Curves Dialog Box

This dialog box appears when you click the Curves button on the Color Settings Sheet. You can set Channel and other
settings.
• Channel
Select from among RGB, Red, Green, or Blue.
Note
• Gray is displayed for monochrome printing and this selection cannot be changed.
• Input
Enter an input value.
Note
• The allowed entry range is 0 to 255.
• You can change the numbers by clicking either ▲ button or ▼ button.
• Output
Enter an output value.
Note
• The allowed entry range is 0 to 255.
