Samsung SHR-4080P User Manual

Real time dvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Real Time DVR
SHR-4080P User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Samsung SHR-4080P

Summary of Contents for Samsung SHR-4080P

  • Page 1 Real Time DVR SHR-4080P User’s Manual...

  • Page 2: Safety Regulations

    SHR-4080P USER’S MANUAL Safety Regulations Please be sure to keep the following in mind for the right use of the product to pre- vent proprietary risk or damage. Do not use multiple plugs at once. This may cause abnormal heat generation or fire Do not put a vase, flowerpot, cup, cosmetics, medicine, or vessel with water around you.

  • Page 3: Before We Start

    You may download open source codes from the following website. (See CCTV Part of http://www.samsung.com.) WARNING [Battery] As wrong exchange of the battery in SHR-4080P may cause explosion, you shall use the certified battery for SHR-4080P. The battery specification is as follows. -Normal Voltage: 3V -Normal Capacity: 220mAh -Continuous Standard Load: 0.2mA...

  • Page 4: Table Of Contents

    Contents Safety Regulations Before we start Code Certification Chapter 1 Overview 1. Introduction 2. Features 3. Part Names and Functions Chapter 2 Installation 1. Installation Environment Setup 2. Checking Product and Accessories 3. Additional HDD Installation Chapter 3 Connecting with Other Equipment 1.
  • Page 5 Chapter 5 Menu Setup Before Use 1. System 5-12 2. Camera 5-16 3. Monitoring 5-18 4. Record Mode 5-19 5. Event Record 5-24 6. Record Schedule 5-26 7. Backup 5-27 8. Network Chapter 6 PTZ Device Control 1. PTZ Control MODE 2.
  • Page 6 7. Monitoring Mode 10-25 8. Search Mode 10-32 9. Setup Mode Appendix 11-1 1. Product Specification 11-4 2. HDD Specifications 11-5 3. Outline Drawing 11-6 4. Factory Default 11-8 5. SHR-4080P Smart Viewer Play Frame Specification 11-9 6. Troubleshooting (FAQ)

  • Page 7: Chapter 1 Overview

    Chapter 1 Overview...

  • Page 8: Introduction

    SHR-4080P USER’S MANUAL Introduction The realTime Digital Video Recorder(DVR) compresses the camera input data from 8 channels into a MPEG4 video file and the voice input data into a G.726 audio file respectively to record them in the Hard Disk or retrieve them from the Hard Disk simultaneously.

  • Page 9: Features

    Features 8 CH Composite Input Connectors PAL Video Source Compatible Able to record the normal sized (720 x 288) video image at the speed of 200IPS(image per second) 8 CH Loop Through Video Connectors Hard Disk Overwrite Mode Large Quantity Hard Disk Backup by IEEE1394 Able to record, play, and transmit both audio and video files to Windows Network Viewer(Smart Viewer) simultaneously Recording and Play of Audio 8CH...

  • Page 10: Part Names And Functions

    SHR-4080P USER’S MANUAL Part Names and Functions Name Function Power LED Displays power on/off condition. Displays both network connection and data transmis- Network LED sion conditions. Back Up LED Displays Back Up Mode. HDD Access Indicates Normal Access to HDD.

  • Page 11: Control Button

    Name Function Video/Audio set in the system records signals real- PANIC Button time. The recording resolution is Level 8 with a nor- mal size. PANIC REC LOCK Locks the REC key motion. Button REC LOCK KEY Sets up Digital Zoom(x2). ZOOM Button ZOOM Performs the TELE, WIDE, PRESET, and VIEW func-...
  • Page 12 SHR-4080P USER’S MANUAL Caution Caution Do not play DVR on the carpet or other soft material to prevent clogging of the air ventilator. To play DVR on the cabinet or rack, be sure to check the ventilation condition. Name Function...

  • Page 13: Chapter 2 Installation

    Chapter 2 Installation...

  • Page 14: Installation Environment Setup

    SHR-4080P USER’S MANUAL Installation Environment Setup Do not play DVR on the carpet or other soft material to prevent clogging of the air ventilator. To play DVR on the cabinet or rack, be sure to check the ventilation condi- tion.
  • Page 15 Checking Product & Accessory Upon delivery of a product, you shall unwrap the product and put it on the even floor or where you want to use it. Then you shall check if the following items are in it. Main Body User’s Manual One Power Cord Two Brackets...

  • Page 16: Hdd Addition

    SHR-4080P USER’S MANUAL HDD Addition You may add up to 3 more HDDs to the product. However, since the product contains has many parts which may incur electric shock, accident, or product breakdown and improper installation or setup may disturb HDD recognition or normal product operation, you shall consult with an expert of the agency where you bought the product.
  • Page 17 2.Detach the cover from the product. (Pull out the cover slightly and lift from the back side to detach.) 3. A bracket is fixed to each side of HDD. Please loosen the screw of the bracket to which you want to fix HDD. BRACKET-HDD...
  • Page 18 SHR-4080P USER’S MANUAL 4.Pull BRACKET-HDD to the product center to detach the fixed part at the bottom to detach BRACKET-HDD from the product. 5.Tighten 4 SCREW-SPECIALs(BWH,6-32UNC,L10.5), supplied as an accessory to fix HDD to BRACKET-HDD. (Screw tighten force shall be strong enough to resist...
  • Page 19 6. Restore HDD installed BRACKET-HDD. (Assembly shall be done in the reverse procedure of disassembly as follows. Align the 5 fix- ing points at the bottom with the BRACKET-HDD fixing holes respectively and push BRACK- ET-HDD out of the product to align the screw fixing holes. Then, tighten the screws firmly.) 7.
  • Page 20 SHR-4080P USER’S MANUAL 8. Check the connector, wiring, and cable fixing condition inside the product and close the cover. 9. Tighten cover-fixing screws. (5 points on both sides and 1 point in the back side) You can apply 2 HDDs to each BRACKET-HDD as shown in the figure.
  • Page 21 Attention Attention ! Regarding the sub fan, you need additional brackets and sub fans as follows. The sub fan is shaped like this when viewed from the front and back. Please pay attention to the fan direction to let wind go through the fan. @ Fix the fan as follows.
  • Page 22 SHR-4080P USER’S MANUAL # Please install the fan to be seen from the front view of the set.
  • Page 23 Fixing the fan to the left. 2-10...

