Contents Safety Instructions ..........................2 Resource Recycle Information ......................3 System Components and Accessories ..................... 4 Installation Instructions ........................5 Installing the Display........................5 Packaging Procedures........................5 Adjusting the Viewing Angle ......................5 Connection Instructions ........................6 Using the Display ..........................7 Turning On the Display ........................ -
Page 3: Safety Instructions
Safety Instructions • Do not place the LCD display near any heat sources such as electric radiators or direct sunlight. Place the display in a stable and well-ventilated place. • The holes or openings on the display are for ventilation. Do not cover or block the ventilation holes with any objects. -
Page 4: Resource Recycle Information
Recycling information We, Gigabyte Technology, care very much about our environment protection strategy and firmly believe that it helps us have healthier earth via appropriate treatment and recycling of industrial technology devices at the end-of-life. These devices contain recyclable materials, which can be re-decomposed and re-integrated into brand-new marvels. -
Page 5: System Components And Accessories
System Components and Accessories LCD Display Audio Cable Power Cord Signal Cable (VGA) User Manual If any component is missing, please contact your local dealer for technical support or customer service. Remark: Please keep the original box and packing materials for future transportation or shipment of the display. -
Page 6: Installation Instructions
Installation Instructions Installing the Display 1. Place the display onto the base. 2. Align the display with the swivel on the base and plug the display into the base. Packaging Procedures If you need to package the display, please unplug the display panel from the base before placing them into a box. -
Page 7: Connection Instructions
Connection Instructions Note: Before installation, please make sure to power off the display and the computer. ○ Power Cord Plug the female end of the power cord to the power socket on the rear of the display. Then plug the male end to the AC power outlet. ○... -
Page 8: Using The Display
Using the Display Turning On the Display Turn on the display before turning on the computer. When the power is on, the LED on the power button lights green and the screen image will appear after about 10 seconds. If the LED doesn’t light green or no image appears, please verify if the display is properly connected. -
Page 9: Osd Selection
OSD Selection After you press the MENU button to enter the OSD menu, use , , , to select the items you want to adjust. Then press the SET AUTO button. After the screen fonts turn from black to blue you may start to make the adjustments. -
Page 10: Troubleshooting
Troubleshooting Problems Possible Solutions • Check if the power switch is in the ON position. Power LED doesn’t light on. • Make sure the power cord is properly connected. • Check if the power switch is in the ON position. No screen image. -
Page 11: Product Specifications
Product Specifications LCD Panel Size 20.1” inch Contrast 600:1 (typical) Viewing Angel Horizontal: 150°, Vertical: 130° (typical) Response Time 8 ms (typical) Brightness 300 cd/㎡(typical) Input Signal Analog video (15-pin connector) Display Colors 16 M Color Frequency Horizontal: 31~ 83 kHz, Vertical: 56 ~ 75 Hz Max. -
Page 12: Appendix
Appendix CONNECTOR PIN ASSIGNMENT 15 - Pin Color Display Signal Cable: PIN NO. DESCRIPTION PIN NO. DESCRIPTION Green Ground Blue Ground Ground DDC-Serial Data Ground H-Sync R-Ground V-Sync G-Ground DDC-Serial Clock B-Ground...
