- Page 1 24-Port 10/100Mbps + 4 built-in Combo 10/100/1000Mbps Copper/SFP (mini-GBIC) Gigabit Management Switch ESW-8228 User's Guide...
-
Page 2: Table Of Contents
The Switch User’s Guide Trademarks ···························································································4 Copyright Statement ···············································································4 Preface ·································································································4 FCC Warning ·····················································································4 CE Mark Warning················································································4 About This Guide ···················································································4 Purpose ····························································································4 Terms/Usage ·····················································································5 Notes, Notices, and Cautions ································································5 1 Introduction ······················································································6 1.1 Gigabit Ethernet Technology·····························································6 1.2 Fast Ethernet Technology ································································6 1.3 Switching Technology ·····································································7 1.4 Key Features ················································································7 1.4.1 Hardware Interfac···································································8... - Page 3 The Switch User’s Guide 5.1.4 MAC Address ······································································ 27 5.1.5 CONSOLE·········································································· 27 5.1.6 Management Host Configuration ············································· 28 5.1.7 System Upgrade ·································································· 28 5.1.8 Saving Parameters ······························································· 29 5.1.9 Parameters Backup & Recovery·············································· 29 5.1.10 Load Default······································································ 30 5.1.11 Reboot ············································································· 30 5.2 Port Management ········································································...
-
Page 4: Trademarks
The Switch User’s Guide Trademarks Copyright @ 2005 Corporation. Contents subject to change without prior notice. is a registered trademark of Corporation/ Systems, Inc. All other trademarks belong to their respective proprietors. Copyright Statement No part of this publication may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from Corporation/... -
Page 5: Terms/Usage
The Switch User’s Guide Terms/Usage In this manual, the term “Switch” (first letter upper case) refers to the Switch, and “switch” (first letter lower case) refers to other Ethernet switches. Notes, Notices, and Cautions NOTE: A NOTE indicates important information that helps you make better use of your device. -
Page 6: Introduction
The Switch User’s Guide Introduction The Switch is equipped with 24 10/100BASE-TX Fast Ethernet ports and 4 combo 10/100/1000BASE-T/SFP (mini-GBIC) ports for flexible copper/fiber Gigabit connection. The Switch is an effective solution for the small and medium size business connections. This all-in-one solution economically integrates Gigabit technology to remove server bottlenecks, and speed up access to the network backbone. -
Page 7: Switching Technology
The Switch User’s Guide 10Base-T Ethernet standard, designed to raise the data transmission capacity of 10Base-T from 10Mbits/sec to 100Mbits/sec. An important technology incorporated by 100Base-T is its use of the Carrier Sense Multiple Access with Collision Detection (CSMA/CD) protocol, which is the same protocol that 10Base-T uses, because of its ability to work with several different types of cable, including basic twisted-pair wiring. -
Page 8: Hardware Interfac
The Switch User’s Guide environment where traffic on the network and the number of users increase continuously. 1.4.1 Hardware Interface (24) 10/100BASE-TX Fast Ethernet ports + (4) 1000BASE-T Gigabit Ethernet ports or (4) SFP(Mini GBIC) for 4 additional copper or fiber Gigabit connections 24×10/100Mbps Auto-negotiation Fast Ethernet RJ45 ports 4×10/100/1000Mbps Auto-negotiation Gigabit RJ45 ports 4×mini-GBIC ports... -
Page 9: Management Features
The Switch User’s Guide 1.4.5 Management features Web-based management Console management Telnet management SNMP provides V1 /V2 1.4.6 MIBS MIB-Ⅱ(RFC 1213) Bridge MIB (RFC 1493) RMON MIB (RFC1757) 802.1Q VLAN MIB (RFC 2674) IF (Interface)MIB (RFC 2233) 1.5 Panel 1.5.1 Front Panel Components The front panel of the Switch consists of LED indicators, 24 10/100BASE-TX Fast Ethernet ports and 4 10/100/1000BASE-T/SFP (mini-GBIC) combo ports . -
