- Page 1 GAMING MONITOR U SE R GUI DE AORUS F O32U2P / AORUS F O32U2 / AORUS F O27Q3...
- Page 2 Changes to the specifications and features in this manual may be made by GIGABYTE without prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by any means without GIGABYTE’s prior written permission. •...
-
Page 3: Table Of Contents
GIGABYTE Service Information . . . . . . . . . . . . . . . . . . . -
Page 4: Introduction
The following items come with your packaging box. If any of them is missing, please contact your local dealer. Monitor Monitor Base Stand Power Cable Power Adapter DP to Mini DP Cable (AORUS FO32U2P) DP Cable HDMI Cable Type-C Cable (AORUS FO32U2/ (AORUS FO32U2P) AORUS FO27Q3) USB Cable... -
Page 5: Product Overview
MINI DP USB 3.2 HDMI-1 HDMI-2 DP OUT TYPE-C Mini DisplayPort HDMI ports (x2) DisplayPort (AORUS FO32U2P) DisplayPort Out USB Type-C port Microphone jack (AORUS FO32U2P) Headphone jack USB upstream port USB 3.2 ports (x2) DC IN jack - 5 -... -
Page 6: Preparing Your Monitor For Wall-Mounting
Preparing your Monitor for Wall-Mounting Note: Use only a 100 x 100 mm VESA compatible wall mount kit to mount the monitor on the wall. Refer to the installation guide included in the wall-mount bracket kit. VESA mounting screw quantity and size: 4 x M4 x 10mm minimum. USING THE DEVICE Turning the Power On/Off Power On... -
Page 7: Selecting The Input Source
Selecting the Input Source Input Control Move the button right ( ) to enter the Input menu. HDMI 1 Control Move the button up/down ( ) to select the desired input source. Then press the HDMI 2 Control button to confirm. Type-C Exit Select OPERATIONS Quick Switch Menu... - Page 8 • Control button down ( ) to enter the Picture Mode menu. Move the Control Move the button up/down ( ) to Picture Mode Control select the desired option and press the button to confirm. Standard MOBA Racing Exit Select • Control button left ( ) to enter the Volume menu.
-
Page 9: Function Key Guide
Function Key Guide • Control Press the button to display the Main menu. Settings OLED Care Game Assist Exit Power Off Control Then use the button (up/down/left/right) to select a function page and configure the related settings. - 9 -... - Page 10 OLED Care • When the Main menu appears on the screen, move the Control button left ( ) to enter the OLED Care menu. OLED Care Status Pixel Clean Start Cleaning Settings Static Control Start Time Delay Pixel Shift APL Stabilize Sub-Logo Dim Corner Dim Reset Settings Exit...
- Page 11 Game Assist • When the Main menu appears on the screen, move the Control button right ( ) to enter the Game Assist menu. Game Assist GAME INFO Game Timer Crosshair Gaming Counter Tactical Switch Refresh Rate Eagle Eye Info Location Dashboard Display Alignment Exit Select...
- Page 12 Configure the Device Settings When the Main menu appears on the screen, move the Control button up ( ) to enter the Settings menu. Exit Move / Adjust Enter / Confirm Button Guide - 12 -...
- Page 13 Gaming Configure the game related settings. Res. FreeSync Premium Pro 2560X1440 FO32U2P Gaming Black Equalizer 2.0 Picture Super Resolution Display Display Mode PIP/PBP FreeSync Premium Pro System Reset All Exit Move / Adjust Enter / Confirm Item Description Black Equalizer Adjust the visibility of dark areas in the image to enhance details and improve visibility in dark scenes.
- Page 14 Picture Configure the image related settings. Input Mode Bri. HDMI 1 Standard Normal FO32U2P Gaming Standard Picture Display MOBA PIP/PBP System Racing Reset All Movie Reader Exit Move / Adjust Enter / Confirm Item Description Picture Select different predefined settings to optimize the visual presentation based on the content type or customize personal preferences.
- Page 15 Display Configure the display screen related settings. Res. FreeSync Premium Pro 2560X1440 FO32U2P Gaming Input Picture Display DP DSC PIP/PBP Daisy Chain System RGB Range Reset All Apply Picture Mode Exit Move / Adjust Enter / Confirm Item Description Input Select the input source.
- Page 16 PIP/PBP Configure the Picture-In-Picture and Picture-By-Picture related settings. Res. FreeSync Premium Pro 2560X1440 FO32U2P Gaming Picture Display PIP/PBP System Reset All Exit Move / Adjust Enter / Confirm Note: PIP/PBP function cannot be enabled when receiving HDR and FreeSync signals. - 16 -...
