User Manual
6EX
TABLE OF CONTENTS
1.1. PREFACE..........................................................................................................1-1
1.2. KEY FEATURES ...............................................................................................1-1
1.3. PERFORMANCE LIST......................................................................................1-2
1.4. BLOCK DIAGRAM ............................................................................................1-3
1.5. INTRODUCE THE Pentium
1.6 What is AGP ..................................................... 1-6
2.1. HARDWARE .....................................................................................................2-1
2.2. SOFTWARE......................................................................................................2-2
2.3. ENVIRONMENT................................................................................................2-2
3.1. UNPACKING .....................................................................................................3-1
3.2. MAINBOARD LAYOUT .....................................................................................3-2
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS .............................3-3
3.4. DRAM INSTALLATION.....................................................................................3-6
3.5. CPU SPEED SETUP ........................................................................................3-7
3.6. CMOS RTC & ISA CFG CMOS SRAM.............................................................3-8
3.7. SPEAKER CONNECTOR INSTALLATION .....................................................3-8
3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION....................3-8
3.9. POWER LED CONNECTOR INSTALLATION ................................................3-8
II Processor & AGP ...........................................1-4
17
Advertisement
Table of Contents
Related Manuals for Gigabyte 6EX
Summary of Contents for Gigabyte 6EX
-
Page 1: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION 1.1. PREFACE......................1-1 1.2. KEY FEATURES ....................1-1 1.3. PERFORMANCE LIST..................1-2 1.4. BLOCK DIAGRAM ....................1-3 1.5. INTRODUCE THE Pentium II Processor & AGP ...........1-4 1.6 What is AGP ............. 1-6 2. SPECIFICATION 2.1. HARDWARE .....................2-1 2.2. SOFTWARE......................2-2 2.3. - Page 2 Table of Contents 3.10. IDE & ATAPI DEVICE INSTALLATION............3-9 3.11. PERIPHERAL DEVICE INSTALLATION............3-9 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION..........3-9 4. BIOS CONFIGURATION 4.1. ENTERING SETUP ..................4-1 4.2. CONTROL KEYS ....................4-1 4.3. GETTING HELP....................4-2 4.3.1. Main Menu ......................4-2 4.3.2. Status Page Setup Menu / Option Page Setup Menu ........4-2 4.4.
-
Page 3: Introduction
1.INTRODUCTION 1.1. PREFACE Welcome to use the 6EX motherboard. It is a Pentium II Processor based PC / AT compatible system with AGP / PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want. -
Page 4: Performance List
Introduction 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Pentium II processor... -
Page 5: Block Diagram
1 4 . 3 1 8 M H z 1.4. BLOCK DIAGRAM 3 3 M H z 3.3V EDO/SDRAM DIMM Sockets 66MHZ 3 3 M H z 3 3 M H z 2 4 M H z F l o p p y P o r t... -
Page 6: Introduce The Pentium Ii Processor & Agp
Introduction 1.5. INTRODUCE THE Pentium II Processor & AGP Figure 1:Retention Mechanism & attach Mount Figure 2:OEM Pentium II Processor... - Page 7 Figure 3:Heatsink / FAN & Heat sink support for OEM Pentium II Processor Figure 4:Boxed Pentium II Processor & Heat sink support...
-
Page 8: What Is Agp
Introduction 1.6 What is AGP The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. 32-bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing. -
Page 9: Specification
SPECIFICATION 2.1. HARDWARE Pentium II Processor 200 – 633 MHz. 242 pins 66 MHz slot1 on board. 66 MHz system speed. SPEED 66 MHz AGP bus speed. (133MHz 2*mode) 33 MHz PCI-Bus speed. 8 MHz AT bus speed. 3 banks 168 pins DIMM module sockets on board. DRAM MEMORY Use 8 / 16 / 32 / 64 / 128 / 256 MB DIMM module DRAM. -
Page 10: Software
Specification Green switch & ACPI LED support. IDE & Display power down support. Monitor all IRQ / DMA / Display / I/O events. 2M bits FLASH RAM. BIOS Supports Plug & Play, DMI Function. ATX Form Factor, 4 layers PCB. DIMENSION 2.2. -
Page 11: Hardware Installation
HARDWARE INSTALLATION 3.1. UNPACKING The mainboard package should contain the following: The 6EX mainboard. The Retention Mechanism & Attach Mount USER'S MANUAL for mainboard. Cable set for IDE, Floppy & I/O devices. Diskette or CD for Mainboard Utility. The mainboard contains sensitive electric components, which can be easily damaged by static electricity, so the mainboard should be left in its original packing until it is installed. -
Page 12: Mainboard Layout
Hardware Installation 3.2. MAINBOARD LAYOUT × Figure 3.1Ø M PCI 4 Only can use slave device 3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector USB port. For Primary IDE port. For Secondary IDE port. For PS/2 Keyboard / Mouse port. For Floppy port For Serial port2 (COM B). - Page 13 SENSE Slot 1 For Pentium II Processor installed J11 (SPK): SPEAKER Connector Pin No. Function Data J10 (RST) : RESET Switch Open Normal operation Short For Hardware Reset System JP6 (PWR) : POWER ON LED ( PW-LED) Pin No. Function LED anode (+) LED cathode (-) J9 (HD) : Hard Disk active LED (HD-LED)
- Page 14 Hardware Installation J6 (GN) : GN-SW Open Normal Operation Short Enter Green Mode JP5 (Soft PWR) : Soft Power Switch Open Normal Operation Short Power On/Off J13 : System After Ac Back Open Soft Off Short Full On JP1 : Keyboard Power On Selection Pin No.
- Page 15 Soft PWR: Soft Power Connector Open: Normal Operation Short: Power On/Off RES: Reset Switch Open: Normal Operation Short: For Hardware Reset System LED: Power LED PIN 1 : anode (+) PIN 2 : cathode (-) PIN 3 : cathode (-) RKPS: Speaker Connector PIN 1 : VCC PIN 2 : NC...
-
Page 16: Dram Installation
Hardware Installation GD: Green LED PIN 1 : LED anode (+) PIN 2 : LED cathode (-) 3.4. DRAM INSTALLATION The mainboard can be installed with 8 / 16 / 32 / 64 / 128 / 256 MB 168 pins DIMM module DRAM, and the DRAM speed must be 50 or 60 ns for EDO &... -
Page 17: Cpu Speed Setup
3.5. CPU SPEED SETUP The default system bus speed is 66.6MHz. The user can change the DIP SWITCH (SW) selection to set up the CPU speed for 200 - 366MHz processor. The CPU speed must match with the frequency RATIO. It will cause system hanging up if the frequency RATIO is higher than CPU's. -
Page 18: Cmos Rtc & Isa Cfg Cmos Sram
Hardware Installation 3.6. CMOS RTC & ISA CFG CMOS SRAM The mainboard contains RTC & CMOS SRAM on board. They have a power supply from external battery to keep the DATA inviolate & effective. The RTC is a REAL-TIME CLOCK device, which provides the DATE & TIME to system. The CMOS SRAM is used for keeping the information of system configuration, so the system can automatically boot OS every time. -
Page 19: Ide & Atapi Device Installation
connected to PWR of mainboard in correct direction. 3.10. IDE & ATAPI DEVICE INSTALLATION There are two-Enhanced PCI IDE ports (IDE1, IDE2) on board, which following ATAPI standard SPEC. Any one IDE port can connected to two ATAPI devices (IDE Hard Disk, CD-ROM & Tape Driver), so total four ATAPI devices can exist in a system.
