Multiple Registrations - Polycom IP 320 Administrator's Manual

Local Web Server
(if enabled)

Multiple Registrations

Central Configuration file:
sip.cfg
(provisioning
server)
Configuration file:
phone1.cfg
For one-touch voice mail access, enable the "one-touch voice mail"
user preference and bypass instant messages to remove the step of
selecting between instant messages and voice mail after pressing the
Messages key on the SoundPoint IP 430, 450, 550, 560, 650, and
670 and the MSG key on the Polycom VVX 1500 (Instant messages
are still accessible from the Main Menu).
Navigate to http://<phoneIPAddress>/coreConf.htm#us
On a per-registration basis, specify a subscribe contact for solicited
NOTIFY applications, a callback mode (self call-back or another
contact) to call when the user accesses voice mail.
Navigate to http://<phoneIPAddress>/reg.htm
Changes are saved to local flash and backed up to <Ethernet
address>-phone.cfg on the provisioning server. Changes will
permanently override global settings unless deleted through the
Reset Local Config menu selection.
The SoundPoint IP 32x/33x and 430 support a maximum of two registrations,
the SoundPoint IP 450 supports three registrations, the SoundPoint IP 550 and
560 support four, and the SoundPoint IP 650 and 670 and the Polycom VVX
1500 support 6. Up to three SoundPoint IP Expansion Modules can be added
to a single host SoundPoint IP 650 and 670 phone increasing the total number
of registrations to 34. The SoundStation IP 6000 and 7000 supports a single
registration.
Each registration can be mapped to one or more line keys (a line key can be
used for only one registration). The user can select which registration to use for
outgoing calls or which to use when initiating new instant message dialogs.
Configuration changes can be performed centrally at the provisioning server
or locally:
Specify the local SIP signaling port and an array of SIP servers to
register to. For each server specify the registration period and the
signaling failure behavior.
• For more information, refer to
Server <server/>
For up to maximum number of registrations, specify a display name,
a SIP address, an optional display label, an authentication user ID
and password, the number of line keys to use, and an optional array
of registration servers. The authentication user ID and password are
optional and for security reasons can be omitted from the
configuration files. The local flash parameters will be used instead.
The optional array of servers and their associated parameters will
override the servers specified in sip.cfg if non-Null.
• For more information, refer to
Server <server/>
on page A-8.
Registration <reg/>
Configuring Your System
on page A-8 and
on page A-134.
4 - 57
