Socket 370 dual processors motherboard

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
Model Number:
GA-6EXDR
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
May. 20, 2001
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection
against
residential
installations.
generates,
uses,
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
harmful
interference
This
equipment
and
can
radiate
in
radio

Advertisement

Table of Contents
loading

Summary of Contents for Gigabyte GA-6EXDR

  • Page 1 Model Number: GA-6EXDR frequency energy, and if not installed and used Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), in accordance with the instructions, may cause Class B Digital Device Supplementary Information: harmful interference to radio communications.
  • Page 2 Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-6EXDR is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive...
  • Page 3 6EXDR Socket 370 Dual Processors Motherboard USER'S MANUAL Socket 370 Dual Processors Motherboard REV. 1.0 First Edition R-10-01-010430...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: 1) Revision History Manual revision information 2) Item Checklist Product item list 3) Features Product information & specification 4) Hardware Setup Instructions on setting up the motherboard 5) Performance &...
  • Page 7: Table Of Contents

    Table Of Content Revision History Item Checklist Summary of Features 6EXDR Motherboard Layout Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition Performance List P.26 Block Diagram P.27 P.28 Advanced Networking Services for Windows NT* 4 and Windows 2000 (Teaming) Memory Installation P.34 DIMM QVL List...
  • Page 8: Revision History

    6EXDR Motherboard Revision History Revision Revision Note Date Initial release of the 6EXDR motherboard user’s manual. Apr. 2001 The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners.
  • Page 9: Item Checklist

    Item Checklist Item Checklist The 6EXDR motherboard Cable for SCSI U160 / ATA33 / Floppy device Diskettes or CD (Driver CD) for motherboard driver & utility 6EXDR user’s manual Internal COM B Cable (Optional) Internal Chassis Cable (Optional)
  • Page 10: Summary Of Features

    6EXDR Motherboard Summary Of Features Form Factor 30.4 cm x 24.3 cm ATX size form factor, 6 layers PCB. 250 watt or higher power supply required Dual ZIF PGA370 Socket Intel Pentium III FC-PGA Two onboard VRMs (VRM 8.4 spec V2.5) 100/133 MHz Front Side Bus support Chipset ServerWorks ServerSet...
  • Page 11 Summary of Features On-Board LAN Integrated two Intel 82559 LAN controllers 10/100Mbps data transfer rate per controller 3 pin Wake on LAN (S1 and S5 state) Adapter Fault Tolerance (AFT) and Adaptive Load Balancing (ALB) Hardware Monitor CPU 1/ CPU 2 fan revolution detect CPU 1/ CPU 2 temperature detect System voltage detect CPU overheat shutdown detect...
  • Page 12: 6Exdr Motherboard Layout

    6EXDR Motherboard 6EXDR Motherboard Layout PS/2 ATX Power PGA 370 CPU 1 RCC-NB6635 6EXDR PGA 370 CPU 2 JP12 64 PCI 1 82559 JP11 JP10 64 PCI 2 LSA0723 82559 PCI1 RCC-IB6566 PCI2 Super I/O Rage BAT1 USB2 COM2 BRIGHT...
  • Page 13: Page Index For Cpu Speed Setup/Connectors/Panel And Jumper Definition

    6EXDR Motherboard Layout Page Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors P.11 ATX Power P.11 COM 1 / VGA / LPT Port P.11 COM 2 Port P.12 Floppy Port P.12 IDE 1(Primary) / IDE 2(Secondary) Port P.13 J1 (CPU1 Fan) P.13...
  • Page 14: Cpu Speed Setup

    6EXDR Motherboard CPU Speed Setup CPU. ( The system bus speed is depended on Supported 100,133MHz). The user can change the DIP switch (SW1) and Jumper (JP9) selection to set up the CPU speed for 600MHz – 1GHz processor. The CPU speed must match with the frequency ratio. It will cause system hanging up if the frequency ratio is higher than that of CPU.
  • Page 15 CPU Speed Setup  !!! 600/100MHz FSB 1. Pentium  Pentium !!! 800/133MHz FSB You can change the DIP switch (SW1) selection to set up the CPU Speed. The CPU frequency RATIO is 6. The FSB is 100MHz, than CPU speed is 600MHz.
  • Page 16 6EXDR Motherboard 4. Pentium  !!! 750/100MHz FSB  !!! 1GHz/133MHz FSB Pentium 5. Pentium  !!! 800/100MHz FSB  !!! 850/100MHz FSB 6. Pentium  !!! 533/133MHz FSB 7. Pentium...
  • Page 17 CPU Speed Setup 8. Pentium  !!! 600/133MHz FSB...
  • Page 18: Connectors