  • Page 24: Chapter 3 Connecting With Other Equipment

    Chapter 3 Connecting with Other Equipment...

  • Page 25: Connecting Video, Audio, & Monitor

    SHR-4080P USER’S MANUAL Connecting Video, Audio, and Monitor...

  • Page 26: Connecting Scsi Device

    Connecting SCSI Device The SCSI interface of SHR-4080P is used for backup or extended storage. Connect an armored SCSI hard disk drive cable to the high-density 50-pin female Ultra SCSI port. SCSI device ID adopts 0 through 5 with 6 connections at most.

  • Page 27: Connecting Network

    SHR-4080P USER’S MANUAL Connecting Network Connecting to Internet through Ethernet(10/100BaseT) Connecting Internet through ADSL...

  • Page 28: Connecting Ieee1394 Device

    - Wait until the HOT PLUG connected hard disk is stabilized enough (approx. 2 sec- onds per each hard disk) and click CONNECT in SHR-4080P MENU before use. - Be sure to click DISCONNECT in SHR-4080P MENU to delete IEEE1394 Device safely.
  • Page 29 SHR-4080P USER’S MANUAL Note Note Refer to Appendix 2 to see which HDD specifications are supplied.

  • Page 30: Connecting Alarm Input/Output

    Connecting Alarm Input/Output The Alarm IN/OUT port in the back of SHR-4080P is composed of the following elements. ALARM IN/OUT Connection Name Function - ALARM IN1 - ALARM IN2 - ALARM IN3 - ALARM IN4 ALARM Input Port - ALARM IN5...
  • Page 31 SHR-4080P USER’S MANUAL ALARM IN/OUT Connection...

  • Page 32: Connecting Rs-485 Device

    Tx(–) Rx(+) Tx(+) Baud Rate covers 600, 1200, 2400, 4800, 9600, 19200, and 38400. Caution Caution Check if RS-485 Device is compatible with SHR-4080P first. Then pay attention to the polarity of RS-485 which has two poles, + and -.

  • Page 33: Chapter 4 Live

    Chapter 4 Live...

  • Page 34: System Motion

    HDD. If the Live screen does not appear at all or the button in front of SHR-4080P repeats blinking, please check the connection across the product body. If you find any error, please ask the shop where you bought the product.

  • Page 35: Livescreen Mode

    Livescreen Mode Definition of Live Screen Icon The Live screen icons of SHR-4080P display the current setup and function status of each screen. V.Loss CAM_01 CAM_01 : Recording Icon Each icon represents Normal / Panic / Event(Alarm+Motion) / Schedule Recording.
  • Page 36 If there is no more video data input with Video On, [V.Loss] appears in the channel. If you set Video On/Off to Off, [V.Off] will appear. Definition of Live Screen Mode SHR-4080P receives 8 live images and displays them in the following 8 modes. CAM_02 CAM_01...

  • Page 37: Selecting Live Screen Mode

    Selecting Live Screen Mode Each mode may be selected by [MODE Button] and [CH1 ~ CH8 Button]. The follow- ing figure shows Live Mode of SHR-4080P after converted. The default is 9 Split Screen Mode. The default of 4 Split Screen Mode is [4 Split 1] Mode to display [CH1 ~ CH4] or [4 Split 2] Mode to display [CH5 ~ CH8].

  • Page 38: Live Channel Selection And Audio On/Off Setup

    SHR-4080P USER’S MANUAL Live Channel Selection and Audio On/Off Setup In other split modes than Full Screen Mode, 9 Split Mode, and Auto Sequence Mode, you may choose a channel to be displayed in each split area on your own. Meanwhile, the channel whose MENU is set to Audio On can set up Audio On/Off in all Live Modes.

  • Page 39: Zoom Function

    Freeze and Zoom Freeze Function Freeze pauses the video image in Live Screen, only available in Live Mode. You can set up Freeze On/Off with [FREEZE Button] and [FREEZE LED] is turned on or off depend- ing on the Freeze On/Off setup condition. Zoom Function Zoom enlarges the selected area twice, only available in Full Screen Mode.

  • Page 40: Event Monitoring

    SHR-4080P USER’S MANUAL Event Monitoring Event Monitoring displays the channel synchronized with a specific event (Sensor/Motion/Video Loss) on the screen when it occurs. Event Monitoring On/Off and Event Duration setup is available in [Menu] [Monitoring]. If you set the Event Monitoring interval to 5 seconds and an event occurs at CH2 in the beginning as in the following figure, the system will display CH2 in the whole screen for 5 second.

  • Page 41: Spot-Out Monitoring

    Spot-out Monitoring Spot-out Monitoring has nothing to do with Live Screen Output, monitoring the full screen of a certain channel. If you select Monitoring in the MENU screen, you can make a channel among CH1 to CH8 spot out or you can output channels one by one at an interval as Auto Sequence Mode of Live Mode.

  • Page 42: Chapter 5 Menu Setup

    Chapter 5 Menu Setup...

  • Page 43: Before Use

    SHR-4080P USER’S MANUAL Before Use Selection ,❷,➛, or ❿ key in the The yellow cursor shows the current window. Use the front to move the cursor on your desirous menu. If you press the “Enter” key with the cursor clicking on your desirable menu, the system will enter the new mode.

