DMX Channel Modes, Assignments, and Values

Channel

9-Channel

Page 16 of 60
Function
1 Automatic Programs
2 LED Operation
Auto Program Speed
3
(when Channel 2 is
between 165—255)
LED Strobe
4 (when Channel 2 is
between 010–255)
Value Setting
000 ó 009
Blackout
010 ó 024
Auto program 1
025 ó 039
Auto program 2
040 ó 054
Auto program 3
055 ó 069
Auto program 4
070 ó 084
Auto program 5
085 ó 099
Auto program 6
100 ó 114
Auto program 7
115 ó 129
Sound-Active mode 1
130 ó 144
Sound-Active mode 2
145 ó 159
Sound-Active mode 3
160 ó 174
Sound-Active mode 4
175 ó 189
Sound-Active mode 5
190 ó 204
Sound-Active mode 6
205 ó 219
Sound-Active mode 7
220 ó 255
DMX mode
000 ó 009
Blackout
010 ó 014
Red
015 ó 019
Green
020 ó 024
Blue
025 ó 029
Amber
030 ó 034
White
035 ó 039
White + Red
040 ó 044
Red + Green
045 ó 049
Green + Blue
050 ó 054
Blue + Amber
055 ó 059
Amber + White
060 ó 064
White + Green
065 ó 069
Green + Amber
070 ó 074
Amber + Red
075 ó 079
Red + Blue
080 ó 084
Blue + White
085 ó 089
Red + Green + Blue
090 ó 094
Red + Green + Amber
095 ó 099
Red + Green + White
100 ó 104
Red + Amber + Blue
105 ó 109
Red + White + Blue
110 ó 114
Red + Amber + White
115 ó 119
Amber + Green + Blue
120 ó 124
Blue + Green + White
125 ó 129
Amber + Green + White
130 ó 134
Amber + White + Blue
135 ó 139
Red + Green + Blue + Amber
140 ó 144
Red + Green + Blue + White
145 ó 149
Green + Blue + Amber + White
150 ó 154
Red + Green + Amber + White
155 ó 159
Red + Blue + Amber + White
160 ó 164
Red + Green + Blue + Amber + White
165 ó 209
Automatic (single colors only)
210 ó 255
Automatic (two colors at a time)
000 ó 255 Automatic speed, slow to fast (colors only)
000 ó 004
No function
005 ó 254
Strobe (fast to slow)
255 Sound-Active strobe