Page 10: Rear Panel
The Switch User’s Guide 1.5.2 Rear Panel Figure 1-3 Rear Panel view of the Switch AC Power Connector: This is a three-pronged connector that supports the power cord. Plug In the female connector of the provided power cord into this connector, and the male into a power outlet. -
Page 11: Technical Specifications
The Switch User’s Guide Status Color Solid Blinking Green The respective port No link. is successfully Connected to an Ethernet network. LINK Orange The respective port The port is The respective port is connected to transmitting or is connected to the The 100Mbps receiving data on 10Mbps Ethernet... -
Page 12: Installation
The Switch User’s Guide Installation The site where you place the Switch may greatly affect its performance. When installing, take the following into your consideration. 2.1 Installation method Follow the guidelines below to install the Switch. Install the Switch in a fairly cool and dry place. See the Technical Specifications for the acceptable temperature and humidity operating ranges. -
Page 13: Connecting The Switch
The Switch User’s Guide Connecting the switch This chapter describes how to connect the Switch to your Fast Ethernet network. 3.1 PC to Switch Figure 3-1 PC to Switch A PC can be connected to the Switch via a two-pair Category 3,4, or5 UTP/STP straight-through cable. - Page 14 The Switch User’s Guide to determine the transmission mode for any new twisted-pair connection: If the attached device does not support auto negotiation or has auto-negotiation disabled, an auto sensing process is initiated to select the speed and set the duplex mode to half-duplex.
-
Page 15: Management
The Switch User’s Guide Management This chapter describes three management methods of the Switch. Web-based management Console management Telnet management SNMP provides v1/v2 4.1 Web-based management The Switch has a Web GUI interface for switch configuration. The Switch can be configured through the Web browser. - Page 16 The Switch User’s Guide NOTE: The factory-default IP Address : 192.168.2.11 Through the Web Management Utility, you do not need to remember the IP Address; select the device shown in the Monitor List of the Web Management Utility to settle the device on the Web browser.
-
Page 17: Console Management
The Switch User’s Guide Figure 4-2 the main page 4.2 Console Management A local console is a terminal or a workstation running a terminal emulation program that is connected directly to the switch via the RS-232 console port on the rear of the switch. - Page 18 The Switch User’s Guide Figure 4-3 1. Type in a name for the connection, select an icon for the connection, and click “OK”.
- Page 19 The Switch User’s Guide Figure 4-4 2. Select the COM port that you are using for this connection and click “OK”. Figure 4-5...
-
Page 20: Telnet Management
The Switch User’s Guide 3. Setup the COM port properties by using the information below and click “OK”. Figure 4-6 NOTE: The console port is set at the factory for the following configuration: Baud rate: 9,600 Data width: 8 bits Parity: none Stop bits: 1 Flow Control: None... - Page 21 The Switch User’s Guide In addition to local terminal mode operation, the Switch supports remote management through Telnet, over the Ethernet LAN network or even over internet. If you are using Microsoft Windows, boot up the computer, go to “Start”-“Run”. Enter ”...
- Page 22 The Switch User’s Guide NOTICE: The factory-default User name is “guest”. Pass word is “guest”...
-
Page 23: Configuration
The Switch User’s Guide Configuration 5.1 System 5.1.1 IP Address Each Switch must be assigned its own IP Address, which is used for communication with an SNMP network manager or other TCP/IP application (for example BOOTP, TFTP). The Switch’s the factory-default IP Address is 192.168.2.11. You can change the factory-default Switch IP address to meet the specification of your networking address scheme. - Page 24 The Switch User’s Guide management stations (NMSs), SNMP agents, Management information base (MIB) and network-management protocol： Network management stations (NMSs)：Sometimes called consoles, these devices execute management applications that monitor and control network elements. Physically, NMSs are usually engineering workstation-caliber computers with fast CPUs, megapixel color displays, substantial memory, and abundant disk space.
- Page 25 The Switch User’s Guide 2. System Options Used to define a logical name to the switch, the location of the switch, and contact person for administration of the switch. This information is used in Enterprise SNMP management, where the network can be very widespread, potentially even in other countries.
- Page 26 The Switch User’s Guide Figure 5-4 Current Communities: show the list in input field Figure 5-5 4. Management Station Configuration A trap manager is a management station (SNMP application) that receives traps (the system alerts generated by the switch). If no trap manager is defined, no traps are issued.
