Pioneer AVIC-F220 Operation Manual

Hide-away navigation system
Hide thumbs Also See for AVIC-F220:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
Operation Manual
HIDE-AWAY NAVIGATION SYSTEM
AVIC-F220
Be sure to read Important Information for the User
first!
Important Information for the User includes the
important information that you must understand before
using this navigation system.
Indications of this unit may be different from the actual
value.
Some of the features of this device do not take in to
consideration the type of vehicle it is installed into.
English

Advertisement

Table of Contents
loading

Related Manuals for Pioneer AVIC-F220

Summary of Contents for Pioneer AVIC-F220

  • Page 1 Operation Manual HIDE-AWAY NAVIGATION SYSTEM AVIC-F220 Be sure to read Important Information for the User first! Important Information for the User includes the important information that you must understand before using this navigation system. Indications of this unit may be different from the actual value.

  • Page 2: Table Of Contents

    Contents Thank you for buying this Pioneer product. Please read through these operating instructions so you will know how to operate your model properly. After you have finished reading the instructions, keep this man- ual in a safe place for future reference.
  • Page 3 Contents – Searching for POIs by preset – Editing the entry in the “Favourites” categories 28 list 39 – Searching for a POI directly from the – Editing your home 40 – Sorting the entry in the “Favourites” name of the facilities 29 –...
  • Page 4 Contents – Changing the virtual speed of the – When the rear view camera is vehicle 51 activated 61 – Setting the keyboard layout 51 Appendix Customising the map screen settings 52 Troubleshooting 62 – Displaying POI on the map 52 Messages and how to react to them 64 –...

  • Page 5: Introduction

    Chapter Introduction Manual overview [Address], [Settings]. ! Extra information, alternatives and other notes are presented in the following for- Before using this product, be sure to read Im- mat: portant Information for the User (a separate e.g.) manual) which contains warnings, cautions, p If the home location has not been stored and other important information that you yet, set the location first.
  • Page 6 Chapter Introduction ! If there appear to be problems with the op- eration of the system. ! When changing the combination of equip- ment. ! When adding/removing additional pro- ducts that connect to the navigation sys- tem. ! If your vehicle position is shown on the map with a significant positioning error.

  • Page 7: Before You Start

    Chapter Before you start 1 Power indicator Checking part names and functions 2 RESET button = For details, refer to Resetting the micro- This chapter gives information about the processor on page 5. names of the parts and the main features using the buttons.

  • Page 8: Attaching The Detachable Device

    Chapter Before you start Attaching the detachable device Charging the battery of the Slide the detachable device all the way into the base unit. detachable device Make sure that the detachable device is se- ! Charging cannot be done when the tempera- curely connected to the base unit terminal.

  • Page 9: Inserting And Ejecting An Sd Memory Card

    (approximately 10 seconds) after re- possible to recover the data. Pioneer accepts start before pressing the MODE button. no liability for damages, costs or expenses = For details of the operations, refer to Screen arising from data loss or corruption.

  • Page 10: Protecting Your Product From Theft

    Chapter Before you start Touch [OK]. Touch [Restart]. The navigation system restarts. The navigation system restarts. After a short pause, the navigation screen re- After a short pause, the navigation screen re- turns. turns. Check that the following screen is dis- played.

  • Page 11: On First-Time Startup

    Chapter Before you start On first-time startup Read the disclaimer carefully, checking its details, and then touch [OK] if you When you use the navigation system for the agree to the conditions. first time, select the language that you want to use.

  • Page 12: How To Use The Navigation Menu Screens

    Chapter How to use the navigation menu screens Screen switching overview Navigation screen Press the MODE button of the AV receiver. AV receiver screen (e.g. AVH-P3200BT) Engb...

  • Page 13: What You Can Do On Each Menu

    Chapter How to use the navigation menu screens What you can do on each Shortcut Menu menu Registering your favourite menu items in shortcuts allows you to quickly jump to the re- 1 Map screen gistered menu screen by a simple touch on on the “Top Menu”...

  • Page 14: Cancelling The Shortcut

    Chapter How to use the navigation menu screens Touch the tab on the right edge or scroll Operating menu screens (e.g. the bar to display the icon that you want “Navigation Menu” screen) to set to shortcut. Scroll bar 1 Screen title Touch and hold the icon that you want to add to shortcut.

