Gigabyte GA-5LXWL-RH User Manual

Gigabyte GA-5LXWL-RH User Manual

Pentium 4/d processor motherboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GA-5LXWL-RH
Pentium
4/D Processor Motherboard
®
USER'S MANUAL
Pentium
*
The WEEE marking on the product indicates this product must not be disposed of with
user's other household waste and must be handed over to a designated collection point
for the recycling of waste electrical and electronic equipment!!
*
The WEEE marking applies only in European Union's member states.
4/D Processor Motherboard
®
Rev. 1001
12ME-5LXWLRH-1001R

Advertisement

Table of Contents
loading

Related Manuals for Gigabyte GA-5LXWL-RH

Summary of Contents for Gigabyte GA-5LXWL-RH

  • Page 1 GA-5LXWL-RH Pentium 4/D Processor Motherboard ® USER’S MANUAL Pentium 4/D Processor Motherboard ® Rev. 1001 12ME-5LXWLRH-1001R The WEEE marking on the product indicates this product must not be disposed of with user's other household waste and must be handed over to a designated collection point for the recycling of waste electrical and electronic equipment!! The WEEE marking applies only in European Union's member states.

  • Page 2: Table Of Contents

    Item Checklist ..................3 WARNING! ....................3 Chapter 1Introduction ................4 1.1 Features Summary ................4 1.2 GA-5LXWL-RH Motherboard Components .......... 6 Chapter 2 Hardware Installation Process ..........8 2-1: Installing Processor and CPU Haet Sink ..........8 2-1-1:Installing CPU ......................8 2-1-2: Installing Heat Sink ....................

  • Page 3: Item Checklist

    Introduction Item Checklist The GA-5LXWL-RH motherboard Serial ATA cable x 4 IDE (ATA100 ) cable x 1 / Floppy cable x 1 I/O Shield Kit CD for motherboard driver & utility SATA Power cable x 4 GA-5LXWL-RH user’s manual WARNING! Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips.

  • Page 4: Chapter 1Introduction

    GA-5LXWL-RH Motherboard Chapter 1 Introduction Features Summary Form Factor 12” x 9.6” ATX form factor, 4 layers PCB. Supports single Intel Pentium 4/Pentium D processor ® ® ® Intel Pentium Dual Core in LGA 775 socket ® Supports 800/1066MHz FSB...
  • Page 5 Introduction On-Board Peripherals 1 x ATA 133 connector 1 x Floppy connector 2 x PS/2 connectors 1 x Parallel port supports Normal/EPP/ECP mode 1 x Serial port (COM) 2 x IEEE 1394 connectors 8 x USB 2.0/1.1 ports (4 x Rear, 4 x Front by cable) 7 x Audio ports (4 x Line-out/ 1 x Line-in/ 1 x MIC/ 1 by cable) 2 x LAN RJ45 4 x SATA 3.0Gb/s connectors...

  • Page 6: 1.2 Ga-5Lxwl-Rh Motherboard Components

    GA-5LXWL-RH Motherboard 1.2 GA-5LXWL-RH Motherboard Components PSU Fan Connector Intel 975X Case Open Intel ICH7R DIMM1 BIOS Flash DIMM2 TI TSB43AB23 DIMM3 ITE IT8718F-S DIMM4 Broadcom CM5787 PCI-E x 16 Slot Relteak ALC888 PCI1 Slot(32bit/33MHz) IDE Connector PCI2 Slot(32bit/33MHz) Floppy Connector...
  • Page 7 Introduction 13 14...

  • Page 8: Chapter 2 Hardware Installation Process

    GA-5LXWL-RH Motherboard Chapter 2 Hardware Installation Process 2-1: Installing Processor and CPU Haet Sink Before installing the processor and cooling fan, adhere to the following cautions: 1. The processor will overheat without the heatsink and/or fan, resulting in permanent irreparable damage.

  • Page 9: 2-1-2: Installing Heat Sink

    Hardware Installation Process 2-1-2: Installing Heat Sink Male Push Pin The top of Female Push Pin Female Push Pin Step. 2 ( to remove the heat sink, turning the push pin Step 1. along the direction of arrow; and reverse the Please apply heat sink paste on the surface of the installed CPU.

