Removing The Roll From The Printer - Canon imagePROGRAF iPF6300S User Manual

Handling Paper >
5.
Press ▲ or ▼ to select the length of paper loaded in the printer, and then press the OK button.
Specify the roll length as follows.
1.
Press the ◀ or ▶ button to move to the next field for input.
2.
Press the ▲ or ▼ button to enter the value.
3.
Repeat steps 1 and 2 to finish entering the value, and then press the OK button.

Removing the Roll from the Printer

Remove rolls from the printer as follows.
Important
• Once a roll has been advanced, do not pull the paper out by force. This will prevent further feeding, and the
printer will be unable to keep track of the amount of roll paper left.
If you accidentally pull out paper, follow these steps to remove the roll, and open the paper feed slot.
Note
• If you need to cut the roll, see "Specifying the Cutting Method for Rolls."
1.
6
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to select the
2.
Press the OK button.
The Paper Menu is displayed.
3.
Press ▲ or ▼ to select Eject Paper, and then press the OK button.
4.
Press ▲ or ▼ to select "Yes", and then press the OK button.
The roll is now rewound and ejected.
790
Removing the Roll from the Printer
Handling rolls >
Note
• If the Tab Selection screen is not displayed, press the Menu button.
Important
• If you have selected ManageRemainRoll > On in the Control Panel menu, a barcode is printed on
the leading edge of the roll.
Do not remove the roll before the barcode is printed. You will be unable to keep track of the amount
of roll paper left. (See "Keeping Track of the Amount of Roll Paper Left.")
→P.797
( Paper tab ) .
→P.794
iPF6300S
