Gigabyte 6WMM Series User Manual

6wmm series pentium ii / iii / celeron processor motherboard
Hide thumbs Also See for 6WMM Series:

Advertisement

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
Model Number:
GA-6WMM
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Aug. 05, 1999
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device ,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection against harmful interference in
residential
installations.
generates,
uses,
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
This
equipment
and
can
radiate
radio

Advertisement

Table of Contents
loading

Summary of Contents for Gigabyte 6WMM Series

  • Page 1 FCC Compliance Statement: This equipment has been tested and found to DECLARATION OF CONFORMITY Per FCC Part 2 Section 2. 1077(a) comply with limits for a Class B digital device , pursuant to Part 15 of the FCC rules. These Responsible Party Name: G.B.T.
  • Page 2: Declaration Of Conformity

    Declaration of Conformity We, Manufacturer/Importer (full address) G.B.T. Technology Träding GMbH Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-6WMM is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive EN 55011...
  • Page 3 6WMM Series II / III / Celeron Pentium Processor Motherboard USER'S MANUAL Pentium II/III/Celeron Processor MAINBOARD REV. 1.3 Third Edition R-13-03-091123...
  • Page 5 How This Manual is Organized This manual is divided into the following sections: 1) Revision History Manual revision information 2) Item Checklist Product item list 3) Features Product information & specification 4) Hardware Setup Instructions on setting up the motherboard 5) Performance &...
  • Page 7: Table Of Contents

    Table Of Content Revision History Item Checklist Summary of Features 6WMM Series Motherboard Layout Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition Performance List P.29 Block Diagram P.30 Suspend to RAM Installation P.31 Memory Installation P.37...
  • Page 8: Revision History

    6WMM Series Motherboard Revision History Revision Revision Note Date Initial release of the 6WMM series motherboard user’s Sep.1999 manual. Second release of the 6WMM series motherboard user’s Oct. 1999 manual Third release of the 6WMM series motherboard user’s Nov. 1999...
  • Page 9: Item Checklist

    Item Checklist Item Checklist þThe 6WMM Series Motherboard þCable for IDE / Floppy device þDiskettes or CD (IUCD) for motherboard utilities oInternal COMB Cable (Optional) oInternal USB Cable (Optional) oCable for SCSI device þ6WMM Series User’s Manual...
  • Page 10: Summary Of Features

    6WMM Series Motherboard Summary of Features 24.4 cm x 24.2 cm Micro ATX SIZE form factor, 4 layers Ÿ Form factor PCB. Motherboard 6WMM series includes 6WMM,6WMM-1 and 6WMM-E Ÿ Pentium II/III/Celeron Processor Ÿ Cache Depend on CPU Ÿ Chipset...
  • Page 11 Summary Of Features Hardware Monitor CPU/Power Supply/Chassis Fan Revolution detect Ÿ CPU Fan Control Ÿ System Voltage Detect Ÿ CPU Overheat Warning Ÿ Chassis Intrusion Detect Ÿ Display Actual Current Voltage Ÿ PS/2 Connector PS/2 Keyboard interface and PS/2 Mouse interface Ÿ...
  • Page 12: 6Wmm Series Motherboard Layout

    6WMM Series Motherboard 6WMM Series Motherboard Layout JP12 PS/2 JP21 JP13 JP17 JP10 JP11 IDE2 IDE1 GMCH 82810 6WMM JP33 Display Cache JP22 Display Cache TV/DFP BAT1 PCI SLOT1 JP30 82801 PCI SLOT2 JP18 JP32 PCI SLOT3 JP31...
  • Page 13: Page Index For Cpu Speed Setup / Connectors / Panel And Jumper