-
Page 27: Password
The Switch User’s Guide Figure 5-7 5.1.3 Password Password is the invaluable tool for the manager to secure the Web Management Switch. You can use this function to change the password. Enter “old password “, “new password”, “confirm password” and click “ok”. Figure 5-8 5.1.4 MAC Address Each Switch must be assigned its own MAC Address. -
Page 28: Management Host Configuration
The Switch User’s Guide Figure 5-10 5.1.6 Management Host Configuration This function is based upon the security of the Switch. If turn on this function then only one IP address of in “Enter Management Host IP “ input field can land the Web management .If turn off this function then all host of the same the network IP address as the Switch ‘IP address can do it. -
Page 29: Saving Parameters
The Switch User’s Guide Figure 5-12 CAUTION: In course of System Upgrade, Please don’t touch The Switch Power. 5.1.8 Saving Parameters This operation will save all your parameters on the switch. After reboot the switch, all the parameters are still valid. If don’t do it the parameters will lose after reboot system. -
Page 30: Load Default
The Switch User’s Guide Figure 5-14 5.1.10 Load Default This operation helps you to reset the device back to the default setting from the factory. Be aware that the entire configuration will be reset, the IP address will be retrieved .The default IP address of 192.168.2.11 will be used. Figure 5-15 CAUTION: This operation will result in all the parameters losing. -
Page 31: Port Management
The Switch User’s Guide Figure 5-16 5.2 Port Management 5.2.1 Port Configuration This page displays the current status of every port. It will display the user’s selection for each port followed by the actual discovered settings. Management Status: Display port status: Enable or Disable, Disable indicates port is off. -
Page 32: Port Statistics
The Switch User’s Guide Figure 5-17 5.2.2 Port Statistics The Port Statistics page provides a view of the current status of every port on the Switch. Pressing the “Reset” button will reset all port counters to zero. -
Page 33: Port Band Restrict
The Switch User’s Guide Figure 5-18 5.2.3 Port Band Restrict The function provides for the administrator In-Band Restrict and Out-Band Restrict of every port on the Switch. Input the range from 64Kbps to 8000Kbps. - Page 34 The Switch User’s Guide Figure 5-19...
-
Page 35: Redundancy
The Switch User’s Guide 5.3 Redundancy 5.3.1 Spanning Tree 1. Spanning Tree Protocol The IEEE 802.1D Spanning Tree Protocol allows for the blocking of links between switches that form loops within the network. When multiple links between switches are detected, a primary link is established. Duplicated links are blocked from use and become standby links. - Page 36 The Switch User’s Guide One switch is elected as the root switch The shortest distance to the root switch is calculated for each switch A designated switch is selected. This is the switch closest to the root switch through which packets will be forwarded to the root. A port for each switch is selected.
- Page 37 The Switch User’s Guide Switch boot Blocking Listening Disabled Learning Forwarding Figure 5-20 STP Port State Transitions You can modify each port state by using management software. When you enable STP, every port on every switch in the network goes through the blocking state and then transitions through the states of listening and learning at power up.
- Page 38 The Switch User’s Guide BPDU for a port and ensures that the BPDU is discarded when its age exceeds the value of the maximum age timer. Forward Delay Timer The amount time spent by a port 15 seconds in the learning and listening states waiting for a BPDU that may return the port to the blocking state.
- Page 39 The Switch User’s Guide NOTICE: The Hello Time cannot be longer than the Max. Age. Otherwise, a configuration error will occur. Max. Age – The Max Age can be from 6 to 40 seconds. At the end of the Max Age, if a BPDU has still not been received from the Root Bridge, your Switch will start sending its own BPDU to all other Switches for permission to become the Root Bridge.
- Page 40 The Switch User’s Guide Figure 5-21 before Applying the STA Rules In this example, only the default STP values are used. Figure 5-21 After Applying the STA Rules The switch with the lowest Bridge ID (switch C) was elected the root bridge, and the ports were selected to give a high port cost between switches B and C.