  • Page 15: Operating The On-Screen Keyboard

    Chapter How to use the navigation menu screens If all of the characters cannot be displayed within the displayed area, touching the key to the right of the item allows you to see remain- ing characters. Operating the on-screen keyboard 1 Text box Displays the characters that are entered.

  • Page 16: How To Use The Map

    Chapter How to use the map Most of the information provided by your navigation system can be seen on the map. You need to be- come familiar with how information appears on the map. How to read the map screen This example shows an example of a 2D map screen.

  • Page 17: Audio Information Bar

    Chapter How to use the map 9 Map orientation indicator Audio information bar ! When “North up” is selected, is dis- While the navigation system screen is dis- played. played, changing the source or adjusting the ! When “Heading up” is selected, volume displays source information at the bot- displayed.

  • Page 18: Types Of The Road Stored In The Map Database

    “Heading up” and can only be used to plot a navigable route. “North up”. Pioneer Navigation will only display a navig- ! Heading up: able route on the map (only the arrival gui- The map display always shows the vehicle’s...

  • Page 19: Switching The Map Between 2D And 3D

    Chapter How to use the map p The map orientation is fixed at “North up” 3D map screen when the map scale is 50 kilometres (25 miles) or more. p The map orientation is fixed at “Heading up” when the 3D map screen is displayed. Display the map screen.

  • Page 20: Scrolling The Map To The Position You Want To See

    Chapter How to use the map Touch on the map screen. tion for this location being shown. (The infor- mation shown varies depending on the position.) p The scrolling increment depends on your dragging length. # Touch The map returns to the current position. Viewing information about The “Eco Graph”...
  • Page 21 Chapter How to use the map = For details, refer to Setting the “Favourites” icon display on page 54. = For details, refer to Displaying POI on the map on page 52. Engb...

  • Page 22: Eco-Driving Function

    Chapter Eco-driving function Reading the screen This navigation system is equipped with an Eco-driving function that can be used to esti- mate whether you are driving in an environ- mentally friendly way. This chapter describes this function. ! The fuel mileage calculated is based on a theoretical value determined from vehicle speed and position information from the navigation system.

  • Page 23: Displaying Eco Drive Level Guidance

    Chapter Eco-driving function p This is not displayed when “Eco Score” 1 Tree icon is set to “Off” or when no route is set. As the level increases, a tree icon changes 4 Eco-gauge from a young tree to a big tree. p This is not displayed when “Eco Drive The green gauge indicates the current score, Level”...
  • Page 24 Chapter Eco-driving function Touch [Settings]. No message appears and no sound beeps when the vehicle experiences a sudden start. Clear Record Fuel consumption data are cleared. Touch [OK]. The settings are completed. The “Eco Settings” screen appears. Touch the desired option. Eco Score ! On (default): Displays “Eco Score”.

  • Page 25: Searching For And Selecting A Location

    Chapter Searching for and selecting a location The basic flow of creating CAUTION your route For safety reasons, these route-setting functions are not available while your vehicle is in motion. 1 Park your vehicle in a safe place and apply To enable these functions, you must stop in a the handbrake.

  • Page 26: Searching For A Location By Address

    Chapter Searching for and selecting a location p Once the country has been selected, you Searching for a location by only have to change countries when the lo- address cation is outside of the country you se- The most frequently used function is “Ad- lected.

  • Page 27: Searching For A Name By Entering Multiple Keywords

    Chapter Searching for and selecting a location Touch the street you want. Entering two keywords The “House#” screen appears. The names including the following words below are displayed as a result: 10 Enter the house number and then ! First keyword you entered. touch [OK].

  • Page 28: Setting Up A Route To Your Home

    Chapter Searching for and selecting a location Touch the key next to “Country” to dis- 11 Touch the desired house number range. play the country list. The searched location appears on the map p Once the country has been selected, you screen.

  • Page 29: Searching For A Poi Directly From The Name Of The Facilities

    Chapter Searching for and selecting a location Touch [POI]. If the location that you want to search for is in The “POI Search” screen appears. another country, this changes the country set- ting. Touch the desired category. p Once the country has been selected, you only have to change countries when the lo- Preset categories cation that you want to search for is outside...

