GA-5YXS1-RH/GA-5YXS-RH
Xeon
®
USER'S MANUAL
*
The WEEE marking on the product indicates this product must not be disposed of with
user's other household waste and must be handed over to a designated collection point
for the recycling of waste electrical and electronic equipment!!
*
The WEEE marking applies only in European Union's member states.
Processor Motherboard
Xeon
Processor Motherboard
®
Rev. 1001
Advertisement
Table of Contents
Related Manuals for Gigabyte Xeon Processor Motherboard GA-5YXS-RH
Summary of Contents for Gigabyte Xeon Processor Motherboard GA-5YXS-RH
- Page 1 GA-5YXS1-RH/GA-5YXS-RH Xeon Processor Motherboard ® USER’S MANUAL Xeon The WEEE marking on the product indicates this product must not be disposed of with user's other household waste and must be handed over to a designated collection point for the recycling of waste electrical and electronic equipment!! The WEEE marking applies only in European Union's member states.
-
Page 2: Table Of Contents
GA-5YXS1-RH/GA-5YXS-RH Motherboard Item Checklist ... 3 Chapter 1 Introduction ... 4 1-1 Considerations Prior to Installation ... 4 1-2 Features Summary ... 5 1-3 GA-5YXS1-RH/GA-5YXS-RH Motherboard Components ... 7 Chapter 2 Hardware Installation Process... 9 2-1 Installing Processor and CPU Haet Sink ... 9 2-1-1: Installing CPU ... -
Page 3: Item Checklist
Introduction Item Checklist The GA-5YXS-RH motherboard (For GA-5YXS-RH) The GA-5YXS1-RH motherboard (For GA-5YXS1-RH) Serial ATA cable x 4 IDE (ATA133 ) cable x 1 / Floppy cable x 1 I/O Shield Kit CD for motherboard driver & utility GA-5YXS-RH/GA-5YXS1-RH Quick Reference Guide * The items listed above are for reference only, and are subject to change without notice. -
Page 4: Chapter 1 Introduction
2. Damage as a result of violating the conditions recommended in the user manual. 3. Damage due to improper installation. 4. Damage due to use of uncertified components. 5. Damage due to use exceeding the permitted parameters. 6. Product determined to be an unofficial Gigabyte product. -
Page 5: Features Summary
Features Summary Form Factor Chipset Memory I/O Control Expansion Slots SATA RAID Controller On-Board Graphic Internal Connector Rear Panel I/O Hardware Monitor 12” x 9.6” ATX form factor, 6 layers PCB. Supports single Intel Xeon ® ® Intel Xeon Dual-Core/Quad-Core processor in LGA 775 socket ®... - Page 6 GA-5YXS1-RH/GA-5YXS-RH Motherboard Temperature, and On-Board LAN BIOS Additional Features /System Temperature values viewing CPU/System Fan Revolution Detect CPU shutdown when overheat Intel 82566DC & 82573LGbE controllers (GA-5YXS1-RH) ® Intel 82566DC & 82573VGbE controller (GA-5YXS-RH) ® Supports dual Gigabit LAN ports Supports WOL Phoenix BIOS on 8Mb flash ROM Support console redirection...
-
Page 7: Ga-5Yxs1-Rh/Ga-5Yxs-Rh Motherboard Components
GA-5YXS1-RH/GA-5YXS-RH Motherboard Components Intel 3200 Intel ICH9R ITE IT8718F-S XGI Volari Z9s VGA Memory Intel 82566DC GbE Intel 82573L GbE Intel 82573V GbE IDE cable connector Floppy cable connector Front USB2 connector Front USB3 connector SATA1 cable connector SATA2 cable connector SATA3 cable connector SATA4 cable connector SATA5 cable connector... - Page 8 GA-5YXS1-RH/GA-5YXS-RH Motherboard...