    6WMM Series Motherboard Layout Page Index for CPU Speed Setup / Connectors / Panel and Jumper Page Definition CPU Speed Setup Connectors Game & Audio Port COMA / VGA / LPT Port COMB Port / USB Connector P.10 TV/DFP P.11 PS/2 Keyboard &...
  • Page 14 6WMM Series Motherboard JP32 (Onboard Sound Function Selection) P.26...
  • Page 15 6WMM Series Motherboard Layout JP21 (AMR Selection) P.26 JP11 (STR Enable) P.27 JP18 (Safe mode/Recovery/Normal) P.27 BAT1 P.28...
  • Page 17: Cpu Speed Setup

    CPU Speed Setup CPU Speed Setup The system bus frequency can be switched between 66MHz and 133MHz by adjusting JP17 & JP10. The CPU Frequency is control by BIOS. The CPU speed must match with the frequency RATIO. It will cause system hanging up if the frequency RATIO is higher than that of CPU.
  • Page 18: Connectors

    6WMM Series Motherboard Connectors Game & Audio Port GAME Port Line Out Line In COM A / VGA / LPT Port LPT PORT COM A...
  • Page 19: Comb Port / Usb Connector

    Connectors COM B Port COM B USB Connector Pin No. Definition USB V0 USB D0- USB D0+ USB V1 USB D1- USB D1+ 1 2 3 4...
  • Page 20: Definition

    6WMM Series Motherboard TV/DFP : TV-Out / Digital Flat Panel Daughter card connector. RED LINE PS/2 Keyboard & PS/2 Mouse Connector PS/2 Mouse PS/2 Keyboard PS/2 Mouse/ Keyboard Pin No. Definition Data VCC(+5V) Clock...
  • Page 21: Cpu Cooling Fan Power Connector

    Connectors CPU Cooling FAN Power Connector Pin No. Definition +12V SENSE Power Cooling FAN Power Connector Pin No. Definition +12V SENSE...
  • Page 22: System Cooling Fan Power Connector

    6WMM Series Motherboard System Cooling FAN Power Connector Pin No. Definition +12V SENSE ATX Power Pin No. Definition 3,5,7,13, 15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off)
  • Page 23: Ir/Cir

    Connectors J6 : IR/CIR Pin No. Definition IRRX IRTX CIRRX Floppy Port RED LINE...
  • Page 24: Ide 1(Primary)/ Ide 2(Secondary) Port

    6WMM Series Motherboard IDE1(Primary) , IDE2 (Secondary) Port RED LINE IDE 2 IDE 1 J2 : Ring Power On (Internal Modem Card Wake Up) Pin No. Definition Signal...
  • Page 25: J4 (Wake On Lan)

    Connectors J4 : Wake on LAN Pin No. Definition +5V SB Signal J7 : CD Audio Line In Pin No. Definition CD-L CD-R...
  • Page 26: Jp9 (Tel)

    6WMM Series Motherboard JP9 : TEL: The connector is for Modem with internal voice connector Pin No. Definition Signal-In Signal-Out J8 : AUXIN Pin No. Definition AUX-L AUX-R...
  • Page 27: Jp31 (Usb Port Selection)

    Connectors JP31 : USB Port Selection Front Panel USB Enable Back Panel USB Enable FPUSB(Default) BPUSB 1-3close 3-5close 2-4close 4-6close JP30 : Front Panel USB Port Pin No. Definition 1,4,5,10 3,7,9 USBP0+ USBP0-...
  • Page 28: J17 (Front Panel Jumper)(Optional)

    6WMM Series Motherboard J17 : Front Panel Jumper (Optional) Pin No. Definition HD LED+ GN LED+ HD LED- PWR LED+ RESET SW Soft ON/OFF 10,12 Green SW IR RX IRTX IR Power J22 : Front Audio Jumper (Optional) Pin No.
  • Page 29: Jp33 (Spdif)

    Connectors JP33 : SPDIF(The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dobly Digital decoder.) Pin No. Definition SPD OUT...
  • Page 30: Panel And Jumper Definition