  • Page 10: 2-2: Install Memory Modules

    Before installing the processor and heatsink, adhere to the following warning: When DIMM LED is ON, do not install/remove DIMM from socket. GA-5LXWL-RH has 4 dual inline memory module (DIMM) sokcets. It supports Dual Channels Technology. The BIOS will automatically detects memory type and size during system boot. For detail DIMM installation, please refer to the following instructions.

  • Page 11: Installation Steps

    Hardware Installation Process Table 1. Supported DIMM Module Type Size Organization RAM Chips/DIMM 256MB 8MB x 8 x 4 bks 16MB x 4 x 4bks 512MB 16MB x 8 x 4bks 32MB x 4 x 4bks 32MB x 8 x 4bks 64MB x 4 x 4bks Installation Steps: 1.

  • Page 12: 2-3: Connect Ribbon Cables, Cabinet Wires, And Power Supply

    GA-5LXWL-RH Motherboard 2-3: Connect ribbon cables, cabinet wires, and power supply 2-3-1 : I/O Back Panel Introduction...
  • Page 13 Hardware Installation Process PS/2 Keyboard and PS/2 Mouse Connector To install a PS/2 port keyboard and mouse, plug the mouse to the upper port (green) and the keyboard to the lower port (purple). Parallel Port The parallel port allows connection of a printer, scanner and other peripheral devices. COAXIAL (SPDIF Out) The SPDIF coaxial output port is capable for providing digital audio to external speakers or compressed AC3 data to an external Dolby Digital Decoder via a coaxial cable.
  • Page 14 GA-5LXWL-RH Motherboard Line In The default Line In jack. Devices like CD-ROM, walkman etc. can be connected to Line In jack. Line Out (Front Speaker Out) The default Line Out (Front Speaker Out) jack. Stereo speakers, earphone or front surround speakers can be connected to Line Out (Front Speaker Out) jack.

  • Page 15: 2-4: Connectors Introduction & Jumper Setting

    Connector Introduction 2-4: Connectors Introduction & Jumper Setting 9 10 1. ATX1 13. F_Audio (Front Audio Connector) 2. ATX2 14. SPDIF (SPDIF In Connector) 3. IDE1 (IDE Connector) 15. CD_IN (CD In Connector) 4. FDD (Floppy Connector) 16. CPU_FAN (CPU Fan Connector) 5.
  • Page 16 GA-5LXWL-RH Motherboard 1) ATX1 (Auxukiary Power Connector) AC power cord should only be connected to your power supply unit after ATX power cable and other related devices are firmly connected to the mainboard. PIN No. Definition +3.3V +3.3V 5VSB +12V +12V +3.3V...
  • Page 17 Connector Introduction 3 ) IDE1 (IDE Connector) Please connect first harddisk to IDE1. The red stripe of the ribbon cable must be the same side with the Pin1. 4 ) FDD (Floppy Connector) Please connect the floppy drive ribbon cables to FDD. It supports 720K,1.2M,1.44M and 2.88Mbytes floppy disk types.
  • Page 18 GA-5LXWL-RH Motherboard 5/ 6/ 7/ 8 ) S_ATA 1~4 (Serial ATA Connectors) You can connect the Serial ATA device to this connector, it provides you high speed transfer rates (3.0Gb/s). Pin No. Definition S_ATA1 S_ATA2 S_ATA4 S_ATA3 9/ 10 ) F_USB1/2 (Front USB Connectors) Be careful with the polarity of the front USB connector.
  • Page 19 Connector Introduction 11 ) F_Panel (2X10 Pins Front Panel connector) Please connect the power LED, PC speaker, reset switch and power switch of your chassis front panel to the F_PANEL connector according to the pin assignment above. Pin No Signal Name Description Hard Disk LED anode (+) MSG+...
  • Page 20 GA-5LXWL-RH Motherboard 12 ) F_1394 (IEEE 1394 connector) Pin No. Definition FTPA1+ FTPA1- FTPB1+ FTPB1- BUSVCC0 BUSVCC0 No Pin 13) F_AUDIO (Front AUDIO Connector) If you want to use Front Audio connector, you must remove 5-6, 9-10 Jumper. In order to utilize the front audio header, your chassis must have front audio connector.
  • Page 21 Connector Introduction 14 ) SPDIF (SPDIF In Connector) Use this device only when your hardware system has digital output function. Pin No. Definition SPDIF IN 15 ) CD_IN (CD IN,Blank) Connect CD-ROM or DVD-ROM audio out to the connector. Pin No. Definition CD-L CD_R...
  • Page 22 GA-5LXWL-RH Motherboard 16 ) CPU_FAN (CPU Fan Connector) Please note, a proper installation of the CPU cooler is essential to prevent the CPU from running under abnormal condition or damaged by overheating.The CPU fan connector supports Max. current up to 1A .
  • Page 23 Connector Introduction 19 ) PSU_FAN (Power Fan Connector) This connector allows you to link with the cooling fan on the system case to lower the system temperature. Pin No. Definition +12V Sense 20 ) SYS_FAN (System Fan Connector) This connector allows you to link with the cooling fan on the system case to lower the system temperature.
  • Page 24 GA-5LXWL-RH Motherboard 21 ) BAT1 (Battery) CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. If you want to erase CMOS...
  • Page 25 Connector Introduction 23 ) JP4 (Skip Password Function) 1-2 Close: Normal (Default setting) 2-3 Close: Skip Supervisor Password in BIOS setup menu 24 ) CLR_CMOS1 (Clear CMOS Function) You may clear the CMOS data to restore its default values by this jumper. Default value doesn’t include the “Shunter”...

