- Page 1 The Quantum Plus Portable Whirlpool Spa Owner's Manual www.clearcreekspas.com...
-
Page 2: Model
IMPORTANT SAFETY INFORMATION READ ALL INSTALLATION INSTRUCTIONS Jacuzzi Whirlpool Bath does not recommend spa water temperatures in excess of 40°C (104°F). temperatures in excess of 40°C (104°F) and prolonged periods of use can raise the internal human body tempera- ture excessively and impair the body’s ability to regulate its internal temperature. -
Page 3: Table Of Contents
The Quantum Plus Portable Whirlpool Spa Owner's Manual Model 770000 Installation Instructions __________________________________ 3-6 Inspection and Shipping Claim ______________________________ 3 Unpacking ______________________________________________ 3 Positioning Your Spa ______________________________________ 4 Electrical Requirements ___________________________________ 4 Electrical Precautions _____________________________________ 4 Outdoor Installation _______________________________________ 5... - Page 4 www.clearcreekspas.com www.clearcreekspas.com...
-
Page 5: Installation Instructions
The unique 4.65m (50 sq feet) filtration system, designed by Jacuzzi Whirlpool Bath, allows easy access from inside the spa to both filter cartridges without having to drain the spa or open the skirt door. - Page 6 230 VAC 4.9 AMP 3450 RPM Single Phase 60 Hz. PRODUCT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE. www.clearcreekspas.com (1514 ltrs.) 26 AMPS (340 kg.) www.clearcreekspas.com (443 kg.) (See page 4)
-
Page 7: Inspection And Shipping Claim
Inspection and Shipping Claim Check for shipping damage upon receipt of the spa. Jacuzzi Whirlpool Bath is not responsible for damage to the spa sustained during shipping. If damage is evident before unpacking, see instructions regarding shipping claims on the outside of the carton and immediately file a claim with the carrier. - Page 8 www.clearcreekspas.com PALLET 4" X 4" X 72" BLOCK www.clearcreekspas.com...
-
Page 9: Positioning Your Spa
Important: Read complete instructions before beginning installation. Positioning Your Spa Because your Quantum Plus spa is a portable, you can locate it just about anywhere you wish—on a deck, patio, or even indoors. Just be sure to position it above ground in an area with good drainage and on a level, continuous surface which can support the weight of the spa when filled with water and people;... - Page 10 www.clearcreekspas.com www.clearcreekspas.com...
-
Page 11: Electrical Precautions
Providing natural or forced ventilation of the room will help maintain comfort and minimize mois- ture damage to the building. Jacuzzi Whirlpool Bath is not responsible for damages resulting from excess mois- ture or water spillage. Consult an architect or engineer for aid in designing your indoor installation. - Page 12 www.clearcreekspas.com GRAVEL DRAIN FIELD BOND BAR www.clearcreekspas.com...
-
Page 13: Equipment Set-Up
12. Refer to Water Quality section of the Operating Instructions. Test for water quality; then add treatment chemicals to ensure proper levels. All Jacuzzi Whirlpool Bath spas are factory tested for proper operation and watertight connections prior to shipping. If leaks or other problems are detected,... - Page 14 www.clearcreekspas.com www.clearcreekspas.com...
-
Page 15: Operating Instructions
The control set-up on your Quantum Plus spa is designed to give you fingertip control of the heater, lights, air induction, Water Rainbow and whirlpool/filter pump and blower systems of your unit from inside or outside your spa. Follow the basic control set-up described below to familiarize yourself with the several functions of the control panels located on the top of the spa. - Page 16 www.clearcreekspas.com www.clearcreekspas.com...
-
Page 17: Setting The Time
Basic Control Set-Up • Make sure the circuit breakers are in the ON (1) position. • Locate the HIGH TEMPERATURE SAFETY SWITCHES which are raised buttons on the end of the heater. Push both buttons to be sure it is in the reset mode. - Page 18 TIMER www.clearcreekspas.com PUSH IN ONE TAB FOR EACH TWO HOUR PERIOD OF OPERATION www.clearcreekspas.com...
-
Page 19: Controls
Controls A switch panel giving you convenient control of the whirlpool filter, heater/filter, blower and light is located under the tinted acrylic cover on the rim of the spa. To ensure your safety and allow easy operation, your spa is equipped with two air-activated switches. One, the SYSTEM switch, controls the whirlpool jets, heat, and filtration. - Page 20 HTR/FLTR FILTER (Filter pump and heater will turn on as (Filter pump will necessary to maintain water run continuously; temperature setting.) heater will turn on as necessary to maintain water temperature setting.) www.clearcreekspas.com INDI www.clearcreekspas.com...
-
Page 21: Temperature Control
Temperature Control Turn on the heater by selecting the HTR/FILTER mode on the SYSTEM selector switch. With this selection, you can verify that the spa’s heater is operating by viewing the HEATER ON light on the spa side panel. Set the Temp. Control knob by rotating it to the desired temperature. - Page 22 www.clearcreekspas.com www.clearcreekspas.com...
