Summary of Contents for Gigabyte 6EMM

  • Page 1: Table Of Contents

    6EMM TABLE OF CONTENTS 1. INTRODUCTION 1.1. PREFACE......................1-1 1.2. KEY FEATURES ....................1-1 1.3. PERFORMANCE LIST..................1-2 1.4. BLOCK DIAGRAM ....................1-3 1.5. INTRODUCE THE Pentium II Processor & AGP ...........1-4 1.6 What is AGP ............. 1-6 2. SPECIFICATION 2.1. HARDWARE .....................2-1 2.2. SOFTWARE......................2-2 2.3.
  • Page 2 Table Of Contents 3.10. IDE & ATAPI DEVICE INSTALLATION............3-6 3.11. PERIPHERAL DEVICE INSTALLATION............3-7 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION..........3-7 4. BIOS CONFIGURATION 4.1. ENTERING SETUP ..................4-1 4.2. CONTROL KEYS ....................4-1 4.3. GETTING HELP....................4-2 4.4. THE MAIN MENU....................4-2 4.5. STANDARD CMOS SETUP MENU ..............4-4 4.6.
  • Page 3: Introduction

    6EMM INTRODUCTION 1.1. PREFACE Welcome to use the 6EMM motherboard. It is a Pentium II Processor based PC / AT compatible system with AGP/ PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want.
  • Page 4: Performance List

    Introduction 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Pentium II processor...
  • Page 5: Block Diagram

    6EMM 1.4. BLOCK DIAGRAM 6 6 M H z 3 . 3 V E D O / S D R A M D I M M S o c k e t s H o s t B u s...
  • Page 6: Introduce The Pentium

    Introduction 1.5. INTRODUCE THE Pentium II Processor & AGP Figure 1:Retention Mechanism & attach Mount Figure 2:OEM Pentium II Processor...
  • Page 7 6EMM Figure 3:Heatsink / FAN & Heat sink support for OEM Pentium II Processor Figure 4:Boxed Pentium II Processor & Heat sink support...
  • Page 8: What Is Agp

    Introduction 1.6 What is AGP The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. 32-bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing.
  • Page 9: Specification

    6EMM SPECIFICATION 2.1. HARDWARE Pentium II processor 200 – 633 MHz. 242 pins 66 MHz slot1 on board. 66 MHz system speed. SPEED 66 MHz AGP bus speed. (133MHz 2*mode) 33 MHz PCI-Bus speed. 8 MHz AT bus speed. 2 banks 168 pins DIMM module sockets on board.
  • Page 10: Software

    Specification Suspend mode support. GREEN FUNCTION Green switch & ACPI LED support. IDE & Display power down support. Monitor all IRQ / DMA / Display / I/O events. 2M bits FLASH RAM. BIOS Supports Plug & Play, DMI Function. Micro ATX Form Factor, 4 layers PCB. DIMENSION 2.2.
  • Page 11: Hardware Installation

    6EMM HARDWARE INSTALLATION 3.1. UNPACKING The mainboard package should contain the following: The 6EMM mainboard. The Retention Mechanism & Attach Mount USER'S MANUAL for mainboard. Cable set for IDE, Floppy devices. CD for Mainboard ¡ B S ound and VGA Utility.
  • Page 12: Quick Reference For Jumpers & Connectors

    COM A SLOT3 SLOT1 AUDIO PS/2 YAMAHA PCI2 PCI1 ATX POWER INTEL 443EX 3D RAGE PRO AGP 2X 6EMM PIIX4 BANK0 BANK1 SLOT4 SLOT2 IDE2 FLOPPY BIOS IDE1 QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector USB port. IDE1 For Primary IDE port.
  • Page 13 6EMM J9 : System After Ac Back Pin No. Function Open Soft Off Close Full On JP1 : Keyboard Power On Selection Pin No. Function 1-2 Close Enabled Keyboard power on. 2-3 Close Disabled Keyboard power on. J10 : Audio Function Selection Pin No.
  • Page 14 Hardware Installation RES: Reset Switch Open: Normal Operation Short: For Hardware Reset System LED: Power LED PIN 1 : anode (+) PIN 2 : cathode (-) PIN 3 : cathode (-) SPKR: Speaker Connector PIN 1 : VCC PIN 2 : NC PIN 3 : NC PIN 4 : Data HD: IDE Hard Disk Active LED...
  • Page 15: Dram Installation

    6EMM 3.4. DRAM INSTALLATION The mainboard can be installed with 8 / 16 / 32 / 64 / 128 / 256 MB 168 pins DIMM module DRAM, and the DRAM speed must be 50 or 60 ns for EDO &...
  • Page 16: Cmos Rtc & Isa Cfg Cmos Sram

    Hardware Installation The CPU is a sensitive electric component and it can be easily damaged by static electricity, so users must keep it away from metal surface when the CPU is installed onto mainboard. ¬ Note: We don’t recommend you to setup up your system speed up to 75 or 83 MHz because they, are not the standard spec.
  • Page 17: Peripheral Device Installation

    6EMM 3.11. PERIPHERAL DEVICE INSTALLATION After the I/O device installation and jumpers setup, the mainboard can be mounted into the case and fixed by screw. To complete the mainboard installation, the peripheral device could be installed now. The basic system needs a display interface card.