-
Page 9: Chapter 2 Hardware Installation Process
Chapter 2 Hardware Installation Process Installing Processor and CPU Haet Sink Before installing the processor and cooling fan, adhere to the following cautions: 1. The processor will overheat without the heatsink and/or fan, resulting in permanent irreparable damage. 2. Never force the processor into the socket. 3. -
Page 10: 2-1-2: Installing Cooling Fan
GA-5YXS1-RH/GA-5YXS-RH Motherboard 2-1-2: Installing Cooling Fan Step 1 Attach the heat sink clip to the processor socket. Step 2 Place the cooling fan on the heat sink. Step 3 Secure the cooing fan with screws. Step 4 Connect processor fan can cable to the processor fanconnector... -
Page 11: Install Memory Modules
Install Memory Modules Before installing the memory modules, please comply with the following conditions: 1. Please make sure that the memory used is supported by the motherboard. It is recommended that memory of similar capacity, specifications and brand be used. 2. -
Page 12: Installation Steps
GA-5YXS1-RH/GA-5YXS-RH Motherboard Installation Steps: 1. Unlock a DIMM socket by pressing the retaining clips outwards.Aling a DIMM on the socket such that the notch on the DIMM exactly match the notch in the socket. 2. Firmly insert the DIMMinto the socket until the retaining clips snap back in place. NOTE!! We recommened you to populate the same device size on each socket and the same DIMM size. -
Page 13: Connect Ribbon Cables, Cabinet Wires, And Power Supply
Hardware Installation Process Connect ribbon cables, cabinet wires, and power supply 2-3-1 : I/O Back Panel Introduction... -
Page 14: Lan Led Description
GA-5YXS1-RH/GA-5YXS-RH Motherboard PS/2 Keyboard and PS/2 Mouse Connector To install a PS/2 port keyboard and mouse, plug the mouse to the upper port (green) and the keyboard to the lower port (purple). Serial Port This connector supports 1 standard COM port, device like modem can be connected to Serial port. VGA Port Connect the monitor cable to this port. -
Page 15: Connectors Introduction & Jumper Setting
Connectors Introduction & Jumper Setting 1. ATX2 2. ATX1 3. IDE1 (IDE cable connector) 4. FDC1 (Floppy cable connector) 5. SATA_1 (SATA cable connector) 6. SATA_2 (SATA cable connector) 7. SATA_3 (SATA cable connector) 8. SATA_4 (SATA cable connector) 9. SATA_5 (SATA cable connector) 10. - Page 16 GA-5YXS1-RH/GA-5YXS-RH Motherboard 1/2) ATX2/1 (24-pin/4-pin ATX power connector) With the use of the power connector, the power supply can supply enough stable power to all the components on the motherboard. Before connecting the power connector, please make sure that all components and devices are properly installed. Align the power connector with its proper location on the motherboard and connect tightly.
- Page 17 Connector Introduction 3 ) IDE1 (IDE cable connector) An IDE device connects to the computer via an IDE connector. One IDE connector can connect to one IDE cable, and the single IDE cable can then connect to two IDE devices (hard drive or optical drive).
- Page 18 GA-5YXS1-RH/GA-5YXS-RH Motherboard 5/ 6/ 7/ 89/10 ) SATA_ 1~6 (Serial ATA cable connectors) SATA 3Gb/s can provide up to 300 MB/s transfer rate. Please refer to the BIOS setting for the SATA 3Gb/s and install the proper driver in order to work properly. 11/ 12 ) USB2/USB3 (USB cable connectors) Be careful with the polarity of the front USB connector.
- Page 19 13 ) HDDBPB1 (SMBUS connector for power supplyr) 14 ) IPMB1 (IPMB connector) Pin No. Definition DETECT HDD LED Pin No. Definition Connector Introduction...
- Page 20 GA-5YXS1-RH/GA-5YXS-RH Motherboard 15/ 16/ 17 ) FAN1 (CPU fan / System fan cable connectors) The cooler fan power connector supplies a +12V power voltage via a 3-pin/4-pin(CPU_FAN) power connector and possesses a foolproof connection design. Most coolers are designed with color-coded power connector wires. A red power connector wire indicates a positive connection and requires a +12V power voltage.
- Page 21 16 ) F_Panel (2X13 Pins Front Panel connector) Please connect the power LED, PC speaker, reset switch and power switch of your chassis front panel to the F_PANEL connector according to the pin assignment above. Pin No. Signal Name FP_PWR_LED P_5V_AUX Pin reomoved ID_LED-...
- Page 22 GA-5YXS1-RH/GA-5YXS-RH Motherboard 20 ) CLR_CMOS1 (Clear CMOS jumper) You may clear the CMOS data to restore its default values by this jumper. Default value doesn’t include the “Shunter” to prevent from improper use this jumper. To clear CMOS, temporarily short 2-3 pin. 1-2 Close: Normal operation (Default setting) 2-3 Close: Clear CMOS...