    6EXDR Motherboard Connectors ATX Power Pin No. Definition 3,5,7,13, 15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off) Please note: AC power cord should only be connected to your power supply unit after ATX power cable and other related devices are firmly connected to the mainboard.
  • Page 19: Com 2 Port

    Connectors COM 2 Port COM 2 FDD 1 : Floppy Port FDD1 Red Line...
  • Page 20: Ide1 (Primary), Ide2 (Secondary) Port

    6EXDR Motherboard IDE1 (Primary), IDE2 (Secondary) Port Red Line IDE1 IDE2 J1 : CPU1 Fan Pin No. Definition Control +12V SENSE...
  • Page 21: J2 (Panel Fan)

    Connectors J2 : Panel Fan Pin No. Definition Control +12V SENSE J4 : Wake On LAN Pin No. Definition +5V SB Signal...
  • Page 22: J5 (Ring Power On)

    6EXDR Motherboard J5 : Ring Power On (Internal Modem Card Wake Up) Pin No. Definition Signal J6 : CPU2 Fan Pin No. Definition Control +12V SENSE...
  • Page 23: J7 (Power Fan1)

    Connectors J7 : Power Fan 1 Pin No. Definition Control +12V SENSE J19 : System Interface Connector...
  • Page 24: J22 (Power Fan2)

    6EXDR Motherboard J22 : Power Fan 2 Pin No. Definition Control +12V SENSE LAN Connector LAN1 LAN2 (LAN Active LED) 1 – Yellow LED (LAN Active LED) 2 – Green LED (LAN Link LED) 100Mb--Light 10 Mb--Blind...
  • Page 25: Ps/2 Keyboard & Ps/2 Mouse Connector

    Connectors PS/2 Keyboard & PS/2 Mouse Connector PS/2 PS/2 Mouse Mouse / Keyboard Pin No. Definition Data Power Clock PS/2 Keyboard Please note: This mainboard supports standard PS/2 keyboard and PS/2 mouse interface connector. SCSI 1 (Primary), SCSI 2 (Secondary) Port SCSI Port...
  • Page 26: Usb1: Usb 1 Connector

    6EXDR Motherboard USB1: USB 1 Connector Pin No. Definition USB V0 USB D0- USB D0+ USB V1 USB D1- 5 6 7 8 USB D1+ Please note: Before you connect your device(s) into USB connector(s), please make sure your device(s) has a standard USB interface like, USB keyboard, mouse, scanner, zip, buzzer…...
  • Page 27: Panel And Jumper Definition

    Panel and Jumper Definition Panel And Jumper Definition J3 : 2x11 Pins Jumper P+ P− P− S P K GN (Green Switch) Open: Normal Operation Close: Entering Green Mode GD (Green LED) Pin 1: LED anode(+) Pin 2: LED cathode(−) HD (IDE Hard Disk Active LED) Pin 1: LED anode(+) Pin 2: LED cathode(−)
  • Page 28: Jp1 (Fireware White Protect)

    6EXDR Motherboard JP1 : Fireware Write Protect Disable Enable (Default) Pin No. Definition Open Disable (Default) Close Enable Please note: To flash/upgrade BIOS on this MB JP1 must be opened. We recommend JP1 to be set to “close”, whenever user is not try to flash/upgrade the BIOS. JP2 : VGA Enable jumper Disabled Enabled...
  • Page 29: Jp3 (Scsi Enable Jumper)

    Panel and Jumper Definition JP3 : SCSI Enable jumper Disabled Enabled (Default) Pin No. Definition Onboard SCSI 1-2 close Enable (Default) Onboard SCSI 2-3 close Disable JP4 : SCSI TERM A Disable Enable (Default) Pin No. Definition Close Enable (Default) Open Disable...
  • Page 30: Jp6 (Scsi Term B)

    6EXDR Motherboard JP6 : SCSI TERM B Disable Enable (Default) Pin No. Definition Close Enable (Default) Open Disable JP10 : LAN1 Enable Selection Disabled Enabled (Default) Pin No. Definition Onboard LAN1 close Enabled (Default) Onboard LAN1 close Disabled...
  • Page 31: Jp11 (Lan2 Enable Selection)

    Panel and Jumper Definition JP11 : LAN2 Enable Selection Disabled Enabled (Default) Pin No. Definition Onboard LAN2 1-2 close Enabled (Default) Onboard LAN2 2-3 close Disabled JP12 : Case Open Pin No. Definition Signal...
  • Page 32: Sw2 : Pole1_On Password Enable/ Pole4_On Cmos Clear

