- Page 1 PB9200 Digital Projector Ceiling Mounting Guide Welcome...
-
Page 2: Table Of Contents
Copyright Copyright 2004 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company. -
Page 3: Packing Parts List
Packing Parts List U-PLATE NUTS x 4 PROJECTOR ADAPTER CEILING ADAPTER PIPE M3 SCREWS x 4 M4 SCREWS x 4 SQUARE TUBE M6 SCREWS x 4 TUBE ADJUSTMENT ASSEMBLY BOLTS x 7 (TUBE BOLTS x 2, L – ADJUST BOLT x 2, TUBE BOLTS x 2) Names of Parts U - PLATE CEILING ADAPTER... -
Page 4: Projector Installation And Throw Distance Chart
Projector Installation and Throw Distance Chart Ceiling Installation for a 4:3 screen [inch (m)] [inch (cm)] [inc h [inc h min . max. min . max. (m)] (cm)] 40(1.0) 24(61) 46 (1.2 ) 71(1.8) 12(30) 24(61) 60(1.5) 36(91) 71(1.8) 107(2.7) 18(46) 36(91) 70(1.8) -
Page 5: Installing A Projector With The Ceiling Bracket
Installing a Projector with The Ceiling Bracket Overview Diagram of completed installation Ceiling Mount Device Installation Procedure Insert the U-PLATE into the CEILING ADAPTER, and tighten two M4 SCREWS (from the bottom) STEP A into the screw holes. Then attach the top part to the ceiling. U-PLATE CEILING ADAPTER M4 SCREWS... - Page 6 STEP B Install the TUBE and the U-PLATE with 2 sets of BOLTS & NUTS (TUBE BOLT). NUTS x 2 TUBE BOLTS x 2 TUBE STEP C Install the PIPE and the TUBE with 2 sets of BOLTS & NUTS (L-ADJUST BOLT). NUTS x 2 L-ADJUST BOLTS x2 PIPE...
- Page 7 STEP E Assemble the PROJECTOR ADAPTER and PROJECTOR with 4 M6 SCREWS. M6 SCREW STEP F Slide the projector with adapter into the ceiling assembly and fix the projector with 4 M3 SCREWS. Ceiling mount bracket M3 SCREW BASE-ASSEMBLY Installation finished. Installing a Projector with the Ceiling Bracket 7...
-
Page 8: Adjusting The Ceiling Bracket
Adjusting the Ceiling Bracket Height Adjustment Make sure to remove the projector first. Loosen the nuts securing to the two L-ADJUST BOLTS. Remove the L-ADJUST BOLTS from the PIPE. Adjust to the correct position for the height of the screen. The height can be adjusted to 309 mm or any value in a range between 639 mm and 849 mm in increments of 30 mm. - Page 9 Horizontal Angle Adjustment Hold the projector’s right and left sides and push it up slightly. Adjust the horizontal angle so that it is correct for the orientation of the screen. The swivel angle can be set within a range of negative to positive 30 degrees. Vertical Angle Adjustment Hold the projector’s right and left sides.
-
Page 10: Specifications And Diagrams
Specifications and Diagrams Specifications Adjustment Range Height 309 mm, 639 mm, 669 mm, 699 mm, 729 mm, 759 mm, 789 mm, 819 mm and 849 mm. Horizontal angle –30 to +30 degrees Vertical angle -5 to +30 degrees Swing angle -15 to +15 degrees Weight 4.2 kg...
