When TIMBRE A/B is selected

7. ZONE (Keyboard zone settings)

Here you can specify keyboard zones to create splits
and velocity switches.
This setting can be changed using the VALUE
switches (or slider), or by holding down the PERF
EDIT switch and pressing a note on the keyboard.
Split Zone
Range Key Zone Bottom
Key Zone Top
Notes in the keyboard area between the Bottom note
and the Top note will sound.
Velocity Zone
Range Vel Zone Bottom
Vel Zone Top
Notes played with a velocity (playing strength)
between the Bottom and Top values will sound.
It is not possible to set the Top value below the Bot-
tom value, nor the Bottom value above the Top value.
8. FILTER (Settings for various
filters)
Damper/Sostenuto
Specifies whether the damper/sostenuto effects will
be applied (ENA) or not (DIS).
Controller
Specifies whether modulation Control such as pitch
bend, vibrato and tremolo will be applied (ENA)
or not (DIS).
Timbre B FX routing
Specifies whether or not the signal from timbre B
will be sent through effect 1(
When TIMBRE 1 to 8 is selected
7. ZONE (Keyboard zone settings)
Here you can specify the range of the note mes-
sages that will be transmitted.
This setting can be changed using the VALUE
switches (or slider), or by holding down the PERF
EDIT switch and pressing a note on the keyboard.
Split Zone
C–1 to G9
C–1 to G9
Note messages will be transmitted for notes played
in the keyboard area between Bottom and Top notes.
Velocity Zone
1 to 127
1 to 127
Note messages will be transmitted for notes played
with a velocity (playing strength) between the Bot-
tom and Top values.
8. FILTER (Settings for various
filters)
You can specify whether or not each of the
SGproX's controllers will transmit MIDI mes-
sages.(
When you operate a controller which is set to
"ENA," the message assigned to that controller will
be transmitted on the MIDI channel of that timbre.
For each controller, refer to Controllers / MIDI
(
p.50).
Performance Edit mode
Range Key Zone Bottom
Key Zone Top
Range Vel Zone Bottom
Vel Zone Top
It is not possible to set the Top value below the Bot-
tom value, nor the Bottom value above the Top value.
p.55).
A.WHEEL1
A.WHEEL2
A.SLIDER1
A.SLIDER2
A.SLIDER3
A.SLIDER4
A.PEDAL
A.PEDAL SW DIS, ENA
DAMPER
AFT.TOUCH
p.55).
C–1 to G9
C–1 to G9
1 to 127
1 to 127
DIS, ENA
DIS, ENA
DIS, ENA
DIS, ENA
DIS, ENA
DIS, ENA
DIS, ENA
DIS, ENA
DIS, ENA