  • Page 44: System

    System System Menu has the following items in detail. Date/Time/Language Setup Date Press the “Enter” key and the ➛ or ❿ key to move to Y/M/D. Use the or ❷ key to change the date. Press the “Enter” key to come out of the mode. Time Press the “Enter”...
  • Page 45 SHR-4080P USER’S MANUAL Note Note [Date/Time Change] Pressing “OK” after you change date and time, you will be asked by a pop-up win- dow if you really confirm the change. Here, press “Yes” to change the time. Since Date/Time does not change in backup/recording process, be sure to stop the backup/recording process before you change Date/Time.
  • Page 46 The Default Password is 4321. New Password This is used to change the system password inside SHR-4080P. You are allowed to create a password up to 8 digits. Press the “Enter” key and then a channel but- ton from 0 ~ 9 on your left to finish input. If you press the “Enter” key after change, the system will automatically turn to “New Password Confirm”.

  • Page 47: Load Factory Default

    SHR-4080P USER’S MANUAL Load Factory Default This initializes all the menu preset values. The recorded data will not be deleted. Press “OK” in the confirmation window to start initializing. System Log System Log is used by a controller to check crucial records.

  • Page 48: Event Log

    System Log List System Start System Start Panic Record Start Panic Record Start Login(Admin) Viewer Login (Admin) Panic Record End Panic Record End Logout(Admin) Viewer Logout (Admin) Time Change Date/Time Change Login(User) Viewer Login (User) Load Factory Default System Initialization Logout(User) Viewer Logout (User) System Upgrade...
  • Page 49 SHR-4080P USER’S MANUAL System Information and Setup Software Version : Displays the current version. Setup is not available. Broadcast Format : Displays the current Format(NTSC/PAL) . Setup is not avail- able. Mac Address : 6 Byte hardware address. Setup is not available.

  • Page 50: Hdd Setup

    Caution Caution [HDD Erase] Data will not be deleted in backup or recording process. Please be sure to suspend backup or recording before you delete any data. HDD Setup Internal HDD Information Displays the number, quantity, and status of ATA, IEEE1394, and SCSI. Setup is not available.
  • Page 51 Caution Caution [ IEEE-1394 Hot-Plug Connect/Disconnect Function ] You may connect or disconnect SCSI while power is supplied to the SHR-4080P main body. Only IEEE1394 supports the Hot-Plug function. [Backup HDD] SCSI and IEEE1394 cannot be used as Backup HDD simultaneously.
  • Page 52 Sets up either Half Duplex or Full Duplex. Note Note If you select Remote Control Device, you may not PTZ Camera with SHR-4080P. The PTZ button in front of SHR-4080P becomes inactivated. Press the PTZ button and the PTZ ban icon( ) will appear.

  • Page 53: System Shutdown

    SHR-4080P USER’S MANUAL System Shutdown Remote Control Device Terminates the work in action safely and turns the power off. Press “OK” in the confirmation window and plug out when you see “Safe to Power Off”. Caution Caution [System Shutdown] Power-off without terminating the system in the System Shutdown menu may incur...

  • Page 54: Camera

    Camera The detailed Camera Menu items are as follows. Camera Configuration Video On : Camera images from a selected channel appear. Off : Camera images from a selected channel disappear. In this case, you are not allowed to set Audio/Title/Auto Seq. Audio On : You can hear voices from a selected channel.
  • Page 55 SHR-4080P USER’S MANUAL Title You can name the camera of a selected channel. If you press the Enter key, the Virtual keyboard will come out. ❿ Virtual Keyboard If you move the cursor, you can type text by text. Up to 15 texts can be typed.

  • Page 56: Ptz Device

    PTZ Camera ID from 0 to 255 Protocol A protocol supported by PTZ Camera The following protocols are now being supported. Samsung/ Vicon/ Panasonic/ AD/ Philips/ Erna/ PelcoD/ PelcoP/Vcltp/ Diamond/ Kalatel Baudrate Baudrate supported by PTZ Camera, 600/ 1200/ 2400/ 4800/ 9600/ 19200/ 38400 Parity Defines one among None, Even, and Odd.

  • Page 57: Screen Setup

    SHR-4080P USER’S MANUAL Screen Setup This is a window to adjust Brightness/Contrast/Color for the camera image of each channel. Put the cursor on the channel that you want to adjust and set up Brightness/Contrast/Color. Once selected, the channel appear in the PIP area on or ❷...

  • Page 58: Monitoring

    Monitoring Event Monitoring You are able to set to Off/3sec/5sec/10sec/20sec/30sec/Continuous. Off : Event Monitoring does not operate to turn to the screen where an event occurs. 3sec/ 5sec/ 10sec/ 20sec/ 30sec : For the period, the screen is seen before the next screen appears.
  • Page 59 SHR-4080P USER’S MANUAL Monitor Out You are not allowed to connect VGA MONITOR and Composite MONITOR simul- taneously. Consequently, the user are obliged to choose either Composite Output or VGA Output. Composite : Output comes out of the “Composite Out” port.

  • Page 60: Record Mode

    Record Mode If you press the front “REC” key, the mode to be recorded will be determined. For Event Recording Mode value setup, refer to 5-18. Event Record Mode Setup Menu. Mode On : Pressing the REC key starts recording the current channel. Off : Even pressing the REC key does not affect current channel recording.

  • Page 61: Event Mode

    SHR-4080P USER’S MANUAL Event Mode The detailed items of Event Record Menu are as follows. Evnet Record Mode Determines a mode to be recorded when an event occurs. V. Size (Video Size ) Determines the size of a screen to be recorded.
  • Page 62 Quality Recording resolution will be determined. Choose one from Level 1(Low) to Level 8 (High). Level 8 supplies the best resolution Rate Determines Frame Rate to be recorded. Frame Rate means the number of screen recorded every second. Set to 25ips, the system records too many screens per second and play continues intermittently since recording is more detailed.
  • Page 63 SHR-4080P USER’S MANUAL Alarm Sensor State Off : Sensor does not operate. N.O(Normal Open) Sensor : Sensor remains open all the time and if closed, an alarm will be issued. (A Contact) N.C(Normal Close) Sensor : Sensor remains closed all the time and if open, an alarm will be issued.
  • Page 64 Motion Detecting M.D State Off : Motion Detection does not operate On : Motion Detection starts operation. Area Select the Motion Detection zone. It is composed of 45x48 sized Block. You are forbidden to determine 4 block rows(Up/Down/Left/Right) to allow them to be displayed in all monitors.

