2) Ring Tone
You can upload a Ring Tone before auto provision, which will be provisioned to the IP phone when using
auto provision feature to configure your IP phones.
NOTE: Ring tone must be wav file, 8k sampling rate, 8 Bit u-law compression. File size should < 200Kbytes.
3) Firmware
You can upload a firmware before auto provision, which will be provisioned to the IP phone when using auto
provision feature to configure your IP phones.
NOTE: the file format must be .fw

10.2.2 Configured Phones

Create New Phone
Enable
Enable auto provisioning for this phone
Phone Type
Choose the Phone Type
MAC Address
Input the MAC address for the phone
New Version
Make sure your phone is with the newest version. If yes, IPPBX will generate the configuration file for IP phone.
Manufacturer
Choose the manufacturer.
DND
Enable or Disable DND.
Call Waiting
Enable or Disable Call Waiting.
Auto Answer
Enable or Disable Auto Answer.
Phone book
Enable or Disable Phone book update .If this option is checked, you must add or upload phone book first.
Ring Tone
Enable or Disable Ring Tone. If this option is checked, you must upload phone book first.
Firmware
Enable or Disable Firmware update. If this option is checked, you must upload firmware first.
Firmware version
If Firmware option is enable, you must input the correct firmware version here.
NOTE: If the firmware version is different from the one you're going to load in IP phone, it will cause
problems in IP phone.
Line