-
Page 41: Spanning Tree Configuration
The Switch User’s Guide (optional) Gigabit ports (default port cost = 4) on switch A are connected to one (optional) Gigabit port on both switch B and C. The redundant link between switch B and C is deliberately chosen as a 100 Mbps Fast Ethernet link (default port cost = 19). -
Page 42: Link Aggregation
The Switch User’s Guide priority. Path Cost: Specifies the path cost of the port. The switch uses this parameter to help determine which port will become a forwarding port. Lower numbers will be used as forwarding ports first. The range is from 0 to 65535. The default values based on IEEE802.1D are: 10Mb/s = 50-600, 100Mb/s = 10-60, 1000Mb/s = 3-10 Figure 5-24 5.3.3 Link Aggregation... -
Page 43: Security
The Switch User’s Guide port trunk, note that: The ports used in a trunk must all be of the same media type (RJ-45, 100 Mbps fiber, or 1000 Mbps fiber). The ports that can be assigned to the same trunk have certain other restrictions (see below). - Page 44 The Switch User’s Guide with the delivery of time critical data over congested networks. The quality of applications that are dependent on such time critical data, such as video conferencing, can be severely and adversely affected by even very small delays in transmission.
- Page 45 The Switch User’s Guide VLAN, regardless of where they are physically on the network. Logically, a VLAN can be equated to a broadcast domain, because broadcast packets are forwarded to only members of the VLAN on which the broadcast was initiated. NOTICE: 1.
- Page 46 The Switch User’s Guide VLAN tags in packet headers. The tagging feature allows VLAN to span multiple 802.1Q-compliant switches through a single physical connection and allows Spanning Tree to be enabled on all ports and work normally. Some relevant terms: Tagging - The act of putting 802.1Q VLAN information into the header of a packet.
- Page 47 The Switch User’s Guide Figure 5-27 Port VLAN ID Packets that are tagged (are carrying the 802.1Q VID information) can be transmitted from one 802.1Q compliant network device to another with the VLAN information intact. This allows 802.1Q VLAN to span network devices (and indeed, the entire network –...
- Page 48 The Switch User’s Guide VLANs and Trunk Groups In order to use VLAN segmentation in conjunction with port trunk groups, you can first set the port trunk group(s), and then you may configure VLAN settings. If you wish to change the port trunk grouping with VLAN already in place, you will not need to reconfigure the VLAN settings after changing the port trunk group settings.
- Page 49 The Switch User’s Guide...
- Page 50 The Switch User’s Guide Figure 5-30 If you want to show or add or modify the VLAN. Figure 5-31 802.1Q VLAN There are up to 256 configurable VLAN groups. By default when 802.1Q is enabled, all ports on the switch belong to default VLAN (VID 1). The default VLAN cannot be deleted.
- Page 51 The Switch User’s Guide Understand nomenclature of the Switch Tagging and Untagging Every port on an 802.1Q compliant switch can be configured as tagging or untagging. Tagging: Ports with tagging enabled will put the VID number, priority and other VLAN information into the header of all packets that flow into those ports.
- Page 52 The Switch User’s Guide Figure 5-32 Click “OK”. Next to view the following page: Then this page display VALN configuration information of all port...
- Page 53 The Switch User’s Guide Figure 5-33 2. Choose “port2” to enter into VLAN configuration. The default PVID is 1...
- Page 54 The Switch User’s Guide Figure 5-34...
- Page 55 The Switch User’s Guide Figure 5-35 3. Choose the type of link :Access or Trunking. Define PVID for port2 Figure 5-36 4. Trunk configuration: Port2 with tagging enabled will put the VID number, priority and other VLAN information into the header of all packets that out of it. Type a name for the new VLAN.
- Page 56 The Switch User’s Guide Figure 5-38 In the VLAN table choose VLAN which you want to tagging. Click “Add” Figure 5-39 If you want to display one VLAN. Figure 5-40...
