Python 502 Owner's Manual page 26

➜
The zone number is the number of LED flashes used by the
system to identify that input. The standard input assignments
are listed below, along with spaces to write in any optional
sensors or switches you have had installed.
Zone - Number
of LED Flashes
1
2
3
4
5
6
7
➜
Warn Away responses are not reported by arming or disarming
diagnostics. If you receive a Bypass notification when arming or
a Tamper Alert notification when disarming, look at the LED.
Active or triggered zones will be indicated by a pattern of blinks
by the LED.
© 2006 directed electronics
Description
Instant trigger - often used
for trunk pinswitches
Shock sensor input - a light impact activates warn
away and a heavier impact activates full alarm.
Door switch trigger
Optional sensor inputs for warn away and full
alarm notification.
Ignition trigger
Hood trigger
Optional sensor inputs for warn away and full
alarm notification.
Dealer-Installed
Options
21