- Page 23 Jumper Setting 21 ) RECCOVERY1 ( BIOS recovery jumper) 1-2 Close: Enable BIOS Recovery function. 2-3 Close: Normal operation(Default setting)
-
Page 24: Block Diagram
GA-5YXS1-RH/GA-5YXS-RH Motherboard Block Diagram CLOCK GENERATOR ICS9LPR502 PCIE x8 PCIE x8 Slot DMI_PN_0~3 Control Bus PCIE x1 PCIE x8 Slot PCIE x1 PCIE x8 Slot PCI 32/33MHz PCI32/33MHz PCI32/33MHz USB2.0 USB2.0 ROC CARD 16MX16 256M XGI Z9s DDR2 COM1 Connector Connector 82573L GbE for GA-5YXS1-RH;... -
Page 25: Chapter 3 Bios Setup
Chapter 3 BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power ON the computer and press <F2>... -
Page 26: Getting Help
GA-5YXS1-RH/GA-5YXS-RH Motherboard GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. -
Page 27: Main
Main Once you enter Phoenix BIOS Setup Utility, the Main Menu (Figure 1) will appear on the screen. Use arrow keys to select among the items and press <Enter> to accept or enter the sub-menu. System Time The time is calculated based on the 24-hour military time clock. Set the System Time (HH:MM:SS) System Date Set the System Date. - Page 28 GA-5YXS1-RH/GA-5YXS-RH Motherboard SATA Port 1/2/3/4/5/6 The category identifies the types of Serial SATA hard disk from drive 1 to 6 that has been installed in the computer. System will automatically detect HDD type. Note that the specifications of your drive must match with the drive table. The hard disk will not work properly if you enter improper information for this category.
-
Page 29: Advanced Processor Options
Advanced Processor Options Advanced Processor Option This category includes the information of CPU Speed, Processor CPUID and Processor L2 Cache. Setup menu for C1 Enhanced Mode, No Execute Mode Memory Protection, Intel EIST Support, and PECI Interface. C1 Enhanced Mode With enabling C1 Enhanced Mode, all loical processors in the physical processor have entered the C1 state, the processor will reduce the core clock frequency to system bus ratio and VID. - Page 30 GA-5YXS1-RH/GA-5YXS-RH Motherboard Intel EIST Support Select the Power Management desired: Enabled C States Only GV1/GV3 Only Disabled PECI Interface The Platform Environmental Control Interface (PECI Interface) is designed specifically to convey system management information from the processor. It is a proprietary single wire bus between the processor and the chipset or other health monitoring device.
-
Page 31: Advanced
Advanced About This Section: Advanced With this section, allowing user to configure your system for basic operation. User can change the Memory Configuration, PCI Configuration, I/O Configuration, Advanced Chipset Control and Hardware Monitor. Figure 2: Advanced BIOS Setup... -
Page 32: Memory Configuration
GA-5YXS1-RH/GA-5YXS-RH Motherboard Memory Configuration Installed Memory/Available to OS/Used by devices/ DIMM Group 1,2,3,4 Status These category is display-only which is determined by POST (Power On Self Test) of the BIOS. Clear Mem. ECC Err Info Extended RAM Step Enabled Disabled Figure 2-1: Memory Configuration Clear the memory status. -
Page 33: Pci Configuration
PCI Configuration Embedded NIC Onboard LAN1 Control Enabled Disabled LAN1 Option ROM Enabled Disabled Onboard LAN2 Control Enabled Disabled LAN2 Option ROM Enabled Disabled Figure 2-2: PCI Configuration Enable onboard LAN device. (Default setting) Disable this function. Enableing this item to initialize device expansion ROM. Disable this function. - Page 34 GA-5YXS1-RH/GA-5YXS-RH Motherboard PCI Slot 1/2/3/4/5 Option ROM Enabled Enableing this item to initialize device expansion ROM. (Defualt setting) Disabled Disable this function.
-
Page 35: I/O Device Configuration
I/O Device Configuration Serial Port A This allows users to configure serial prot A by using this option. Enabled Enable the configuration (Default setting) Disabled Disable the configuration. Base I/O Address/IRQ 3F8/IRQ4 Set IO address to 3F8/IRQ4. (Default setting) 2F8/IRQ3 Set IO address to 2F8/IRQ3. -
Page 36: Usb Controller
GA-5YXS1-RH/GA-5YXS-RH Motherboard Base I/O Address/IRQ 3F8/IRQ4 Set IO address to 3F8/IRQ4. 2F8/IRQ3 Set IO address to 2F8/IRQ3. (Default setting) 3E8/IRQ4 Set IO address to 3E8/IRQ4. 2E8/IRQ3 Set IO address to 2E8/IRQ3. USB Controller This item allows users to enable or disable the USB device by setting item to the desired value. - Page 37 driver supports AHCI mode. Disabled Disabled this function. SATA RAID Enable Enabled Enabled SATA RAID function. Disabled Disable this function. (Default setting) BIOS Setup...
