- Page 1 Zalman Tech Co., Ltd. User s Manual User s Manual http://www.zalman.co.kr E-mail:zalman@zalman.co.kr...
- Page 2 6) Zalman’s CPU Coolers offer very stable operation of a CPU in an OVERCLOCKED environment. * If you try OVERCLOCKING, please make sure that the fan is in Normal Mode. * Zalman Tech. Co., Ltd. is not responsible for any damage to systems or CPUs caused by CPU OVERCLOCKING.
- Page 3 1) For a noiseless computer, a Noise Prevention (NP) Power Supply, a NP HDD, a NP CD-ROM and a NP VGA CARD should be used together with this cooler. 2) Zalman affixes a Computer Noise Prevention System (CNPS) Mark to each of its parts and components used for noiseless computers.
- Page 4 1. First, check whether your CPU is a P4 CPU or an AMD CPU. Then, depending on the type of CPU, insert the bolts (A or B) into the appropriate holes in the cooler body (See Figure 1). Intel P4 CPU AMD CPU <...
- Page 5 (3) Check the locations of the holes around the socket and those of the bolts A mounted in the mounting holes, and then place the FHS horizontally on the center of the CPU. Mainboard (4) To make the FHS completely contact the CPU core (this is important to protect the CPU core from Case overheating), tighten each bolt A by one turn in the...
- Page 6 (2) Insert one of the provided bolts B into a tapered spring as shown in Figure 5, and insert the bolt B into an appropriate mounting hole of the cooler body (See Figure 1). Repeat until four bolts are installed in the cooler body. (Caution! The diameter of the spring increases from one end to the other end.
- Page 7 You can select the desired fan speed by turning the knob. Note 2) FAN MATE 1 has been specifically designed for the fan of this product. Zalman Tech. Co., Ltd. is not responsible for any damage to systems or CPUs caused by using it with other types of fans.
