LM210D_manual_UK-WEU.indd 1
LabelManager 10D
The easy to use label maker for your desktop
User Guide ............................................. Page 2
Guide D'Utilisation ..................................... Page 22
Gebruikershandleiding ............................. Pagina 42
Bedienungsanleitung .................................. Seite 62
www.dymo.com
28-06-2007 10:03:29
Advertisement
Table of Contents
Related Manuals for Dymo LabelManager 10D
Summary of Contents for Dymo LabelManager 10D
- Page 1 LabelManager 10D The easy to use label maker for your desktop User Guide ..........Page 2 Guide D’Utilisation ........Page 22 Gebruikershandleiding ......Pagina 42 Bedienungsanleitung ........Seite 62 www.dymo.com LM210D_manual_UK-WEU.indd 1 28-06-2007 10:03:29...
-
Page 2: Table Of Contents
Contents About Your New Label Maker ................ 5 Product Registration .......................5 Getting Started .................... 5 Connecting the Power .....................5 Inserting the Batteries ....................5 Connecting the Optional Power Adapter ..............6 Inserting the Tape Cassette .....................6 Using the Label Maker for the First Time............7 Getting to Know the Label Maker .............. - Page 3 Saving a Label .......................15 Opening Saved Labels ....................16 Inserting Saved Text .....................16 Caring for Your Label Maker ................ 16 Troubleshooting..................18 DYMO D1 Label Cassettes ................19 Power Adapter ................... 19 Documentation Feedback ................20 Environmental Information ................ 21 LM210D_manual_UK-WEU.indd 3...
- Page 4 1 Figure 1 LabelManager 210D Electronic Label Maker 17 AC power connector Tape cutter button Accented character 10 Punctuation 18 Clear Print 11 Space bar 19 Recall Save 12 Insert 20 Navigation 13 CAPS 21 LCD display Number lock 14 Format 22 Cancel Backspace...
-
Page 5: About Your New Label Maker
You can choose to print your labels in many different font sizes and styles. The label maker uses DYMO D1 tape cassettes in widths of 6 mm, 9 mm, or 1 mm. These tape cassettes are available in a wide range of colors. -
Page 6: Connecting The Optional Power Adapter
Connecting the Optional Power Adapter An optional 9 Volt, 1.5 A power adapter can also be used to power the label maker. Connecting the AC adapter to the label maker disconnects the batteries as a power source. To connect the power adapter Plug the power adapter into the power connector on the top, left side of the label maker. -
Page 7: Using The Label Maker For The First Time
Using the Label Maker for the First Time The first time you turn on the power, you are asked to select the language and units of measure. These selections will remain set until you change them, or until the label maker is reset. -
Page 8: Lcd Display
The number of characters displayed will vary due to proportional spacing. With DYMO’s exclusive graphical display, most of the formatting you add is visible instantly. For example, the italics and rounded border added to the text below is clearly displayed. -
Page 9: Num Lock
Num Lock key provides access to the numbers located on some of the alphabetic keys. When Num Lock mode is turned on, the Num Lock indicator is shown on the display and the numbers 0 through 9 appear when you press the corresponding letter keys. Num Lock is turned off by default. -
Page 10: Adding Font Styles
Adding Font Styles You can choose from six different font styles: AaBbCc Normal AaBbCc Bold AaBbCc Italic Outline Shadow Vertical The style you select applies to all characters. Styles can be used with alphanumeric characters and some symbols. To set the font style Press Select Style and press Select a font style and press... -
Page 11: Creating Two-Line Labels
To add a border style Press Select Borders and press Select a border style and press When using borders on two-line labels, both lines are enclosed in one border. To add an underline Press Select Underline and press Press again when the underlined text is shown in the display. On two-line labels, both lines are underlined. -
Page 12: Creating Fixed-Length Labels
Creating Fixed-Length Labels Normally, the length of the label is determined by the length of the text. However, you can choose to set the length of the label for a specific application. When you choose a fixed label length, the label text is automatically resized to fit the label. If the text cannot be adjusted to fit within the fixed label length, a message is displayed showing the smallest possible label length for this text. - Page 13 (Subscripts/Superscripts) To insert a sym Press , select Symbols, and press Select the symbol category and press Use the left and right arrow keys to move to your desired symbol. The left and right arrows move horizontally along a row of symbols. The up and down arrow keys scroll vertically through the rows of symbol types.
-
Page 14: Adding Punctuation
Adding Punctuation You can quickly add punctuation using the punctuation shortcut key. To insert punctuation Press Select the punctuation mark you want and press Using the Currency Key You can quickly add a currency symbol using the currency shortcut key. Press Select the currency symbol you want and press Adding International Characters... -
Page 15: Printing Multiple Labels
To preview your label • Press 5. The label length is displayed, then the text of the label scrolls across the display. Printing Multiple Labels Each time you print, you are asked how many copies to print. You can print up to ten copies at one time. -
Page 16: Opening Saved Labels
To save the current label Press The first available memory location is displayed. Use the arrow keys to move through the locations. You can store new text in any of the memory locations. Select a memory location and press Your label text is saved and you are returned to the label. Opening Saved Labels You can easily open labels saved in memory to use at a later time. -
Page 17: Caring For Your Label Maker
Caring for Your Label Maker Print head Your label maker is designed to give you long and Cutter trouble-free service, while requiring very little button maintenance. Clean your label maker from time to time to keep it working properly. Clean the cutter blade each time you replace the tape cassette. -
Page 18: Troubleshooting
Motor is stalled due to label jam • Clean cutter blade. If you still need assistance, contact DYMO Customer Support. See Contacting Customer Support at the back of this User Guide to locate the contact number for your country. LM210D_manual_UK-WEU.indd 18... -
Page 19: Dymo D1 Label Cassettes
DYMO D1 Label Cassettes Width: 6 mm 9 mm 12 mm Length: S070770 S070670 S070500 Black/Clear 4610 40910 45010 S070510 Blue/Clear 45011 S07050 Red/Clear 4501 S070780 S070680 S07050 Black/White 461 4091 4501 S070690 S070540 Blue/White 40914 45014 S070700 S070550 Red/White... -
Page 20: Documentation Feedback
We also welcome your suggestions about additional topics you would like to see covered in the documentation. Send email messages to: documentation@dymo.com. Please keep in mind that this email address is only for documentation feedback. If you have a technical question, please contact Customer Support. -
Page 21: Environmental Information
Environmental Information The equipment that you have bought requires the extraction and use of natural resources for its production. It may contain substances that are hazardous to health and the environment. In order to avoid the dissemination of those substances in our environment, and to diminish the pressure on natural resources, we encourage you to use the appropriate take-back systems. - Page 22 LM210D_manual_UK-WEU.indd 22 28-06-2007 10:03:50...
-
Page 23: Contacting Customer Support
CONTACTING CUSTOMER SUPPORT COUNTRY TELEPhONE SUPPORT FAx SUPPORT UNITED KINGDOM 00 7 41 55 9 + 1 0 581 9 80 IRELAND 014 118 94 + 1 0 581 9 80 FRANCE 01 69 49 + 1 0 581 9 80 NEDERLAND 00 581 9 86 00 581 9 80... - Page 24 ©2007 DYMO A Newell Rubbermaid company DYMO bvba Industriepark-Noord 30 9100 Sint-Niklaas Belgium www.dymo.com LM210D_manual_UK-WEU.indd 24 28-06-2007 10:03:51...