- Page 17 System Configure the system related settings. Res. FreeSync Premium Pro 2560X1440 FO32U2P Gaming Language Picture Audio Display Audio Mode PIP/PBP OSD Settings System Quick Switch Reset All Other Settings Exit Move / Adjust Enter / Confirm Item Description Language Select the desired language for the OSD menu. Audio Configure the audio related settings.
- Page 18 Other Settings • HDMI-CEC: When this function is enabled, CEC devices like PS5, XBOX can turn on the monitor when they are awakened (continue) and switch off the display when they enter either standby or off mode. • USB(A/C) Charge: Enable/Disable the USB Type-A and Type-C charging function.
-
Page 19: Appendices
APPENDICES Specifications Item Specifications AORUS FO32U2P AORUS FO32U2 AORUS FO27Q3 Model Panel Size 31.5-inch 26.5-inch Aspect Ratio 16:9 Resolution 3840 x 2160 2560 x 1440 LED Life 30,000 hours (min.) Pixel Pitch 181.4 x 181.4 um 229.2 x 229.2 um Brightness 250 nits (Typ, SDR APL 100%); 1000 nits (Typ, HDR APL 3%) Contrast Ratio 1.5M:1 Color Depth... -
Page 20: Supported Timing List
Supported Timing List AORUS FO32U2P AORUS FO27Q3 Model AORUS FO32U2 Timing List HDMI TYPE-C HDMI TYPE-C 640 x 480 / 60Hz 640 x 480 / 67Hz 640 x 480 / 72Hz 640 x 480 / 75Hz 720 x 400 / 70Hz 720 x 480 / 60Hz 720 x 576 / 50Hz 800 x 600 / 56Hz 800 x 600 / 60Hz... - Page 21 AORUS FO32U2P Model AORUS FO27Q3 AORUS FO32U2 Timing List HDMI TYPE-C HDMI TYPE-C 2560 x 1440 / 60Hz 2560 x 1440 / 120Hz 2560 x 1440 / 240Hz 2560 x 1440 / 360Hz 3840 x 2160 / 30Hz 3840 x 2160 / 50Hz 3840 x 2160 / 60Hz 3840 x 2160 / 100Hz 3840 x 2160 / 120Hz...
-
Page 22: Troubleshooting
• Make sure that the cloth is damp, but not wet. • When wiping, avoid applying excessive pressure on the screen. • Acidic or abrasive cleaners can damage the screen. GIGABYTE Service Information More service information, please visit GIGABYTE official website. https://www.gigabyte.com/ - 22 -... -
Page 23: Safety Information
SAFETY INFORMATION Safety Precautions Read through the following Safety Precautions before using the monitor. • Only use the accessories that are provided with the monitor or that which are recommended by the manufacturer. • Keep the plastic packaging bag for the product in a place that cannot be reached by children. -
Page 24: Stability Hazard Precautions
• Eye exercise can help reduce eye strain. Repeat these exercises frequently: (1) look up and down (2) slowly roll your eye (3) move your eyes diagonally. This model has passed Flicker Free and Low Blue Light verification by TÜV Rheinland. To learn more: https://www.gigabyte.com/tw/Support/FAQ/4310 - 24 -... -
Page 25: Regulatory Information
European Union (EU) RoHS (recast) Directive 2011/65/EU & the European Commission Delegated Directive (EU) 2015/863 Statement GIGABYTE products have not intended to add and safe from hazardous substances (Cd, Pb, Hg, Cr+6, PBDE, PBB, DEHP, BBP, DBP and DIBP). The parts and components have been carefully selected to meet RoHS requirement. Moreover, we at GIGABYTE are continuing our efforts to develop products that do not use internationally banned toxic chemicals. - Page 26 European Union (EU) Community Waste Electrical & Electronic Equipment (WEEE) Directive Statement GIGABYTE will fulfill the national laws as interpreted from the 2012/19/EU WEEE (Waste Electrical and Electronic Equipment) (recast) directive. The WEEE Directive specifies the treatment, collection, recycling and disposal of electric and electronic devices and their components. Under the Directive, used equipment must be marked, collected separately, and disposed of properly.
- Page 27 CE declaração de conformidade Este produto estão em conformidade com das seguintes Diretivas UE: Diretiva Baixa Tensão 2014/35/UE; Diretiva CEM 2014/30/UE; Diretiva Conceção Ecológica 2009/125/CE; Diretiva RSP 2011/65/CE e a Diretiva (UE) 2015/863 que altera o Anexo II. A conformidade com estas diretivas é verificada utilizando as normas europeias harmonizadas.