    6WMM Series Motherboard Panel and Jumper Definition Panel Jumper GN (Green Switch) Open: Normal Operation Close: Entering Green Mode GD (Green LED) Pin 1: LED anode(+) Pin 2: LED cathode( ) HD (IDE Hard Disk Active LED) Pin 1: LED anode(+)
  • Page 31: Jp13 (Keyboard Power On)

    Panel and Jumper Definition JP13 : Keyboard Power On Pin No. Definition 1-2 close Keyboard Power on Enabled 2-3 close Keyboard Power on Disabled (Default) JP21 : USB KB/Mouse Wake up Selection Pin No. Definition Enable USB KB / Mouse 1-2 close Wake up 2-3 close Disable USB KB /Mouse...
  • Page 32: Jp6 (Clear Cmos Function)

    6WMM Series Motherboard JP6 : Clear CMOS Function Pin No. Definition 1-2 close Clear CMOS 2-3 close Normal (Default) JP7 : Case Open Pin No. Definition Signal...
  • Page 33: Jp2 (Str Led Connector)

    Panel and Jumper Definition JP2 : STR LED Connector STR LED Connector External. RAM Indicator LED1 JP1 : Top Block Lock Pin No. Definition Open TBL Lock Close UN Lock...
  • Page 34: Jp5 (Timeout Reboot Function)

    6WMM Series Motherboard JP5 : Timeout Reboot Function Pin No. Definition Open Timeout reboot Close No Reboot on timeout J1 : Buzzer Enable Pin No. Definition Open Internal Buzzer Disable Close Internal Buzzer Enable (Default)
  • Page 35 Panel and Jumper Definition JP32 : Onboard Sound Function Selection Pin No. Definition Disable 1-2 close Onboard sound Enable 2-3 close Onboard sound (Default) J21 : AMR Selection Pin No. Definition 1-2close Secondary AMR 2-3close Disable CODEC...
  • Page 36 6WMM Series Motherboard JP11 : STR Enable Pin No. Definition Open STR Disabled (Default) Close STR Enabled JP18 : Normal / Safe mode / Recovery Pin No. Definition 1-2close Normal(Default) 2-3close Safe mode 1-2-3open Recovery...
  • Page 37 Panel and Jumper Definition BAT1 : Battery + Danger of explosion if battery is incorrectly replaced. + Replace only with the same or equivalent type recommended by the manufacturer. + Dispose of used batteries according to the manufacturer’s instructions.
  • Page 38: Performance List

    6WMM Series Motherboard Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.)
  • Page 39: Block Diagram

    Block Diagram Block Diagram INTEL Slot 1 66/100/133 MHz Processor Host Bus 66/100/133MHz Display 66/100/133 MHz GMCH 3.3V SDRAM 82810E Display Cache 100 MHz 14.318/33/48/66 MHz Interface 9248-96 4 PCI PCI Bus 33MHz 82801AA ATA66 IDE Channels AC’97 Link 2 USB Ports COM Ports 3 COM AC’97...
  • Page 40: Suspend To Ram Installation

    6WMM Series Motherboard Suspend to RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 41 Suspend to RAM installation Step 2: (If you want to use STR Function, please set jumper JP11 (Closed.) Pin No. Definition Open STR Disabled (Default) Close STR Enabled Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup.
  • Page 42 6WMM Series Motherboard A.3 How to put your system into STR mode? There are two ways to accomplish this: 1. Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down”...
  • Page 43 Suspend to RAM installation Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 44 6WMM Series Motherboard C. Select the “Advanced” tab and “Standby” mode in Power Buttons. Step 4: Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button.. A.4 How to recover from the STR sleep mode? There are six ways to “wake up”...
  • Page 45 Suspend to RAM installation A.5 Notices : In order for STR to function properly, several hardware and software requirements must be satisfied: A. Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). B.
  • Page 46: Memory Installation

    6WMM Series Motherboard Memory Installation The motherboard has 2 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