    6EXDR Motherboard SW2 : Pole1_ON Password Enable/ Pole4_ON CMOS Clear Pin No. Definition Pole4_Off CMOS Clear Pole3_ON NC Pole2_ON NC Pole1_ON Password Enable BAT1 : Battery CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer.
  • Page 33: Performance List

    Performance List Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) •...
  • Page 34: Block Diagram

    6EXDR Motherboard Block Diagram Coppermine I Coppermine II Host BUS SDRAM Registered DIMM with ECC 160MB/s /One CH 64bit / 66Mhz Channel CNB30LE 64bit PCI SLOT x 2 Channel 4GB Max. LSI 53C1010-66 Dual Ch Ultra160 SCSI Controller 32bit PCI SLOT x 2 32bit / 33Mhz Ati Rage XL VGA Port...
  • Page 35: Advanced Networking Services For Windows Nt* 4 And Windows 2000 (Teaming)

    Advanced Networking Services Advanced Networking Services for Windows NT* 4 and Windows 2000 (Teaming) Please make sure the Intel LAN Adapter teaming driver Install complete. refer to page 62) 1. Intel LAN Adapter Teaming Adapter Teaming Installation Notes for the PRO/100 S Server Adapter Under Windows NT 4.0 and Windows 2000.
  • Page 36 6EXDR Motherboard 2. Adapter Fault Tolerance (AFT) 2.1 OverView A method of safeguarding the network link to the server switch or network service using transparent backup links. Adapter Fault Tolerance (AFT) requires two adapters and an intelligent software agent that continuously monitors both links. If any component of one link fails, the redundant link takes over within seconds—typically, without users (connected via a hub or switch) even noticing the exchange.
  • Page 37 Advanced Networking Services 3. Adaptive Load Balancing (ALB) 3.1 Overview Also known as asymmetric port aggregation—is a method of ensuring consistent high server throughput and transparent backup connections by using multiple network interface cards and balancing the data transmissions across them. As many as four Intel® server adapters, connected to a switch, can be configured to work together as a "team"...
  • Page 38 6EXDR Motherboard 4. General Instructions 4.1 Perform Teaming In Windows NT4.0 Or Windows 2000 Setup Intel PROSet II. Then, double-click on the Intel (R) PROSet II icon in the Control Panel will launch the PROSet utility. 2. Create a new team .
  • Page 39 Advanced Networking Services 3. At the Teaming Wizard dialog, select the type of team you want to create and click Next. 4. Add a check in the checkbox for each adapter you want as a part of the team and click Next.
  • Page 40 6EXDR Motherboard 5. Click OK to close PROSet. II You should notice a new listing in the Network control panel, which is the team you have created. 6. After the team created, a Intel® Advanced Network Services Virtual Adapter will appear on Network in the Control Panel.
  • Page 41: Memory Installation

    Memory Installation Memory Installation The motherboard has 4 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 42: Page Index For Bios Setup

    6EXDR Motherboard Page Index for BIOS Setup Page Main P.37 Advanced P.39 Chipset P.49 PCIPnP P.50 Power P.52 Boot P.53 Security P.54 Exit P.59...
  • Page 43 BIOS Setup BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power ON the computer and press <Del>...
  • Page 44: Main

    6EXDR Motherboard GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 45 BIOS Setup • • • • Chipset This setup page includes all the items of chipset special features. • • • • PCIPnP This setup page includes all the configurations of PCI & PnP ISA resources. • • • • Power This setup page includes all the items of Green function features.
  • Page 46: Advanced