-
Page 57: Mac Address Bind
The Switch User’s Guide Figure 5-41 5.4.2 MAC Address Bind This function is based upon for the switch security. When you add one MAC Address is bind with one port. it remains in the switch's address table, regardless of whether the device is physically connected to the switch. -
Page 58: Mac Address Filtering
The Switch User’s Guide Figure 5-43 5.4.3 MAC Address Filtering MAC address filtering allows the switch to drop unwanted traffic. Traffic is filtered based on the destination addresses. In the MAC Address box, enter the MAC address that you want to filter out. Click ”Add”. -
Page 59: Mac Address Learning
The Switch User’s Guide Figure 5-45 5.4.4 MAC Address Learning For every port choose MAC Study’ status: Enable/Disable In the Port box enter the port number. Choose status. Click ”Ok”... -
Page 60: Mac Address Aging Time
The Switch User’s Guide Figure 5-46 5.4.5 MAC Address Aging Time The Aging Time affects the learning process of the Switch. Dynamic forwarding table entries, which are made up of the source and destination MAC addresses and their associated port numbers, are deleted from the table if they are not accessed within the aging time. -
Page 61: Qos
The Switch User’s Guide by the Switch. If the Aging Time is too short however, many entries may be aged out too soon. This will result in a high percentage of received packets whose source addresses cannot be found in the forwarding table, in which case the switch will broadcast the packet to all ports, negating many of the benefits of having a switch. -
Page 62: Qos Configuration
The Switch User’s Guide service required by the packet across a network. Service Level－defines the priority that will be given to a set of classified traffic. You can create and modify service levels. Policy－comprises a set of “rules” that are applied to a network so that a network meets the needs of the business. - Page 63 The Switch User’s Guide Figure 5-48 Figure 5-49 2. VLAN-COS QoS settings allow customization of VLAN ID to Traffic classifiers In the field input VID. Input you want to mapping COS number. To delete an entry from the table, simply select it and click Delete. Figure 5-50...
- Page 64 The Switch User’s Guide Figure 5-51 3.802.1p-priority-CoS QoS settings allow customization of packet priority in order to facilitate delivery of data traffic that might be affected by latency problems. The IEEE 802.1p Priority specification uses 8 priority levels to classify data packets. In 802.1p compliant devices, a tag inserted into the packet header is used to identify the priority level of data packets.
- Page 65 The Switch User’s Guide Figure 5-53 4. Port-COS QoS settings allow customization of VLAN ID to Traffic classifiers In the field input the port number. Input you want to mapping COS number.
- Page 66 The Switch User’s Guide Figure 5-54 5. COS-Queue mapping In the field input COS. Input you want to mapping the Queue number.
- Page 67 The Switch User’s Guide Figure 5-55 6. Queue Management The administrator can modify Queue Policy: WRR/Always High. Figure 5-56 If choose WRR this page Show Queue Weight...
-
Page 68: Multicast
The Switch User’s Guide Figure 5-57 5.6 Multicast 5.6.1 IGMP Snooping Theory Computers and network devices that want to receive multicast transmissions need to inform nearby routers that they will become members of a multicast group. The Internet Group Management Protocol (IGMP) is used to communicate this information. - Page 69 The Switch User’s Guide A host will never send a report when it wants to leave a group (for version 1). A host will send a “leave” report when it wants to leave a group (for version 2). Multicast routers send IGMP queries (to the all-hosts group address: 224.0.0.1) periodically to see whether any group members exist on their sub networks.
-
Page 70: Static Routing Port
The Switch User’s Guide Figure 5-60 5.6.2 Static Routing Port Access this function configuring the port become the member of IGMP Groups of one VLANs In the Port box enter the port number and enter the number of The VLAN (VLD ). Figure 5-61 5.7 Port Analysis 5.7.1 Port Analysis... -
Page 71: Port Mirror
The Switch User’s Guide Figure 5-62 If received the packet’ size less than 64 byte or overstep 1518 byte .The network has the malfunction. 5.7.2 Port Mirror Port Mirroring is a method of monitoring network traffic that forwards a copy of each incoming and/or outgoing packet from one port of a network switch to another port where the packet can be studied. -
Page 72: Storm Restricting
The Switch User’s Guide the Capture port. Egress Port: duplicate the data sent to the source and forward it to the Capture port. Figure 5-62 5.8 Storm Restricting The administrator can use this function to limit the amount of Broadcast or Multicast or Flooded for every port.