  • Page 30: Searching For A Nearby Poi

    Chapter Searching for and selecting a location Searching for a nearby POI Touch the POI you want. The searched location appears on the map You can search for POIs in your surroundings. screen. = For the subsequent operations, refer to Set- Touch [Home] on the map screen and ting a route to your destination on page 34.

  • Page 31: Selecting Destination From "Favourites

    Chapter Searching for and selecting a location Enter the city name and then touch Touch [Home] on the map screen and [OK]. then touch [Navigation]. = For details of the operations, refer to Screen switching overview on page 12. Touch [Favourites]. The “Select Favourite”...

  • Page 32: Selecting A Location You Searched For Recently

    Chapter Searching for and selecting a location Touch [Home] on the map screen and Touch the entry you want. then touch [Navigation]. = For details of the operations, refer to Screen switching overview on page 12. Touch [FEEDS]. The “Select List” screen appears. Touch the item you want.

  • Page 33: Searching For A Location By Scrolling The Map

    Chapter Searching for and selecting a location Enter the longitude, and then touch Touch and drag the screen to scroll the [OK]. map to the position you want. Touch = For details of the operations, refer to Screen switching overview on page 12. The screen returns to the previous screen.

  • Page 34: After The Location Is Decided

    Chapter After the location is decided 1 Distance to the destination Setting a route to your 2 Travel time to your destination destination 3 Estimated fuel cost to your destination = For details, refer to Inputting the fuel Search for a location. = For details, refer to Chapter 6.

  • Page 35: Checking And Modifying The Current

    Chapter Checking and modifying the current route Displaying the “Route info” Modifying the route screen calculation conditions You can modify the conditions for route calcu- Touch [Home] on the map screen and lation and recalculate the current route. then touch [Navigation]. = For details of the operations, refer to Screen Display the “Route info”...

  • Page 36: Checking The Current Itinerary

    Chapter Checking and modifying the current route p The system may calculate a route that in- Avoid Toll Road This setting controls whether toll roads (in- cludes streets or bridges that are subject to cluding toll areas) should be taken into ac- traffic restrictions during a certain time even if “On”...

  • Page 37: Deleting A Waypoint

    Chapter Checking and modifying the current route Display the “Route info” screen. Touch [OK] on the “Waypoints List” = For details, refer to Displaying the “Route screen. info” screen on page 35. Touch [Waypoints]. The “Waypoints List” screen appears. Touch [Add]. The route is recalculated, and the Route con- firmation screen appears.

  • Page 38: Cancelling The Route Guidance

    Chapter Checking and modifying the current route Display the “Route info” screen. Touch [Home] on the map screen and = For details, refer to Displaying the “Route then touch [Navigation]. = For details of the operations, refer to Screen info” screen on page 35. switching overview on page 12.

  • Page 39: Registering And Editing Locations

    Chapter Registering and editing locations Storing a location in Registering a location by scroll “Favourites” mode Storing your favourite locations as “Favour- Touch and drag the screen to scroll the map to the position that you want to regis- ites” provides you with the opportunity to save ter.

  • Page 40: Editing Your Home

    Chapter Registering and editing locations Touch the item that you want to Touch next to the home location. change the setting. The “Edit Favourite” screen appears. p Up to 17 characters can be input for the Touch the item that you want to name.

  • Page 41: Deleting The Entry From The "Favourites" List

    Chapter Registering and editing locations p Current order is indicated on the upper Touch [Delete]. right of the screen. Sorts the items in the list in order by dis- tance from the vehicle position. Sorts the items in the list alphabetically. Sorts the items in the list in order of the re- cently used items.

  • Page 42: Editing Your Home

    Chapter Registering and editing locations Touch [Home]. Touch the item that you want to change the setting. The “Select Search Method” screen appears. # Touch [Phone #]. Search for a location. You can edit the registered phone number. After searching for a point, display it on a # Touch [Modify Location].

  • Page 43: Exporting And Importing "Favourites" Items

    Chapter Registering and editing locations Select the location you want to delete. Insert an SD memory card into the SD card slot. = For details of the operation, refer to Insert- ing an SD memory card on page 9. Touch [Home] on the map screen and then touch [Navigation].
  • Page 44 Chapter Registering and editing locations p The utility programme navgate FEEDS is available from our website. For details, refer to the information on our website. Store the item into the SD memory card by using the navgate FEEDS. Insert an SD memory card into the SD card slot.

