Summary of Contents for Gigabyte GD-1503BP
- Page 1 Warning card FCC Declaration of Conformity CE EU Declaration of Conformaty...
- Page 4 Your monitor Pedestal AC Power cord D-sub Signal cable This manual...
- Page 5 2.1 Install the pedestal To attach the base to your monitor, please following the steps for installation of the pedestal as below: step 1 step 2 step 3 2.2.1 Turn off your computer and unplug its power cable. 2.2.2 C onnect the power cord to the power jack on the back of your monitor 2.2.3...
- Page 6 AC Power cable (1) VGA Signal Cable Audio in Note: (3) only for monitor with speaker function VGA Signal Cable 3 Audio cable AC Power cable...
-
Page 7: Switching The Monitor On/Off
4.1 SWITCHING THE MONITOR ON/OFF This ON/OFF button is used for switching the monitor on and off. Note: The ON/OFF switch does not disconnect the device from the mains voltage. To completely disconnect the mains voltage. Please remove the power plug from the socket. 4.2 POWER INDICATOR This indicator lights up green or blue when the monitor operates normally. - Page 8 Color Select Menu...
- Page 10 Mode Resolution Vertical Horizontal 720 x 400 31.47 kHz 70 Hz 640 x 480 31.47 kHz 60 Hz 640 x 480 37.86 kHz 72.8 Hz 640 x 480 37.5 kHz 75 Hz 800 x 600 37.88 kHz 60.3 Hz 800 x 600 48.08 kHz 72.2 Hz 800 x 600...
-
Page 11: Products Specifications
Technical Information 5.1 Products Specifications Inch Size 15" Max. Resolution 1024*768@75 Hz 768@60 Recommend Resolution 1024* Horizontal Freq. 30-60 KHz Vertical Freq. 60-75 Hz Active Display Area 304*228 mm Bandwidth 80 MHz User Control 4 Key Sw OSD Functions Bri htness, contrast, H-position, V-position, H-Size, phase, Color, auto, Reset, language, OSD, Exit,... -
Page 12: Signal Connector Pin Assignment
5.2 Signal connector pin assignment... - Page 13 5.3 Visual Inspection Even the normal pixels on the LCD screen reach 99.99% or higher, there may be 0.01% or less pixels showing dark or light while displaying.
- Page 14 5.4 Troubleshooting Before calling for service, check the information in this section to see if you can remedy any problems by yourself. If you need assistance, please call the dealer where you purchased the LCD monitor. There is no SCREEN image The power cord is securely connected to the monitor, the adaptor, and the wall outlet.
- Page 15 Warning Card...