  • Page 65: Video Loss

    SHR-4080P USER’S MANUAL Sensitivity Determines Motion sensing sensitivity. Sensitivity grade consists of Low Medium Very High in the ascending order. Alarm-Out Selects Alarm-Out scope when Motion occurs. At this moment, this supports 5 Alarm Outs. Choose an alarm-out that you want to synchronize with the current motion channel.

  • Page 66: Event Record

    Record Schedule You may select a time when recording starts automatically. Selection by the day or by the time is available. The default is set to “None”. Pressing “CH > “ copies the value of Channel 1 to all the channels. The horizontal axis numbered from 0 to 23 represents the time value.
  • Page 67 SHR-4080P USER’S MANUAL Both(Continuous, Event) On occurrence of Event, Continuous Recording is replaced with Event Recording Mode. Holiday If you press “Holiday”, a calendar pops up and you are able to designate holidays. Move to a date and press “Enter” to complete designation.

  • Page 68: Backup

    Backup Sel Tap is not checked in the beginning. Once checked, Sel Tap activates “Start” and free space is displayed in the Free Space zone. Set the date and time that you want to back up and press “Start” to start Backup. When you change Start Date/Time or End Date/Time, free space keeps updated in the Free Space zone.

  • Page 69: Network

    IP. If you continue to fail in DHCP or ADSL connection, keep the main body of SHR-4080P off for a while and turn it on for retry. The Port number indicates the 4 ports by which the main body attempts network connection. The default is 554, 555, 556, 557.
  • Page 70 In addition, if you want to use the DHCP function backed by IP Router to allocate Dynamic IP to the main body of SHR-4080P, you shall designate a port for the IP which SHR-4080P has been allocated by the IP Router setup menu.
  • Page 71 Chapter 6 PTZ Camera Control...

  • Page 72: Ptz Camera Control Mode

    Use direction keys to move this bar until you reach the channel with the PTZ symbol and press the PTZ button in front of SHR-4080P to enter PTZ Camera Control Mode. If you succeed in entering PTZ Camera Control Mode, the PTZ symbol on the monitor screen will turn yellow from white while the PTZ button in front of SHR- 4080P will turn blue.
  • Page 73 Note If you select Remote Control Device, you may not control PTZ Camera with SHR- 4080P. It’s because the PTZ button in front of SHR-4080P remains inactivated. Press the PTZ button and the PTZ ban icon( ) will appear. It’s because the RS-...

  • Page 74: Basic Operation Of Pan, Tilt, & Zoom

    Press the LEFT or RIGHT button in front SHR-4080P in PTZ Camera Control Mode to control PTZ Camera horizontally. TELE WIDE VIEW PRESET TILT Press the UP or DOWN button in front SHR-4080P in PTZ Camera Control Mode to control PTZ Camera vertically. TELE WIDE VIEW PRESET ZOOM Press the TELE/WIDE button in front SHR-4080P in PTZ Camera Control Mode to zoom in or out PTZ Camera.

  • Page 75: Preset Setup

    Memorizes up to 20 PTZ Camera positions at the moment. Note Note For AD Protocol PTZ Camera, this memorizes only 7 positions. Press the SET button in front of SHR-4080P in Single Screen PTZ Camera Control Mode to set up Preset. TELE WIDE...
  • Page 76 SHR-4080P USER’S MANUAL Move the cursor right and press ENTER in PTZ Control Mode first. Then, press Enter to run P/T/Z/ Motion Mode in the PIP screen and press Enter again to cancel P/T/Z/ Motion Mode. Press Enter at the Position Name position to see Virtual Keyboard. Type Position Name and press OK to save Position and Position Name.

  • Page 77: Camera Menu Setup

    Press the SET button in front of SHR-4080P in Single Screen PTZ Camera Control Mode to select Camera Menu. TELE WIDE VIEW PRESET Press the SET button in front of SHR-4080P to return to the upper menu from SET button Camera Menu.

  • Page 78: Preset View

    SHR-4080P USER’S MANUAL Preset View Preset setup allows your movement to a certain saved position of PTZ Camera. Press the VIEW button in front of SHR-4080P in Single Screen PTZ Camera Control Mode to select Preset. TELE WIDE VIEW PRESET...

  • Page 79: Other View

    Other View Press the VIEW button in front of SHR-4080P in Single Screen PTZ Camera Control Mode to supply PTZ Camera. This is a very special function. Note Note Samsung, Panasonic, PelcoP, or PelcoD Protocol PTZ Camera supplies this function.

  • Page 80: Chapter 7 Recording

    Chapter 7 Recording...

  • Page 81: Panic (Emergency Recording)

    SHR-4080P USER’S MANUAL PANIC (Emergency Recording) Pressing the button records all the images input so far. PANIC Recording specification is Normal Size, Level 8 Quality, and 25 ips. During PANIC Recording, LED lights on and a recording icon appears on the screen.

  • Page 82: Rec (Normal Recording)

    REC (Normal Recording) Pressing REC the button starts recording as set in Record Mode of MENU. Then, REC LED lights on and a recording icon appears on the screen. During recording in HDD, HDD LED in front blinks. During REC Recording, you may stop REC Recoding by pressing the REC button then REC LED lights out.

  • Page 83: Timer Recording

    SHR-4080P USER’S MANUAL Record Schedule While “Continuous Recording” or “Both” is selected for Record Schedule in MENU, Timer Recording automatically starts. Otherwise, Timer Recording remains inacti- vated. During Timer Recording, Recording Icon appear on the screen. During recording in HDD, HDD LED in front blinks.

  • Page 84: Event Recording

    Event Recording Alarm Sensor State in Event Record Alarm of MENU shall be set to N.O (Normal Open) or N.C (Normal Close) Motion Detection M.D State in Event Record Motion Detection of MENU shall be set to On. Video Loss Video Loss State in Event Record Video Loss of MENU shall be set to On.
  • Page 85 Chapter 8 Search and Play...

