DHCP client
To configure the access point by using CCA:
Connect the Ethernet port on the access point to a switch port on a
S 1
TEP
SBCS device and power on the Cisco AP541N.
Connect a PC with CCA installed to any access switch port on the
S 2
TEP
UC520 or SR520.
Create a new CCA site by entering a name and the IP address of
S 3
TEP
the UC520 or SR520.
Connect to the CCA site by using the appropriate login credentials.
S 4
TEP
Click Window > Topology View.
S 5
TEP
When you have connected to the CCA site and the devices have
been discovered, the Topology map includes the Cisco AP541N.
Any non-SBCS devices connected to the switch are not shown
N
OTE
in the Topology map.
Right-click the access point to display the options: Configuration
S 6
TEP
Utility, Properties, and Annotation.
Click Configuration Utility.
S 7
TEP
The Access Point Configuration Utility displays in a new window.
Cisco AP541N Dual-band Single-radio Access Point Quick Start Guide
Internet