    6EXDR Motherboard Advanced BIOS SETUP UTILITY Main Advanced Chipset PCIPnP Power Boot Security Exit Setup Warning Setting items on this screen to incorrect values may cause the system to malfunction! Standard Boot Settings SuperIO Configuration Floppy Configuration IDE Configuration Event Log Configuration System Health Monitoring Hardware Remote Access Configuration Select Screen...
  • Page 47 BIOS Setup • • • • Quick Boot Disabled Disabled Quick Boot Function. Enabled Quick Boot Function. (Default Value) Enabled • • • • Boot Up Num-Lock Keypad is number keys. (Default Value) Keypad is arrow keys. • • • • PS/2 Mouse Support Enabled PS/2 Mouse Support.
  • Page 48 6EXDR Motherboard • • • • Serial Port 1 Address Enable onBoard Serial port 1 and address is 3F8. (Default Value) Enable onboard Serial port 1 and address is 2F8. Enable nboard Serial port 1 and address is 3E8. Enable nboard Serial port 1 and address is 2E8. Disabled Disable nboard Serial port 1.
  • Page 49 BIOS Setup • • • • Parallel Port Mode Using Parallel port as Enhanced Parallel Port. Using Parallel port as Extended Capabilities Port. (Default Value) Normal Normal Operation. Bi-Directional Using Parallel port as Bi-Directional. • • • • ECP Mode DMA Channel Set Parallel Port DMA is 3.
  • Page 50 6EXDR Motherboard • • • • Floppy Drive A / Floppy Drive B The category identifies the types of floppy disk drive A or drive B that has been installed in the computer. Disabled No floppy drive installed 360KB, 5¼”. 5¼”...
  • Page 51 BIOS Setup BIOS SETUP UTILITY Advanced Primary IDE Master (Primary IDE Slave, Secondary IDE Master, Secondary IDE Slave) Device: Not Detected Type [Auto] LBA/Large Mode [Auto] Block(Multi-Sector Transfer) [Auto] PIO Mode [Auto] DMA Mode [Auto] S.M.A.R.T. [Auto] 32 Bit Data Transfer [Enabled] Select Screen Select Item...
  • Page 52 6EXDR Motherboard PIO Mode Auto Set PIO Mode to Auto. Set PIO Mode to 0. Set PIO Mode to 1. Set PIO Mode to 2. Set PIO Mode to 3. Set PIO Mode to 4. DMA Mode Auto Set DMA Mode to Auto. SWDMA 0~2 Set DMA Mode to SWDMA 0~2.
  • Page 53 BIOS Setup BIOS SETUP UTILITY Advanced Event Log Configuration Event Logging [Enabled] Clear All Event Logs [No] Select Screen Select Item Change Field Select Field General Help Save and Exit Exit V02.04 (C) Copyright 1985-2000, American Megatrends Inc. Figure 2-5: Advanced •...
  • Page 54 6EXDR Motherboard BIOS SETUP UTILITY Advanced System Health Monitoring ACPI Shut Down Temp. [Disabled] CPU Temp. Alarm [Disabled] CPU1 Fan Fail Alarm [No] CPU2 Fan Fail Alarm [No] Power Fan1 Fail Alarm [No] Power Fan2 Fail Alarm [No] System Fan Fail Alarm [No] Reset Case Open Status [No]...
  • Page 55 BIOS Setup • • • • CPU Temp. Alarm Normal Operation. (Default value) Disabled 60°C / 140°F Monitor CPU Warning Temp. at 60°C / 140°F 70°C / 158°F Monitor CPU Warning Temp. at 70°C / 158°F 80°C / 176°F Monitor CPU Warning Temp. at 80°C / 176°F 90°C / 194°F Monitor CPU Warning Temp.
  • Page 56 6EXDR Motherboard BIOS SETUP UTILITY Advanced Configure Remote Access type and parameters Remote Access [Disabled] Select Screen Select Item Change Field Select Field General Help Save and Exit Exit V02.04 (C) Copyright 1985-2000, American Megatrends Inc. Figure 2-7: Advanced • • • • Remote Access Disable this Function.
  • Page 57: Chipset

    BIOS Setup Chipset BIOS SETUP UTILITY Main Advanced Chipset PCIPnP Power Boot Security Exit Memory Scrubbing [Disabled] ISA IO Cycle Delay [1.5 BCLK] MPS 1.4 Support [Enabled] Select Screen Select Item Change Field Select Field General Help Save and Exit Exit V02.04 (C) Copyright 1985-2000, American Megatrends Inc.
  • Page 58: Pcipnp

    6EXDR Motherboard PCIPnP BIOS SETUP UTILITY Main Advanced Chipset PCIPnP Power Boot Security Exit Plug & Play O/S [No] Reset Config Data [No] PCI Latency Timer [64] Palette Snooping [Disabled] USB Function [Enabled] Legacy USB Support [Auto] Select Screen Select Item Change Field Select Field General Help...
  • Page 59 BIOS Setup • • • • PCI Latency Timer Set PCI Latency Timer is 32. Set PCI Latency Timer is 64. (Default Value) Set PCI Latency Timer is 96. Set PCI Latency Timer is 128. Set PCI Latency Timer is 160. Set PCI Latency Timer is 192.
  • Page 60: Power

