TABLE OF CONTENTS
1.1. PREFACE..........................................................................................................1-1
1.2. KEY FEATURES ...............................................................................................1-1
1.3. PERFORMANCE LIST......................................................................................1-2
1.4. BLOCK DIAGRAM.............................................................................................1-3
1.5. INTRODUCE THE Pentium
1.6. What is AGP ....................................................................................................1-5
2.1. HARDWARE .....................................................................................................2-1
2.2. SOFTWARE......................................................................................................2-2
2.3. ENVIRONMENT................................................................................................2-2
3.1. UNPACKING .....................................................................................................3-1
3.2. MAINBOARD LAYOUT .....................................................................................3-2
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS..............................3-2
3.4. DRAM INSTALLATION .....................................................................................3-6
3.5. CPU SPEED SETUP.........................................................................................3-6
3.6. CMOS RTC & ISA CFG CMOS SRAM.............................................................3-7
3.7. SPEAKER CONNECTOR INSTALLATION......................................................3-8
3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION ....................3-8
3.9. POWER LED CONNECTOR INSTALLATION.................................................3-8
II / III Processors................................................1-4
1
Advertisement
Table of Contents
Related Manuals for Gigabyte Pentium II / III Processors 6ZMM
Summary of Contents for Gigabyte Pentium II / III Processors 6ZMM
-
Page 1: Table Of Contents
6ZMM TABLE OF CONTENTS 1. INTRODUCTION 1.1. PREFACE...1-1 1.2. KEY FEATURES ...1-1 1.3. PERFORMANCE LIST...1-2 1.4. BLOCK DIAGRAM...1-3 1.5. INTRODUCE THE Pentium 1.6. What is AGP ...1-5 2. SPECIFICATION 2.1. HARDWARE ...2-1 2.2. SOFTWARE...2-2 2.3. ENVIRONMENT...2-2 3. HARDWARE INSTALLATION 3.1. UNPACKING ...3-1 3.2. - Page 2 3.10. IDE & ATAPI DEVICE INSTALLATION ...3-8 3.11. PERIPHERAL DEVICE INSTALLATION ...3-8 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION...3-9 4. BIOS CONFIGURATION 4.1. ENTERING SETUP...4-1 4.2. CONTROL KEYS ...4-1 4.3. GETTING HELP ...4-2 4.4. THE MAIN MENU...4-2 4.5. STANDARD CMOS SETUP MENU...4-4 4.6.
- Page 3 6ZMM A.2. YAMAHA SOUND DRIVER INSTALLATION...A-6...
-
Page 5: Introduction
6ZMM 1. INTRODUCTION 1.1. PREFACE Welcome to use the 6ZMM motherboard. It is a Pentium Processor based PC / AT compatible system with AGP/ PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want. -
Page 6: Performance List
24.5 cm x 20 cm Micro-ATX form factor, 4 layers PCB. 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. -
Page 7: Block Diagram
6ZMM Hi-End 1.4. BLOCK DIAGRAM SDRAM 82443ZX CHIPSET 100MHz RAGE PRO AGP Bus 100MHz 100MHz PCI Bus PIIX4 82371EB IDE Bus CHIPSET ISA Bus Ultra DMA/33 IDE Ports YAMAHA L-IN AC-2 L-OUT Game Port 576MHz 39.1 43.4 3.3V EDO/SDRAM DIMM Sockets Host Bus 100MHz 100MHz... -
Page 8: Introduce The Pentium Ii / Iii Processors
Introduction 1.5. INTRODUCE THE Pentium II / III Processors Figure 1:Universal Retention Mechanism & attach Mount Figure 2:OEM Pentium II Processor... -
Page 9: What Is Agp
6ZMM Figure 3: OEM Pentium III Processor 1.6 What is AGP The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. -
Page 11: Specification
2. SPECIFICATION 2.1. HARDWARE Pentium MHz. 242 pins 66/100 MHz slot1 on board. 66/100 MHz system speed. SPEED 66 MHz AGP bus speed. (2X mode 133MHz) 33 MHz PCI-Bus speed. 8 MHz AT bus speed. 2 banks 168 pins DIMM module sockets on board. DRAM MEMORY Use 8 / 16 / 32 / 64 / 128 / 256 MB DIMM module DRAM. -
Page 12: Software
6ZMM 1x Line in Audio Ports 1x Line out 1x Micro in 1x Game Port 2x CD Line in 1x VGA Port. VGA Ports Suspend mode support. GREEN FUNCTION Green switch & Green LED support. IDE & Display power down support. Monitor all IRQ / DMA / Display / I/O events. - Page 13 Specification...
-
Page 15: Hardware Installation
HARDWARE INSTALLATION 3.1. UNPACKING The mainboard package should contain the following: The 6ZMM mainboard. The Retention Mechanism & Attach Mount or Universal Retention Mechanism & Attach Mount USER'S MANUAL for mainboard. Cable set for IDE, Floppy devices. [COMB Cable(Optional)]. CD or diskette for Mainboard ¡ B S ound and ATi VGA Utility. The mainboard contains sensitive electric components, which can be easily damaged by static electricity, so the mainboard should be left in its original packing until it is installed. -
Page 16: Mainboard Layout
6ZMM 3.2. MAINBOARD LAYOUT ISA 1 PCI 3 PCI 2 PCI 1 YAMAHA JP12 PIIX4 BIOS Buzzer JP14 ×Figure 3.1Ø 3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector USB port. IDE1 For Primary IDE port. IDE2 For Secondary IDE port. FLOPPY For Floppy port PS/2... - Page 17 +12V SENSE Power FAN :Power FAN Power Connector Pin No. Function GND. +12V System FAN : System FAN Power Connector Pin No. Function GND. +12V JP7 : Wake on Lan Pin No. Function +5V SB Signal IR : INFRARED Connector (IR) --(Optional) Pin No.
- Page 18 6ZMM JP9 : Onboard Sound Function Selection Pin No. Function 1-2 Close Onboard Sound Function Enabled(Default). 2-3 Close Onboard Sound Function Disabled. JP1 : Keyboard Power On Selection Pin No. Function 1-2 Close Enabled Keyboard power on. 2-3 Close Disabled Keyboard power on (Default). JP14: CLEAR CMOS Function Pin No.
- Page 19 JP6 : For 2X11 PINs Jumper PWR P+P P S P K R Soft PWR: Soft Power Connector Open: Normal Operation Short: Power On/Off RES: Reset Switch Open: Normal Operation Short: For Hardware Reset System P+P P : Power LED PIN 1 : anode (+) PIN 2 : cathode ( ) PIN 3 : cathode ( )
-
Page 20: Dram Installation
6ZMM PIN 2-PIN3 : Short PIN 4 : Data ( ) HD: IDE Hard Disk Active LED PIN 1: LED anode (+) PIN 2: LED cathode ( ) GN: Green Function Switch Open : Normal operation Short : Entering Green Mode GD: Green LED PIN 1 : LED anode (+) PIN 2 : LED cathode ( ) -
Page 21: Cmos Rtc & Isa Cfg Cmos Sram
the DIP SWITCH (SW1) selection to set up the CPU speed for 233 - 650MHz processor. The CPU speed must match with the frequency RATIO. It will cause system hanging up if the frequency RATIO is higher than CPU's. DIP SWITCH (SW) FREQ. -
Page 22: Speaker Connector Installation