  • Page 45: Fuel Cost Management

    Chapter Fuel cost management Using the “Fuel details” ! Fuel Unit: Set the fuel unit. function ! Currency: Inputting the fuel consumption Set the unit of currency. When all the items are entered, inputting the information for calculating the fuel consumption information is complete. fuel cost You can estimate the fuel cost to your destina- Calculating the fuel consumption...

  • Page 46: Exporting The Data Of Fuel Cost Information

    Chapter Fuel cost management Enter the fuel consumption informa- Insert an SD memory card into the SD tion. card slot. = For details of the operation, refer to Insert- ing an SD memory card on page 9. Touch [Home] on the map screen and then touch [Navigation].
  • Page 47 Chapter Fuel cost management Touch [Export] next to “Fuel details”. Data export starts. After the data is exported, the completion mes- sage appears. Touch [OK]. The “Navigation Menu” screen appears. Engb...

  • Page 48: Using Applications

    Chapter Using Applications Launching the application This product enables you to use applications downloaded via the utility programme navgate You can launch applications downloaded to FEEDS, providing for navigation functions a an SD memory card via the utility programme wide variety of entertainment functions. navgate FEEDS.

  • Page 49: Customising Preferences

    Chapter Customising preferences Displaying the “Settings Controls the master volume of both the navi- gation guidance and beep. Menu” screen When set to , guidance is output. When set Touch [Home] on the map screen. , no guidance is output. The “Top Menu”...

  • Page 50: Setting The Time Difference

    Chapter Customising preferences The time difference can be set from –4.0 to Touch [Voice Language]. The “Voice Language Selection” screen ap- +9.0 hours. pears. Touch [Summer Time]. Touch the desired language. If necessary, set to summer time. After the language is selected, the previous Summer time setting is off by default.

  • Page 51: Changing The Virtual Speed Of The Vehicle

    Chapter Customising preferences Changing the virtual speed of Touch [Region]. The “Regional Settings” screen appears. the vehicle When calculating the expected time of arrival Touch [Keyboard]. and the travel time to the destination, set the Each time you touch the key changes that set- average speed for the motorway or ordinary ting.

  • Page 52: Customising The Map Screen Settings

    Chapter Customising preferences Touch [Display] to change the setting to “On”. Customising the map screen settings p If you do not want to display the POI icon The general settings related with a map screen on the map, touch [Display] to turn it can be customised.

  • Page 53: Switching The Map Between 2D And 3D

    Chapter Customising preferences Touch [Map]. A red tick mark appears next to the selected category. To cancel the selection, touch the The map setting screen appears. entry again. Touch [View Mode]. If there are more detailed categories within the Each time you touch the key changes that set- subcategory, is active.

  • Page 54: Changing The Road Colour

    Chapter Customising preferences Touch [Day/Night Display]. Touch [Map]. Each time you touch the key changes that set- The map setting screen appears. ting. Touch [Close Up View]. ! Automatic (default): Each time you touch the key changes that set- You can change the colours of a map be- ting.

  • Page 55: Displaying The Fuel Consumption Information

    Chapter Customising preferences Display the “Settings Menu” screen. Setting the speed limit display = For details of the operations, refer to Dis- Selects whether to display or hide the speed playing the “Settings Menu” screen on limit of the current road. page 49.

  • Page 56: Registering And Editing Your Home

    Chapter Customising preferences Registering and editing your home When registering your home location, touch [Set Home]. = For details, refer to Registering and editing your home on page 41. 1 Status Correcting the current location Indicates the connection status of the GPS aerial, the reception sensitivity and from Touch the screen to adjust the current position how many satellites the signal is received.

  • Page 57: Recording Your Travel History

    Chapter Customising preferences Touch [Demo Mode]. You cannot export your track log to the SD memory card. p While the setting is “On”, the navigation system continues to store the track logs in the inserted SD memory card. Touch [Type]. Each time you touch the key changes that set- ting.

  • Page 58: Other Functions

    Chapter Other functions Replicating the settings each method. For the contents that are cleared in each method, see the list presented later. You can import settings you have made on the = For detailed information about the items utility programme navgate FEEDS which is which would be erased, refer to Setting available separately to the navigation system.