  • Page 86: Before Use

    SHR-4080P USER’S MANUAL Before Use Pressing the SEARCH button shows Search Menu on the screen as seen above. CALENDAR uses a calendar to search video files at the preset time. Event Search searches video files recorded by Event. Date/Time inputs a day and time on which the system searches video files.

  • Page 87: Calendar Search

    Calendar Search Be sure to designate both the channel and the date first. Then press “Start” to initi- ate search. Uses a calendar to search video files at the preset time. Four channels as a maxi- mum are in the range of search. key and ➛,❿...

  • Page 88: Event Search

    SHR-4080P USER’S MANUAL Event Search Searches Normal Recording, Panic Recording, Sched.(Schedule) Recording, Alarm Recording, Motion Recording, and VLoss(Video Loss) Recording by the time. You shall select a channel to search to see the Event information of the channel. On the basis of the Event information for each channel, the system searches the video file for the event.

  • Page 89: Date/Time Search

    Date/Time Search Use the Day/Time information to search video files at the time as you desire. Up to 4 channels can be searched at once. , ❷, After you select a channel with the key, the checkbox on the right of ➛...

  • Page 90: Go To First Search

    SHR-4080P USER’S MANUAL Go to First Search Searches the oldest one among recorded video files. Up to 4 channels can be searched at once. , ❷, ➛ After you select a channel with the key, the checkbox on the right of the selected channel number will be checked.

  • Page 91: Go To Last Search

    Go to Last Search Searches the latest one among recorded video files. Up to 4 channels can be searched at once. , ❷, ➛ After you select a channel with the key, the checkbox on the right of the selected channel number will be checked. If you want to start search, use the ❷...

  • Page 92: Backup Data Search

    SHR-4080P USER’S MANUAL Backup Data Search Searches a video file for the preset time making use of the Day/Time information among recorded video files. Up to 4 channels can be searched at once. , ❷, After you select a channel with the key, the checkbox on the right of ➛...

  • Page 93: Play

    Play Press the PLAY/PAUSE button( ) to play the data recorded in HDD. ❿ II This chooses out a channel with the oldest data among recorded channels and plays the data from the first part of the channel. If you used the SEARCH button for play just before, the system would remember the information of the played channel until you click the PLAY/PAUSE button( ) again, then the system...
  • Page 94 SHR-4080P USER’S MANUAL Definition Play Screen Mode 4 Split Screen Single Screen PIP Screen 9 Split Screen If you press the Mode key, the play screen will be characterized by 4 Split, Single, PIP, and 9 Split Screen. If you select one channel in Search, 4 Split Screen will not appear.
  • Page 95 Play at Faster Speed If you press the LEFT or RIGHT button( ) or use the shuttle during ❿ ❿ ➛ ➛ play, you will be able to see the screen at the x2, x4, x8, x16, x32, and x64 speed either forwardly or reversely.

  • Page 96: Chapter 9 Backup

    Chapter 9 Backup...

  • Page 97: Backup Start

    Pressing START begins backing up the whole channel data until the preset time at the armored HDD. During Backup process, Backup LED in front of SHR-4080P turns green. Note Note Pressing Cancel does not cancel or pause Backup but rise to the upper menu. Backup...

  • Page 98: Backup Stop

    If you select Stop during Backup process, Backup will stop immediately. As soon as Backup stops or ends, Backup LED in front of SHR-4080P lights out. If you change the time of the system or shuts down it, Backup in progress will...

  • Page 99: Backup Play

    SHR-4080P USER’S MANUAL Backup Play Press the SEARCH button in front of SHR-4080P and select Backup Search to play the backup data. Select a channel and time and press Start to play a data. Note Note Backup is not available during Backup...

  • Page 100: Chapter 10 Pc Viewer

    Chapter 10 Smart Viewer...

  • Page 101: Introduction

    SHR-4080P USER’S MANUAL Introduction Smart Viewer is a program that a general PC user is able to install SHR-4080P to his PC to monitor the search video and audio data through Network without going to the site where SHR-4080P is installed by himself.

  • Page 102: Feature

    Feature Thanks to the transmission of video data compressed by the MPEG-4 Video Compression method, this plays video images of good quality. Thanks to the G.726 Voice Compression method, this supplies voice data of good quality. Use of armored MIC improves the quality of remote voice. Thanks to the transmission of video/audio stream through RTP(Real-Time Transport Protocol), real-time video play capacity is excellent and multi-users’...
  • Page 103 SHR-4080P USER’S MANUAL PC Specification(Recommendation) OS : Win98SE, WinMe, Win2000, WinXP Recommendation : CPU P3 1GHz or higher RAM 256 Mb or higher VGA RAM 16Mb or higher DirectX 8.1 or higher Note Note Depending on Recording Rate, Video Size, and user’s PC specification set to SHR- 4080P, the number of Smart Viewer play frame varies.

  • Page 104: Smart Viewer Installation

    Smart Viewer Installation 10-4-1 Smart Viewer Installation Put a Smart Viewer Program CD in CD-ROM and open the “Smart Viewer” folder in CD. Smart Viewer supports Win98se/ME/2000/XP OS. Win98se/ME users and Win2000/XP users shall make use of the setup file in the “Win98_ME” folder and the “Win2000_XP ”...
  • Page 105 SHR-4080P USER’S MANUAL Click the “Next” button. If you agree with Smart Viewer License, click “Yes”. Designate a folder to install Smart Viewer in it and click “Next”. 10-5...
  • Page 106 The system proceeds with setup file installation and system setup. Installation is complete. Press “Finish” to terminate installation. 10-6...
  • Page 107 SHR-4080P USER’S MANUAL 10-4-2. Smart Viewer SDK Setup Smart Viewer SDK is a tool to help a user make his own Viewer program with the modules(ActiveX Control, DirectShow Filter) for the operation of Smart Viewer in the MS Windows environment.
  • Page 108 Click "Next". If you agree with Smart Viewer SDK License, click "Yes". 10-8...
  • Page 109 SHR-4080P USER’S MANUAL Designate a folder for Smart Viewer SDK installation and click "Next". Install the SDK document and sample program and set up the necessary system. 10-9...
  • Page 110 Installation Complete. Click "Finish" to terminate the installation. Note Note Refer to the Doc folder in the folder in which Smart Viewer SDK has been installed for the details of Smart Viewer SDK. 10-10...