    6EXDR Motherboard Power BIOS SETUP UTILITY Main Advanced Chipset PCIPnP Power Boot Security Exit ACPI Aware O/S [Yes] Power Management [Disabled] System After AC Back [Off] Select Screen Select Item Change Field Select Field General Help Save and Exit Exit V02.04 (C) Copyright 1985-2000, American Megatrends Inc.
  • Page 61: Boot

    BIOS Setup Boot BIOS SETUP UTILITY Main Advanced Chipset PCIPnP Power Boot Security Exit Boot Device Priority Hard Disk Drivers ATAPI CDROM Drivers Select Screen Select Item Enter Go To Sub Screen General Help Save and Exit Exit V02.04 (C) Copyright 1985-2000, American Megatrends Inc. Figure 6: Boot BIOS SETUP UTILITY Boot...
  • Page 62: Security

    6EXDR Motherboard Security BIOS SETUP UTILITY Main Advanced Chipset PCIPnP Power Boot Security Exit Supervisor Password : Not Installed User Password Not Installed Change Supervisor Password Change User Password Clear User Password Boot Sector Virus Protection [Disabled] Select Screen Select Item Enter Go to Sub Screen General Help...
  • Page 63 BIOS Setup BIOS SETUP UTILITY Main Advanced Chipset PCIPnP Power Boot Security Exit Supervisor Password : Not Installed User Password Not Installed Change Supervisor Password Change User Password Clear User Password Boot Sector Virus Protection [Disabled] Enter New Password: Select Screen Select Item Enter Go to Sub Screen...
  • Page 64 6EXDR Motherboard When you select “ Change Supervisor Password ” this function, the following message will appear at the center of the screen to assist you in creating a password. Type the password, up to six characters, and press <Enter>. You will be asked to confirm the password.
  • Page 65 BIOS Setup BIOS SETUP UTILITY Main Advanced Chipset PCIPnP Power Boot Security Exit Supervisor Password : Installed User Password Not Installed Change Supervisor Password User Access Level [Full] Change User Password Clear User Password Enter New Password: Password Check [Setup] Boot Sector Virus Protection [Disabled] Select Screen...
  • Page 66 6EXDR Motherboard When you select “ Change User Password ” this function, the following message will appear at the center of the screen to assist you in creating a password. Type the password, up to six characters, and press <Enter>. You will be asked to confirm the password.
  • Page 67: Exit

    BIOS Setup Exit BIOS SETUP UTILITY Main Advanced Chipset PCIPnP Power Boot Security Exit Exit Saving Changes Exit Discarding Changes Load Optimal Defaults Load Failsafe Defaults Discard Changes Select Screen Select Item Enter Go to Sub Screen General Help Save and Exit Exit V02.04 (C) Copyright 1985-2000, American Megatrends Inc.
  • Page 68: Appendix

    6EXDR Motherboard Appendix Appendix A : Intel 82559 LAN Driver Installation Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “Control Panel”. 2.Click “System”.
  • Page 69 Appendix 8.Type”D:\82559v40” 10.Click “Next”. 9.Click Next. 12.Click “Finish” to restart computer. 11.Click “Next”. (10)
  • Page 70 6EXDR Motherboard Appendix B: BIOS Flash Procedure BIOS update procedure: If your OS is Win9X, we recommend that you used Gigabyte @BIOS Program to flash BIOS. Click “Tool” . Click “@BIOS Writer v1.05” Click “ ” . Click Here. Methods and steps : I.
  • Page 71 In method I, if the BIOS file you need cannot be found in @BIOS server, please go onto Gigabyte's web site for downloading and updating it according to method II. d. Please note that any intercorruption during updating will cause system unbooted...
  • Page 72 Format a bootable system floppy diskette by the command “ format a:/s ” in command mode. Visit the Gigabyte website at http:// www.gigabyte.com.tw ,Select the BIOS file you need and download it to your bootable floppy diskette.
  • Page 73 Appendix Appendix C: Acronyms Acronyms Meaning ACPI Advanced Configuration and Power Interface Advanced Power Management Accelerated Graphics Port Audio Modem Riser Audio Communication Riser BIOS Basic Input / Output System Central Processing Unit CMOS Complementary Metal Oxide Semiconductor CRIMM Continuity RIMM Communication and Networking Riser Direct Memory Access Desktop Management Interface...
  • Page 74 6EXDR Motherboard Acronyms Meaning Original Equipment Manufacturer PCI A.G.P. Controller POST Power-On Self Test Peripheral Component Interconnect RIMM Rambus in-line Memory Module Special Circumstance Instructions SECC Single Edge Contact Cartridge SRAM Static Random Access Memory Symmetric Multi-Processing System Management Interrupt Universal Serial Bus Voltage ID...
