mode outlined above.

9.3 Selecting Standard or Economy Skimming/Heating Mode

Press the MODE button to select either "Standard" or "Economy" skim-
ming/heating mode. The control panel's indicator on the right side of the
LCD changes to indicate which mode is selected. When an automatic
skimming/heating cycle activates, the LCD screen displays the following
message:
Summer Logic: In warm weather, the water temperature in the hot tub
may exceed the set temperature. This condition may occur due to heat
transference from the main pump and 24-hour circulation pump. If the
water temperature is higher than 95°F (35°C) and rises two degrees
above the set temperature, a "Summer Logic" condition occurs that deacti-
vates the circulation pump and ozonator (if equipped). This safety fea-
ture cannot be altered! The circulation pump and ozonator will remain
off until the water temperature cools to the set temperature (except
between12AM-2AM when the circulation pumps runs for it's mandatory
2-hour "clean-up" cycle). To help prevent a "Summer Logic" condition, it
may be necessary to reduce skimming/heating cycle and/or circulation
pump run times in warm weather.

9.4 Preset Skimming/Heating Cycles

Your hot tub comes with four 30-minute skimming/heating cycles already
programmed in, beginning at 6:00 a.m., noon, 6:00 p.m., and midnight.
You can easily change the start time, or the cycle length for any of these
cycles to suit your individual needs by following the steps in the next sec-
tion.

9.5 Clean-Up "Blow-Out" Cycle

The clean-up cycle is once per day in both Standard and Economy mode at
12:00 PM for two minutes. This is not user programmable. Pump #2 and
pump #3 activate for one minute to circulate any water in the plumbing.
After 1 minute they both go off and pump #1 runs for 1 minute. If the
skimming/heating cycle is also set at 12:00 PM pump #1 will continue to
run for the duration of the cycle.

10.0 Programming Instructions

10.1 Adjusting Time of Day

The Sentry control system remembers the time of day even in the event of a
prolonged power outage. However, it may occasionally be necessary to reset
the time of day. For example: if you are not in the Pacific Time Zone you
Page 28
