Completing the installation

To complete the installation, complete the following steps:
1. Insert the bezel hinges into the slots on the server chassis and close the bezel
2. Position the left-side cover over the server.
3. Place the bottom edge of the cover onto the bottom edge of the server.
4. Rotate the top edge of left-side cover toward the server; then, press down on
5. Rotate the bezel to its fully closed position.
6. Using the supplied key, lock the left-side cover and bezel.
7. Connect the cables and power cords. For more information, see "Connecting

Closing the bezel media door

To close the media door, complete the following steps:
1. Swing the bezel media door closed and push it into the bezel to close it.
2. From inside of the top section of the bezel door, slide the blue tab down to lock
3. Close the bezel (see "Closing the bezel").

Closing the bezel

To close the bezel, complete the following steps:
1. Rotate the left side of the bezel toward the server to the closed position.
2. Lock the left-side cover, using the key that comes with the server.
76
ThinkServer TD200x Types 3719, 3821, 3822, and 3823: Installation and User Guide
("Closing the bezel media door" and "Closing the bezel").
the cover handle until it clicks into place ("Installing the left-side cover" on page
77).
the cables" on page 77.
the bezel media door.