  • Page 111: Smart Viewer Program Execution

    SHR-4080P USER’S MANUAL Smart Viewer Program Execution Double-click the Smart Viewer icon in the background screen to run the program. 10-11...

  • Page 112: Smart Viewer Initial Screen

    @ This button terminates or minimizes the program. # It displays the current date, day, and time. $ This button is used for the connection with the preset DVR(SHR-4080P) or site. % This screen shows the monitoring video image. ^ This window displays the event message from SHR-4080P real-time.

  • Page 113: Monitoring Mode

    SHR-4080P USER’S MANUAL Monitoring Mode DVR(SHR-4080P)/SITE Connection - Select the name of DVR(SHR-4080P) or site for connection and click the connec- tion button. Note Note You can determine the name, IP, and password of DVR(SHR-4080P) for connection in Setup Mode. Also, setup of a site which permits simultaneous connection to multi- DVRs(SHR-4080P) is available in Setup Mode.
  • Page 114 No more than 3 users, one Admin. authorized user and 2 User authorized users are allowed to access SHR-4080P simultaneously. Caution Caution Once occupied by 3 users, SHR-4080P does not permit more connection. Monitoring Mode Connection Screen Caution Caution If you alter “Resolution” or “Color Quality” from the setup tab of [Display Registration Information] while Smart Viewer is running, Smart Viewer will fall into an unexpected condition.
  • Page 115 SHR-4080P USER’S MANUAL Time Information - As soon as you are connected to SHR-4080P, the current date, day, and time of SHR-4080P will be displayed. - Otherwise, the current date, day, and time of your PC will be displayed. Connection Information - As soon as you are connected to SHR-4080P, the connection button will display connection status.
  • Page 116 Window. Note Note ^ If you connect and set up PTZ Camera in SHR-4080P, PTZ controllability of the channel will be displayed. Select a channel capable of PTZ and use the PTZ related buttons at the bottom to control PTZ. (Refer to the description of PTZ Related Button.)
  • Page 117 ❿ Setup Start / End (Local) : Start/Finish the Menu screen at SHR-4080P. ❿ Video Loss CH[N] : Video Loss at the N channel of SHR-4080P encountered. ❿ Alarm Detection CH[N] : Alarm issued at the N channel of SHR-4080P.
  • Page 118 1 (CH) - In Quad Mode : 1,2,3,4 5,6,7,8 1,2,3,4 (CH) - In the event of connection with one SHR-4080P, this will not apply for Nine-Split Mode. Note Note If you connected with multi-DVRs(SHR-4080P) through a site, Sequence will operate as follows.
  • Page 119 SHR-4080P USER’S MANUAL Play Screen Condition Information / Selection Button - Displays the Split or Play condition of the screen in play. - Press each camera icon to choose the relative channel. : During play in Nine-split Mode : During play in Quad Mode...
  • Page 120 1 (CH) - In Quad Mode : 1,2,3,4 5,6,7,8 1,2,3,4 (CH) - In the event of connection with one SHR-4080P, this will not apply for Nine-split Mode. Note Note If you connected with multi-DVRs(SHR-4080P) through a site, Sequence will operate as follows.
  • Page 121 SHR-4080P USER’S MANUAL Video Recording Button - If you select a channel in play and click the REC button, the image will be saved in a file format with the extension of *.dvr in a designated folder of your PC.
  • Page 122 ZOOM IN / OUT will be acti- vated in the clicked part. Note Note The PAN / TILT / ZOOM function is supplied to all camera. But, POWER ZOOM is supported only by Samsung Smart Dome Camera, with TILT below 45°. 10-22...
  • Page 123 The name of @,#, and $ functions varies depending on the camera and some cam- eras does not support any of those functions. - The Samsung camera supports all the functions and names. - The Panasonic camera supports all the functions, but with different names.
  • Page 124 The Camera Menu Setup function is supported by Samsung and Panasonic. Caution Caution As far as SHR-4080P uses the PTZ Camera control related functions, Smart Viewer can not control PTZ Camera. The PTZ Camera control related functions are authorized with the user with Admin authority.

  • Page 125: Search Mode

    Search Mode Description of Search Mode Initial Screen - Search Mode is divided into Remote Mode for SHR-4080P image search/play and Local Mode to play *.dvr file saved in the directory designated by your PC. ! Pressing this button enters Search Mode for the remote control of the image recorded in SHR-4080P.
  • Page 126 - Same as “DVR(SHR-4080P)/SITE Connection” of Monitoring Mode. Remote Mode - This mode sends out the video data recorded in SHR-4080P to Network for play. - Up to 4 channels are allowed for simultaneous search and play. - The video information at the time indicated by TimeBar will be displayed in the Play screen.
  • Page 127 SHR-4080P USER’S MANUAL Calendar Window - If the video data in on-line SHR-4080P was recorded, the date turns red. - If you click the date in red, the saved video data will be displayed. - The currently selected date will be marked with a thick red box.
  • Page 128 Video Record / Convert File / Print / Setup ! Video Record Button - If you select a channel in play and click the SAVE button, the image will be saved in a file format with the extension of *.dvr in a designated folder of your - The name of the directory in which an image will be saved, the file name, and the length of an image to be saved shall be set up by Setup Mode Viewer...
  • Page 129 SHR-4080P USER’S MANUAL # Print - This function outputs the screen zone of the image in play which is now being displayed. $ Setup Mode Button - This button pops up the Setup Mode window. Play Buttons ! Play : Play...
  • Page 130 Local Mode is not permitted. Click the Stop button first before conversion. Time Line - Displays the time information on the video data in SHR-4080P on the calendar window for the selected day. - The General mode indicates the information on time for 24 hours while the Extension mode indicates the information on time every 2 hours.
  • Page 131 - This mode plays *.dvr files recorded in the directory of your PC by the Record function. - You can search and play only one channel. - You are free for access to the user being connected to SHR-4080P - Other functions than the calendar display function are as same as those of Remote Mode.

