Safety
Near End Margin
This sets the length of the near end margin of the roll paper.
Setting
Printer Default
3mm
20mm
• Cut Speed
This selects the auto cut speed.
User's Guide
The settings of the printer operating panel are applied.
The paper is ejected immediately after printing.
The sheet is ejected when the specified time after printing has elapsed.
The settings of the printer operating panel are applied.
The printing continues to the next line immediately after the last line.
The printing continues to the next line after the set time.
*For the media type that has problems, such as ink smears on the page or colors that seem un-
even during borderless printing etc., increase the value for this setting.
The settings of the printer operating panel are applied.
Print at a standard size.
*Select for Media Type that has no problem when printing with a standard size margin.
Select this when rubbing against the printhead occurs such as when using paper that tends to
curl.
Paper Detailed Settings Dialog Box
Details
Details
Details
275