  • Page 26: 2-5: Block Diagram

    Block Diagram 2-5: Block Diagram CLOCK GENERATOR CK410 ICS 954101DF INTEL LGA775 VRD 11.1 Pentium 4/Pentium D Presler / Cedar Mill Core FSB 1066/800/533 PCI-E Graphic Card CHANNEL A PCIE x8 PCIE x16 Slot DDRII533/667 Un-Buffered ECC DIMM x 2 GlENWOOD Intel 975X CHANNEL B...

  • Page 27: Chapter 5 Bios Setup

    BIOS Setup Chapter 5 BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off.

  • Page 28: Getting Help

    GA-5LXWL-RH Motherboard GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.

  • Page 29: Main

    BIOS Setup Main Once you enter Award BIOS Setup Utility, the Main Menu (Figure 1) will appear on the screen. Use arrow keys to select among the items and press <Enter> to accept or enter the sub-menu. CMOS Setup Utility-Copyright(c) 1984-2006 Award Software Main Advanced Seccurity...

  • Page 30: Ide Hdd Auto Detection

    GA-5LXWL-RH Motherboard IDE Channel 0 Master, Slave / Channel 1 Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer. There are two types: auto type, and manual type. Manual type is user-definable; Auto type that will automatically detect HDD type.
  • Page 31 BIOS Setup Drive A The category identifies the types of floppy disk drive A that has been installed in the computer. None No floppy drive installed 360K, 5 5.25 inch PC-type standard drive; 360K byte capacity. 1.2M, 5 5.25 inch AT-type high-density drive; 1.2M byte capacity (3.5 inch when 3 Mode is Enabled).

  • Page 32: Advanced

    GA-5LXWL-RH Motherboard Advanced CMOS Setup Utility-Copyright(c) 1984-2006 Award Software Main Advanced Seccurity PC Health Info Exit Advanced BIOS Feature Item Help Integrated Peripherals Power Management Setup PnP/PCI Configuration : Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help...

  • Page 33: Advanced Bios Feature

    BIOS Setup Advanced BIOS Feature CMOS Setup Utility-Copyright(c) 1984-2006 Award Software Advanced Advanced BIOS Feature Item Help Hard Disk Boot Priority Quick Power On Self Test [Enabled] First Boot Device [Floppy] Second Boot Device [Hard Disk] Third Boot Device [CD-ROM] Boot Menu [Enabled] Boot Up Flppy Seek...

  • Page 34: Quick Power On Self Test

    GA-5LXWL-RH Motherboard Quick Power On Self Test This category speeds up Power On Self Test (POST) after you power on the computer. If it is set to Enable, BIOS will shorten or skip some check items during POST. Enabled Enables quick POST.(Default setting) Disabled Normal POST.

  • Page 35: Init Display First

    BIOS Setup Boot Up Num-Lock Enable the Boot Up Num-Lock. (Default setting) Disable this function. Init Display First This feature allows you to select the first initation of the monitor display from which card, when you install an AGP VGA card and a PCI VGA card on board. Set Init Display First to PCI Express Slot.