  • Page 132: Setup Mode

    SETUP MODE Description of Initial Screen ! This button is used to select items for DVR Setup, Viewer Setup, Site Setup, and S/W Version setup. @ Shows what the selected Setup item can set up in detail. # This button terminates the Setup window. $ This button saves the information revised in the Setup window, remarks the infor- mation prior to such a revision, or terminates the Setup window.
  • Page 133 - Viewer Setup: Viewer Setup allows you to set up various kinds of items concern- ing operations of Smart Viewer. - Site Setup: Site Setup allows you to set up SHR-4080P information, that is SHR- 4080P name, IP Address, ID, and Password that you contact through Smart Viewer or register all the registered SHR-4080Ps at a site for control.

  • Page 134: Dvr Setup

    Note Note - DVR setup Where SHR-4080P that you wish to connect to has been already occu- pied by other user in an Admin Capacity, - You are authorized with access to DVR Setup in an Admin capacity only. The button will not be activated if you are connected to SHR-4080P as a user or unconnected.
  • Page 135 - Information Information shows the information on on-line SHR-4080P. Note Note For the detailed items of DVR Setup, refer to Chapter 5, MENU. - Password Password determines the password for the control of SHR-4080P Menu or SHR-4080P key input. 10-35...
  • Page 136 Note Note - If you change the Time / Date value, SHR-4080P will automatically cut the connec- tion with Smart Viewer to apply a new time setup. - Upon completion of new time setup of SHR-4080P, you are permitted to resume connection with Smart Viewer.
  • Page 137 Note Note Language change by SYSTEM LANGUAGE results in change of language expression setup of SHR-4080P. In short, the language setup of Smart Viewer does not change. Language specification to be supported is subject to change later. - Disk Mode In Disk Mode, you may set up Writing Mode of HDD attached to SHR-4080P.
  • Page 138 - Remocon (Remote Control Device) Remocon can set up Remote Control Device fixed to SHR-4080P. Note Note If you fix Remote Control Device to the main body of SHR-4080P and activate the setting values, Viewer will be disabled to control PTZ. 10-38...
  • Page 139 @ Camera/Audio - Config. Config. sets up Video, Audio On/Off, Camera Title, and Auto Sequence Time for each channel of on-line SHR-4080P. Caution Caution - Title supports English only. If you type in and apply Title in your native language, Warning message will pop up to ask your retyping.
  • Page 140 - PTZ device If a dome camera is connected to all channels, sets up Camera ID, Protocol, Baud Rate, Parity, Data Bit, Stop Bit, and Serial Mode. # Monitoring - Monitoring Monitoring sets up both Event Monitoring and OSG Display of Live Mode. 10-40...
  • Page 141 SHR-4080P USER’S MANUAL $ Recording - Rec. Mode Rec. Mode sets up Live Mode decision, Video Size during recording, Quality, and Rate. Note Note Full D1(L) Video Size does not support 25ips Rate. - Event Rec. Event Rec. sets up Video Size, Quality, Rate, Pre Alarm, and Post Alarm values to be recorded when Event occurs.
  • Page 142 - Alarm Rec. Alarm Rec. sets up the information necessary for Alarm Recording. Note Note More than one camera shall be selected to apply Alarm. - Motion Rec. Motion Rec. sets up the information necessary for recording by Motion Detection. 10-42...
  • Page 143 SHR-4080P USER’S MANUAL - Video Loss Video Loss sets up the information on how to inform the user of Video Loss of SHR-4080P. % Network - Password This sets up the password for Admin and User to let you connect with SHR- 4080P through Network in Smart Viewer.
  • Page 144 SHR-4080P supports the connection with Static IP, Dynamic IP, and ADSL(PPPoE). Sets up the network Bandwidth. Please adjust the bandwidth to the network con dition in which SHR-4080P is connected. Sets up IP Address, Port Number, Gateway, Subnet Mask, and DNS. Please input both ID and password of the sub scriber in the event of ADSL.

  • Page 145: Viewer Setup

    - A PORT number is flexible and 4 numbers in a row will be changed in all. (554,555,556,557 --> 558,559,560,561) - You shall allocate the above ports for SHR-4080P if you want to compose a net- work by IP Router.
  • Page 146 No. + Serial No.” or camera number, current date, and time, set to “Camera No. + Date”. @ Location - As long as you are connected to SHR-4080P in Monitoring or Search Mode while recording the video data in display, this sets up a directory where *.dvr file format will be saved.
  • Page 147 Record Rate is set to 6 ips in the Menu, Viewer will be able to record up to 6 frames per a second. Sequence Time - As long as you are connected to SHR-4080P in Monitoring Mode while Auto Sequence is dominant, this sets up Auto Sequence Time. Time setup ranges from 10 to 20 minutes.