-
Page 23: Normal Operation
Or, for the total whirlpool effect, you can adjust all jets so they point in a clockwise or counterclockwise direction to circulate the air and water mixture in a circular motion all about the spa. -
Page 24: Filtration
Filtration When you are ready to leave the spa, push the SYSTEM switch button to turn off the whirlpool. Then select the HTR/ FILTER mode. Adjust the TEMP CONTROL knob to the temperature at which you want the water maintained. In this way, the water will be filtered when the heater goes on to maintain the temperature. -
Page 25: Maintenance
These conditions can be corrected with the use of spa treatment chemicals which are available from your Jacuzzi Whirlpool Bath dealer. Such conditions include the following: Foaming: A defoamer is available to minimize foaming of the water. -
Page 26: Disinfecting
cially for spas. The test kit must be of the type which allows you to test for the disinfectant (chlorine) level, pH, and total alkalinity. Make sure, that chemicals used in your spa are especially for spa use, and not for swimming pools, as water quality maintenance of spas and swimming pools is very different. -
Page 27: Balancing Ph
Water Chemistry Disinfecting (continued) return to the 2.0 to 5.0 ppm range before using the spa again. Do not install a rigid cover during this procedure until the disinfectant level is back to normal. High concentra- tions of chlorine or bromine will damage metallic plated finishes if the cover is in place. - Page 28 www.clearcreekspas.com www.clearcreekspas.com...
-
Page 29: Water Level/Drain
Water Level/Drain The water level in the spa must be maintained at its normal level. Evaporation and splashing will cause the water level to drop. When concentrations of impurities from evaporation, water quality chemicals, body oils, perfumes, dirty feet, and winds, etc., accumulate in the spa and cannot be filtered out, it is necessary to drain your spa and refill it with fresh water. - Page 30 housing and replace the basket, reversing the above pro- cedure. Oils will coat the filters, resulting in a reduced flow. To remove such materials, soak the cartridges in a plastic pail containing a commercial filter cleaning solution (available from most pool supply stores). Follow the manufacturer’s instructions for use.
-
Page 31: Automatic Filtration/Maintenance
Automatic Filtration/Maintenance If you plan to be away, you should maintain minimum water quality by running the filter system. To do this, set the timer to turn the system on for at least two hours each day. This will cause the filter system to turn on at a desired time. Set the timer according to instructions on page 8 with the SYSTEM switch OFF. - Page 32 CAUTION: Not winterizing will cause irreversible dam- age (at freezing temperatures) to the pump and/or plumbing lines. Note: If the spa is to be used during winter in a cold climate, see warm climate instructions below. In a warm climate where there are occasional freezing temperatures, follow this procedure: 1.
-
Page 33: Spa Light
With a minimum amount of care and cleaning, your whirlpool spa will look new for years. To clean your spa, simply use a mild non-abrasive liquid detergent, isopropyl alcohol, or commercially prepared spa cleaner. - Page 34 www.clearcreekspas.com www.clearcreekspas.com...
-
Page 35: Troubleshooting Guide
5. Abnormal water usage. 6. Low water flow from jets. *Note: The skills and tools necessary for the safe repair of this spa require the services of qualified service personnel. Contact your Jacuzzi Whirlpool Bath dealer. www.clearcreekspas.com PROBABLE CAUSE A Actuated too rapidly B. - Page 36 www.clearcreekspas.com www.clearcreekspas.com...
- Page 37 10. Motor will not start. *Note: The skills and tools necessary for the safe repair of this spa require the services of qualified service personnel. Contact your Jacuzzi Whirlpool Bath dealer. www.clearcreekspas.com PROBABLE CAUSE E. Dirty filter.
- Page 38 www.clearcreekspas.com www.clearcreekspas.com...
- Page 39 11. Motor stops. 12. Air Blower does not operate. *Note: The skills and tools necessary for the safe repair of this spa require the services of qualified service personnel. Contact your Jacuzzi Whirlpool Bath dealer. www.clearcreekspas.com PROBABLE CAUSE F. Improper or defective wiring.
- Page 40 www.clearcreekspas.com www.clearcreekspas.com...
-
Page 41: Alternate Use Of Water Rainbow
Alternate Use of Water Rainbow Spout as Fill Spout You can use your Water Rainbow spout as a fill spout by permanently plumbing it to a fresh water supply if local codes permit. Local plumbing codes may require the use of an anti-siphon valve for such a connection. Do not interconnect water supply with recirculating system of the spa. - Page 42 www.clearcreekspas.com www.clearcreekspas.com...
- Page 43 USE INSTALLATION INSTRUCTIONS SUPPLIED WITH PRODUCT. Jacuzzi Whirlpool Bath has obtained applicable code (standards) listings generally available on a national basis for products of this type. It is the responsibility of the installer/owner to determine specific local code compliance prior to installation of the product.