-
Page 38: Advanced Chipset Control
GA-5YXS1-RH/GA-5YXS-RH Motherboard Advanced Chipset Control Enable Multimedia Timer Enable Multimedia Timer support. (Default setting) Disable this function. Figure 2-4: Advanced Chipset Control... -
Page 39: Hardware Monitor
BIOS Setup Hardware Monitor Figure 2-5: Hardware Monitor CPU / Motherboard Temperature Display the current CPU temperature, Motherboard, and Ambient temperature. Voltage Monitor: DDR1V8, VCC3, VCORE, 0V9, 5V Detect system's voltage status automatically. FAN Monitor: CPU FAN/ Front FAN/ System FAN (RPM) Display the current System 1/2 and CPU fan speed. -
Page 40: Reset Configuration Data
GA-5YXS1-RH/GA-5YXS-RH Motherboard Boot -time Diagnostic When this item is enabled, system will shows Diagnostic status when system boot. Enabled Enable Boot-time Diagnostic. Disabled Disable this function. (Default setting) Reset Configuration Data Reset all configuration data. Do not make any changes. (Default setting) NumLock This option allows user to select power-on state for NumLock. -
Page 41: Security
BIOS Setup Security About This Section: Security In this section, user can set either supervisor or user passwords, or both for different level of password securities. In addition, user also can set the virus protection for boot sector. Figure 3: Security Set User Password You can only enter but do not have the right to change the options of the setup menus. -
Page 42: Set Supervisor Password
GA-5YXS1-RH/GA-5YXS-RH Motherboard Set Supervisor Password You can install and change this options for the setup menus. Type the password up to 6 characters in lengh and press <Enter>. The password typed now will clear any previously entered password from the CMOS memory. You will be asked to confirm the entered password. -
Page 43: Server
BIOS Setup Server Figure 4: Server... -
Page 44: System Management
GA-5YXS1-RH/GA-5YXS-RH Motherboard System Management Figure 4-1: System Management Server Management This category allows user to view the server management features. Including information of BIOS Version. All items in this menu cannot be modified in user’s mode. If any items require changes, please consult your system supervisor. -
Page 45: Console Redirection
Console Redirection BIOS Redirection Port If this option is set to enabled, it will use a port on the motherboard. Serial Port A Serial Port B Disabled Baud Rate This option allows user to set the specified baud rate. Options Terminal Type This option allows user to select the specified terminal type. -
Page 46: Flow Control
GA-5YXS1-RH/GA-5YXS-RH Motherboard Flow Control This option provide user to enable the flow control function. None XON/OFF CTS/RTS Terminal Type This option allows user to select the specified terminal type. This is defined by IEEE. Options Not supported. Software control. Hardware control. (Default setting) VT100, VT100 8bit, PC-ANSI 7bit, VT100+, VT-UTF8... - Page 47 Assert NMI on SERR If thisoption is set to enabled, PCI bus system error (SERR) is enabled and is routed to NMI. Enabled Disabled Post Error Pause If this item is set to enabled, the system will wai for user intervention on critical POST errors. If this item is disabled, the system will boot with no intervention if possible.
-
Page 48: Boot
GA-5YXS1-RH/GA-5YXS-RH Motherboard Boot Boot Priority Order This field determines which type of device the system attempt to boot from after PhoenixBIOS Post completed. Specifies the boot sequence from the available devices. If the first device is not a bootable device, the system will seek for next available device. Key used to view ot configure devices: Up and Down arrows select a device. -
Page 49: Exit
Exit About This Section: Exit Once you have changed all of the set values in the BIOS setup, you should save your changes and exit BIOS setup program. Select “Exit” from the menu bar, to display the following sub-menu. Exit Saving Changes Exit Discarding Changes Load Settup Default Discard Change... -
Page 50: Exit Saving Changes
GA-5YXS1-RH/GA-5YXS-RH Motherboard Exit Saving Changes This option allows user to exit system setup with saving the changes. Press <Enter> on this item to ask for the following confirmation message: Pressing ‘Y’ to store all the present setting values tha user made in this time into CMOS. Therefore, whenyou boot up your computer next time, the BIOS will re-configure your system according data in CMOS. -
Page 51: Exit Discarding Changes
BIOS Setup Exit Discarding Changes This option allows user to exit system setup without changing any previous settings values in CMOS. The previous selection remain in effect. This will exit the Setup Utility and restart your compuetr when selecting this option. - Page 52 GA-5YXS1-RH/GA-5YXS-RH Motherboard Load Settup Default This option allows user to load default values for all setup items. When you press <Enter> on this item, you will get a confirmation dialog box with a message as below:...
-
Page 53: Discard Changes
BIOS Setup Discard Changes This option allows user to load previos values from CMOS for all setup item. When you press <Enter> on this item, you will get a confirmation dialog box with a message as below:... -
Page 54: Save Changes
GA-5YXS1-RH/GA-5YXS-RH Motherboard Save Changes This option allows user to save setup dat ato CMOS. When you press <Enter> on this item, you will get a confirmation dialog box with a message as below: Press [Yes] to save setup daya to CMOS.