  • Page 148: Site Setup

    - Determines if Smart Viewer shall be automatically connected to SHR-4080P or Site as soon as it starts running. - If you check “Auto Connection On”, the name of SHR-4080P and Sites that are currently registered in DVR/Site List will be listed as follows and if you select one, it will be automatically connected to the selected SHR-4080P or Site as soon as Smart Viewer starts running.
  • Page 149 $ This button adds a new site or deletes or revises the already-registered Site. % This button adds DVR(SHR-4080P) selected from DVR List to the Site selected from Site List. But, if the selected DVR(SHR-4080P) is set to ADSL Network, it can not be registered with the site.
  • Page 150 1. Network Modes - LAN - If DVR(SHR-4080P) is connected to LAN, set Network Modes to LAN. - If the LAN connected to DVR(SHR-4080P) uses Static IP, select Static IP from Address Type and input the name and IP Address of DVR(SHR-4080P).
  • Page 151 Reference - DVR may be named in both English and Korean with no more than 10 texts. - Login Password shall be as same as Network Password for SHR-4080P to authorize connection. - DVR addition will be possible only after you type in all the information where nec- essary.
  • Page 152 @ Deletion of Already-Registered DVR(SHR-4080P) - If you select one DVR(SHR-4080P) in DVR List for deletion and press the [Delete] button, the following message box will pop up. If you press [OK] button then, DVR(SHR-4080P) will be deleted. - As long as DVR(SHR-4080P) for deletion is connected with the current Smart Viewer, the following message box will pop up and DVR(SHR-4080P) will not be deleted.
  • Page 153 SHR-4080P USER’S MANUAL Site List - Site List registers multi- DVRs(SHR-4080P) that you want to contact at once by Smart Viewer at one site for control. You are allowed to register a new Site or delete or modify the selected Site from the registered list and add DVR(SHR-...
  • Page 154 Site may be named in both English and Korean with no more than 10 texts. @ Deletion of Already-Registered Site or DVR(SHR-4080P) - If you select one Site or DVR(SHR-4080P) in Site List for deletion and press the [Delete] button, the following message box will pop up. If you press [OK] button then, either Site or DVR(SHR-4080P) will be deleted.
  • Page 155 Modification to DVR(SHR-4080P) shall be done only in DVR List. DVR(SHR-4080P) Addition to Site - If you press the [Add] button, DVR(SHR-4080P) selected from DVR List will be added to the Site selected from Site List. Site addition to DVR(SHR-4080P) set to ADSL is prohibited.
  • Page 156 DVR(SHR-4080P), your access will be denied. ! Smart Viewer Version and system requirements will be displayed. @ Here displays the version and name of DVR if any DVR(SHR-4080P) is being connected with Smart Viewer. You are also able to upgrade DVR(SHR-4080P) S/W by transmitting it to on-line DVR(SHR-4080P).
  • Page 157 DVR(SHR-4080P) composing a site if any DVR(SHR-4080P) is being connected with the site but also displays DVR(SHR-4080P) S/W version. - As long as Smart Viewer is isolated from DVR(SHR-4080P), this part remains inactivated. - Each DVR Version has a check box, which is used for S/W Upgrade.
  • Page 158 @ Click the following button to open the “SHR-4080 Firmware” file in tgz format. # Press the [Upgrade] button to transmit a file to the selected DVR(SHR-4080P) and start upgrade of DVR(SHR-4080P) S/W. $ The progress of file transmission and upgrade will be displayed at the bottom.

  • Page 159: Appendix

    Appendix...

  • Page 160: Product Specification

    SHR-4080P USER’S MANUAL Product Specification Item Specification Remark 32bit RISC CPU Memory SDRAM : 64MByte Flash : 8MByte Operation System Embedded OS Broadcasting PAL System Input Voltage AC 100-230V, 50/60Hz Power Comsumption 85 Watt Max Composite 8 Channel - 1.0Vp-p - 75 Ω...
  • Page 161 Time Laps PAL : 1/2.5/5/6.25/8.33/12.5/ 25ips ATA HDD x 4(MAX) * Packing 120GB Internal -Primary/Secondary IDE Connector (Samsung) -MAX HDD Size : 250GB x 4 = 1Tera Byte x 1EA Storage IEEE1394 I/F HDD Capacity External -MAX 6 (Daisy chain connection) -MAX HDD Size : 250GB x 6 = 1.5Tera Byte...
  • Page 162 SHR-4080P USER’S MANUAL Item Specification Remark Calendar Event - Normal, Panic, Schedule, Alarm, Motion, Search Mode Video Loss Date/Time Go to First Go to Last Backup Data Resolution Decoding Performance Resolution & Play Back Performance CIF(352 x 288) 25ips 25ips/1Ch...

  • Page 163: Hdd Specifications

    73.4 GB Ultra320 SCSI ST373307LC 146.8 GB ST3146807LC Internal ATA HDD/IEEE1394 I/F External HDD Maker Capactity Interface Model No 120 GB Ultra ATA-133 SV1203N Samsung 5,400 160 GB SV1604N 7,200 120 GB Ultra ATA-133 4R120LO Maxtor 7,200 160 GB 4R160LO 5,400...

  • Page 164: Outline Drawing

    SHR-4080P USER’S MANUAL Outline Drawing 11-5...

  • Page 165: Factory Default

    Factory Default This restores the Network information and preset values in SHR-4080P to the original state at the time of factory shipment. Factory Default will be done if you; - Use System / Load Factory Default in MENU or, - If you hold on to the Mode button in Live Mode and keep pressing the CH5 button for 5 seconds, the system will return to the Factory default condition.
  • Page 166 SHR-4080P USER’S MANUAL Classification Detailed Items Factory Setup Monitoring Setup Event Monitoring Duration OSD Display Date Time Title Status Spot Out Channel Spot Out Event Monitor Monitor Out Composite Out PB Channel Position Right Down Record Mode Mode Setup Video Size...

  • Page 167: Shr-4080P Smart Viewer Play Frame Specification

    SHR-4080P is connected with a fast network like LAN. When the main body of SHR-4080P is connected with a slow network like ADSL, the play speed will be 0.5 Frame/sec. In addition, the above specification has been defined to the recommended specification of your PC.

  • Page 168: Troubleshooting(Faq)

    4080P DVR. 6. You cannot enter MENU by forgotten password. - If you forget the password, you shall reset SHR-4080P DVR to the values set at the factory. Keep pressing both the "MODE" button and the "5" button on the left for 5 seconds until LED lights on in the order of 1❖2❖3❖4❖5.
  • Page 169 HDD. 12. You cannot connect to SHR-4080P DVR through Smart View. - Check if 3 Smart Viewer users are in connection with SHR-4080P DVR. SHR- 4080P DVR allows no more than 3 users’ connection with Smart Viewer at a time.
  • Page 170 5 times. If it remains unconnected after 5 time trial, it will automatically give up connection. - As far as SHR-4080P DVR is connected to the ADSL network, you may be dis- connected from Smart Viewer when the network conditions goes bad.
