P a c k a g e d T e r m i n a l A i r C o n d i t i o n e r / H e a t P u m p
9 , 0 0 0 - - - 1 5 , 0 0 0 B T U / H R
Packaged Terminal
Thank you for choosing Soleus air conditioner.
For correct operation, please read this owner's manual carefully
before operating the unit and keep it for consultation.
Air Conditioner
OWNER'S MANUAL
S O L E U S A I R C O N D I T I O N E R S
Model
SG-PTAC-09HPDA
SG-PTAC-12HPDA
SG-PTAC-15HPDA
Advertisement
Table of Contents
Related Manuals for Soleus Air SG-PTAC-09HPDA
Summary of Contents for Soleus Air SG-PTAC-09HPDA
-
Page 1: Air Conditioner
S O L E U S A I R C O N D I T I O N E R S Model SG-PTAC-09HPDA SG-PTAC-12HPDA SG-PTAC-15HPDA Thank you for choosing Soleus air conditioner. For correct operation, please read this owner's manual carefully before operating the unit and keep it for consultation. -
Page 2: Table Of Contents
CONTENTS SAFETY CONSIDERATIONS GENERAL INFORMATION UNIT FEATURES ELECTRICAL DATA INSTALLATION HOW TO CONNECT SYSTEM CONFIGURATION OPERATION ..CARE AND CLEANING PREVENTATIVE MAINTENANCE TROUBLESHOOTING LIMITED WARRANTY ......¡ö The figures in this manual may be different with the material objects, please refer to the material objects for reference. -
Page 4: Unit Features
UNIT FEATURES This Premium unit has many exciting features which are different than those found on standard PTAC models. The owner must be familiar with these features in order to fully understand the operation and capability of the unit. • Intelligence – Your Premium unit has an on board computer that utilizes real time diagnostics to prolong the life of your unit. - Page 5 UNIT FEATURES CONTINUED • Unit Configuration – There are many different configuration possibilities, through both dipswitches and the digital keypad, that allow you to configure the unit for your exact application. See section on unit configuration for more details. Following are the configuration selections that have not previously been mentioned: •...
-
Page 6: Electrical Data
ELECTRICAL DATA WARNING ELECTRICAL SHOCK HAZARD Failure to follow this warning could result in personal injury or death and/or property damage DO NOT alter cord or plug or use an extension cord. POWER CONNECTION OPTIONS Appropriate power cord accessory kit is determined by the voltage, and amperage of the branch circuit. The unit does not come with a power cord (or hard wire kit). -
Page 7: Installation
INSTALLATION Proper installation is the responsibility of the installer. Product failure due to improper installation is not covered under the Warranty. CHASSIS INSTALLATION Units are shipped without a sleeve. In applications where unit is a replacement, it is recommended that a GREE or Carrier sleeve be used. - Page 8 RETRO FIT SLEEVE PREPARATIO N IMPORTANT: Inspect wall sleeve thoroughly pr ior to installat ion. Man ufacturer does not assum e responsibilit y for costs or dam ages due to defects in sleeve or for improper installation. WARNING ELECTRI CAL SHOCK HAZARD Failure to follow this warning could result in personal injury or death.
-
Page 9: Install Unit Into Wall Sleeve
INSTALL UNIT INTO WALL SLEEVE 1. Carefully remove shipping tape from the front panel and vent door. See Fig. 9 . 2. Remove shipping screw from the vent door, if present. See Fig. 10. 3. Remove front panel. See Fig. 11. 4. -
Page 10: Auxiliary Controls
AUXILIARY CONTROLS WALL THERMOSTAT TERMINAL IMPORTANT: Only trained, qualified personnel should access electrical panel on unit and install Please contact your local electrical contractor, dealer, or distributor for electrical accessories. assistance. Thermostat Wire Routing Thermostat wire is field supplied. Recommended wire gauge is 18 to 20 gauge solid thermostat wire. NOTE: It is recommended that extra wires are run to unit in case any are damaged during installation. - Page 11 TERMINAL CONNECTIONS The wall thermostat terminal block is located behind the front panel and is easily accessible on front of control panel. Energy Management (24VAC in) Common TYPICAL WALL THERMOSTAT See Note 1 STATUS LED See Note 2 TERMINAL BLOCK NOTES: 1.
-
Page 12: How To Connect
HOW TO CONNECT IMPORTANT: Please read following electrical safety data carefully. WARNING ELECTRICAL SHOCK AND/OR UNIT OPERATION AND DAMAGE HAZARD Failure to follow this warning could result in personal injury or death and/or unit operation and damage. Follow the National Electrical Code (NEC) or local codes and ordinances. For personal safety, this unit MUST BE properly grounded. -
Page 13: System Configuration
SYSTEM CONFIGURATION VENTILATION CONTROL The ventilation control lever is located at left side of unit, behind front panel. NOTE: The vent door shipping hardware must be Vent Control Open removed before using vent control lever. See (Pull lever through label to operate.) Installation Instructions. -
Page 14: Dip Switches
DIP SWITCHES Auxiliary dip switch controls are located behind front panel, through an opening below the control panel. To access, remove front panel. See Fig. 11. Dip switches are accessible without opening the control box. Unit must be powered OFF to effectively change their status. -
Page 15: Keypad Configuration
KEYPAD CONFIGURATION Keypad Configuration Allows further configuration of system to desired application. Changes do not take affect until power is cycled on the unit. To enter Keypad configuration Cycle power to unit. Press and hold the Fan Speed Button and the COOLER button for 5 continuous seconds, within 30 seconds of the unit being powered up. -
Page 16: Operation
OPERATION IMPORTANT: When unit is first started, high humidity conditions can cause condensation to form on discharge grille. Keep doors and windows closed. Room humidity will decrease and moisture will evaporate. TEMP CONTROL FAN, MODE& OPERATION Fig. 22 – PTAC CONTROLS ABOUT THE CONTROLS ON YOUR UNIT NOTE: In case of a power failure, the unit will remember the last programmed settings and will restart to those settings. -
Page 17: Care And Cleaning
CARE AND CLEANING FRONT PANEL AND CASE Turn unit off and disconnect power supply. To clean, use water and a mild detergent. DO NOT use bleach or abrasives. Some commercial cleaners may damage the plastic parts. OUTDOOR COIL Coil on outdoor side of unit should be checked regularly. Unit will need to be removed to inspect dirt build- -up that will occur on the inside of the coil. -
Page 18: Preventative Maintenance
PREVENTATIVE MAINTENANCE Preventative maintenance is essential to proper unit operation, efficiency and longevity. To ensure equipment operates properly, it must be properly maintained. Equipment operation should be checked and verified several times during each year. During regular unit inspection and maintenance, follow the guidelines below: Clean both sides of outdoor coil. -
Page 19: Troubleshooting
TROUBLESHOOTING POSSIBLE CAUSES SOLUTIONS UNIT DOES NOT START • Unit may have become unplugged • Check that plug is plugged securely in wall receptacle. • Fuse may have blown Note :Plug has a test/reset button on it. Make sure that the plug •... -
Page 20: Limited Warranty
LIMITED WARRANTY Soleus International Inc. warrants the accompanying Soleus Air SPTAC series Air Conditioner (SG - PTAC - 09 / 12 / 15 HDPA) to be free of defects in material and workmanship for the applications specified in its operation instruction for the period of labor and parts specified below.