  • Page 36: Integrated Peripherals

    GA-5LXWL-RH Motherboard Integrated Peripherals CMOS Setup Utility-Copyright(c) 1984-2006 Award Software Advanced Integrated Peripherals Item Help On-Chip Primary PCI IDE [Enabled] SATA RAID/ACHI Mode [Disabled] On-Chip SATA Mode [Enhmanced] x PATA IDE Set to Ch.0 Master/Slave SATA Port 0/2 Set to Ch.2 Master/Slave...

  • Page 37: Usb Controller

    BIOS Setup OnChip Promary PCI IDE Enabled Enable the function of On-chip primary PCI IDE. (Defualt setting) Disabled Disable this function. OnChip SATA RAID/ACHI Mode Disabled Disable both RAID and ACHI function. (Default setting) ACHI Enable SATA as ACHI function. RAID Enable SATA as RAID function.

  • Page 38: Onboard Parallel Port

    GA-5LXWL-RH Motherboard USB Keyboard Support Enabled Enable USB Keyboard Support. Disabled Disable USB Keyboard Support. (Default setting) USB Mouse Support Enabled Enable USB Mouse Support. Disabled Disable USB Mouse Support. (Default setting) Azalia Codec Auto Auto detect audio function.(Default value) Disabled Disable this function.

  • Page 39: Parallel Port Mode

    BIOS Setup Parallel Port Mode Using Parallel port as Standard Parallel Port. (Default setting) Using Parallel port as Enhanced Parallel Port. Using Parallel port as Extended Capabilities Port. ECP+EPP Using Parallel port as ECP & EPP mode. ECP Mode Use DMA This option is only available if the setting for the Parallel Port Mode option is ECP.

  • Page 40: Power Management Setup

    GA-5LXWL-RH Motherboard Power Management Setup CMOS Setup Utility-Copyright(c) 1984-2006 Award Software Advanced Power Management Item Help ACPI Suspend Type [S3(STR) AC Back Function [Memory] Resume By Alarm [Disabled] x Date (of Month) Alarm x Time (hh: mm: ss) 0:0:0 : Move...

  • Page 41: Resume By Alarm

    BIOS Setup Resume by Alarm You can set "Resume by Alarm" item to enabled and key in Data/time to power on system. Disabled Disable this function. (Default setting) Enabled Enable alarm function to POWER ON system. If RTC Alarm Lead To Power On is Enabled. Date ( of Month) Alarm : Everyday, 1~31 Time ( hh: mm: ss) Alarm :...

  • Page 42: Pnp/Pci Configuration

    GA-5LXWL-RH Motherboard PnP/PCI Configuration CMOS Setup Utility-Copyright(c) 1984-2006 Award Software Advanced PnP/PCI Configuration Item Help IRQ Resources PCI Latency Time (Clk) [64] : Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F7: Optimized Defaults...

  • Page 43: Security

    BIOS Setup Security CMOS Setup Utility-Copyright(c) 1984-2006 Award Software Main Advanced Seccurity PC Health Info Exit Set Supervisor Password Item Help x Set User Password Password Check [Setup] Halt On [All Errors] Chassis Opening Warning [Disabled] x Hard Disk Security : Move Enter: Select +/-/PU/PD: Value F10: Save...

  • Page 44: Password Check

    GA-5LXWL-RH Motherboard Password Check Select whether the password is required every time when the system boots or only when user enter the setup. Halt On The category determines whether the computer will stop if an error is detected during power up.

  • Page 45: Pc Health

    BIOS Setup PC Health CMOS Setup Utility-Copyright(c) 1984-2006 Award Software Main Advanced Seccurity PC Health Info Exit Temperature Item Help Voltage : Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F7: Optimized Defaults Figure 4: PC Health Temperature Display the current CPU temperature, motherboard front and rear temperature.

  • Page 46: Info

    GA-5LXWL-RH Motherboard Info CMOS Setup Utility-Copyright(c) 1984-2006 Award Software Main Advanced Seccurity PC Health Info Exit BIOS Version Item Help BIOS Date 10/3/2006 Processor Type Genuine Intel(R) Processor Speed 1.87GHz/1068MHz L1 Cache 64KB L2 Cache 2048KB Total Memory DIMM1 Not Installed...

  • Page 47: Exit

    BIOS Setup Exit CMOS Setup Utility-Copyright(c) 1984-2006 Award Software Main Advanced Seccurity PC Health Info Exit Save & Exit Setup Item Help Save & Turn Off Exit Without Saving Load Setup Defaults : Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values...