  • Page 59: Returning The Navigation System To The Initial State

    Chapter Other functions Returning the navigation system to the initial state You can return settings or recorded content to the default or factory settings. = For detailed information about the items which would be erased, refer to Setting items to be deleted on the next page. Display the “Settings Menu”...

  • Page 60: Setting Items To Be Deleted

    Chapter Other functions Setting items to be deleted The items to be deleted vary depending on the reset method. The items listed in the following table return to the default or factory settings. Any items not listed below will be retained. —...

  • Page 61: Interruption Of The Av Receiver Screen

    Chapter Other functions Interruption of the AV receiver screen When a function with a higher priority reaches the connected AV receiver, the navigation screen automatically switches to the AV recei- ver screen. The screen switches in the following cases. When a phone call is received When a mobile phone is connected to the AV receiver via Bluetooth wireless technology and an incoming call comes in, the display...

  • Page 62: Appendix

    If you have problems operating your navigation system, refer to this section. The most common problems are listed below, along with likely causes and solutions. If a solution to your problem cannot be found here, contact your dealer or the nearest authorised Pioneer service facility. Problems with the navigation screen...
  • Page 63 Appendix Appendix Symptom Cause Action (Reference) You cannot position your vehicle If a vehicle phone or mobile phone The quality of signals from the GPS satellites on the map without a significant is used near the GPS aerial, GPS re- is poor, causing reduced positioning accu- ception may be lost temporarily.

  • Page 64: Messages And How To React To Them

    When What to do (Reference) ! Change the destination. Route calculation was not Route calculation has failed be- ! Consult the Pioneer Local dealer if this mes- possible. cause of a malfunction in map data, software, or hardware. sage persists.

  • Page 65: Positioning Technology

    Appendix Appendix Positioning technology Map matching As mentioned, the positioning systems used Positioning by GPS by this navigation system are susceptible to The Global Positioning System (GPS) uses a certain errors. Their calculations may, on occa- network of satellites orbiting the Earth. Each sion, place you in a location on the map where of the satellites, which orbit at a height of no road exists.

  • Page 66: When Positioning By Gps Is Impossible

    Appendix Appendix When positioning by GPS is your vehicle may differ from the position dis- played on the map screen. impossible ! If you make a shallow turn. ! GPS positioning is disabled if signals can- not be received from more than two GPS satellites.
  • Page 67 Appendix Appendix ! If the road has a series of hairpin bends. ! If you enter or exit a multi-storey car park or similar structure using a spiral ramp. ! If there is a loop or similar road configura- ! If your vehicle is turned on a turntable or si- tion.

  • Page 68: Route Setting Information

    Appendix Appendix ! During voice guidance, turns and intersec- ! When you drive around a roundabout. tions from the motorway are announced. However, if you pass intersections, turns, and other guidance points in rapid succes- sion, some may delay or not be announced. ! It is possible that guidance may direct you off a motorway and then back on again.

  • Page 69: Common Notes About The Sd Memory Card

    Appendix Appendix Common notes about the SD memory card ! Do not leave the SD memory card in any lo- cation with high temperatures. ! Operations may vary depending on the kind of an SD memory card. ! Depending on the kind of the SD memory card you use, this navigation system may not recognise the storage device or files may not be played back properly.

  • Page 70: Display Information

    Appendix Appendix Display information “Navigation Menu” screen “Settings Menu” screen Page Page Address 26, 27 Sound Go Home Region UI Language, Voice Language Time Petrol km / mile Parking Speed Hotel Keyboard Spell Name Near Me Overlay POI Near Dest. View Mode Around City Show Manoeuvre...

  • Page 71: Settings Menu" Screen

    Appendix Appendix “Settings Menu” screen Page Connection Demo Mode Drive Log Safe Mode F. Reset Engb...

  • Page 72: Glossary

    Appendix Appendix Glossary Set route The route marked out by the system to your Current location destination. It is highlighted in bright colour The present location of your vehicle; your cur- on the map. rent location is shown on the map by a red tri- angle mark.

  • Page 73: Specifications

    Appendix Appendix Specifications General Rated power source ....14.4 V DC (allowable voltage range: 10.8 V to 15.1 V DC) Earthing system ....... Negative type Maximum current consumption ............. 1.0 A Dimensions (W × H × D): ..........85 mm × 28 mm × 147 mm Detachable device ..
  • Page 74 Engb...
  • Page 75 Engb...
