GA-5BXWL-RH Motherboard
Chapter 1 Introduction
1.1
Features Summary
Form Factor
CPU
Chipset
Memory
I/O Control
Expansion Slots
SATA RAID Controller
On-Board Graphic
On-Board Sound
On-BoardIEEE 1934
12" x 9.6" ATX form factor, 6 layers PCB.
Supports single Intel
Xeon
®
Intel
Dual Core/Quad Core in LGA 775 socket
®
Supports 1066/1333MHz FSB
Intel
X38 MCH Chipset
®
Intel
82801IR ICH9 RAID
®
4 x DDR2 DIMM sockets
Supports up to 8GB 667/800 memory
Dual Channel memory bus
Unbuffered DDR 667/800
ITE IT8718F-S Super I/O
Supports 4 PCI slots 32-Bit/33MHz
Supports 1 PCI-Express x16 slot
Supports 1 PCI-Express x4 slot
Built in Intel
82801IR ICH9 RAID with Software RAID 0,1,10, 5
®
Supports 5 SATA 3.0 Gb/s connectors
Build in Intel
X38 MCH Chipset
®
Relteak
ALC 262 Chipset
®
Support Jack-Sensing
Line Out / 2 front speaker
Line In / 2 rear speaker(by s/w switch)
Mic In / center& subwoofer(by s/w switch)
SPDIF Out /SPDIF In
CD_In
Surround Back speaker (by optional Surround-Kit)
Compliant with Vista Premium
TI TSB43AB23
2 x 1394a box headers
4
processor
®
