Summary of Contents for BenQ Portable PB6240
- Page 1 PB6240 Digital Projector Portable Series User’s Manual Welcome...
- Page 2 Copyright Copyright 2005 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BenQ Corporation.
-
Page 3: Table Of Contents
Table of contents Important safety instructions ........1 Introduction ..............5 Projector features .............. 5 Shipping contents.............. 6 Optional accessories ............7 Projector exterior view ............. 7 Front / upper side ..................7 Rear side .....................7 Bottom side ....................8 Connector panel ..................8 Controls and functions ............. 9 External control panel ................9 Remote control ..................10 Remote control effective range ..............11... - Page 4 Accessories (included in the standard package) ........42 Optional accessories (not included in the standard package) ....42 Ordering parts or getting information ............. 42 Safety instructions for ceiling mounting of your BenQ projector... 43 Troubleshooting............44 Specifications.............45 Projector specifications .............45 Timing chart...............46...
- Page 5 Supported timing for Video and S-Video inputs ........46 Dimensions ............... 47 Warranty..............48 Limited Warranty ............. 48 Regulation Statements ..........49 FCC statement ..............49 EEC statement ..............49 MIC statement ..............49 Table of contents...
- Page 6 <Memo> Table of contents...
-
Page 7: Important Safety Instructions
Important safety instructions Your BenQ projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. - Page 8 Never replace the lamp assembly or This product is capable of displaying any electronic components unless inverted images for ceiling mount the projector is unplugged. installation. Please use BenQ’s Ceiling Mounting Kit for mounting the unit and ensure it is securely installed. Important safety instructions...
- Page 9 Safety Instructions (Continued) Do not place this projector in any of the Do not block the ventilation holes. following environments. - Do not place this unit on a blanket, bedding or any other soft surface. - Space that is poorly ventilated or confined. - Do not cover this unit with a cloth or any Allow at least 50 cm clearance from walls other item.
- Page 10 If the projector does become wet, disconnect it from the power supply’s wall socket and call BenQ to have the projector serviced. Besides probable physical damage to the projector, doing so may result in accidents and possible injury.
-
Page 11: Introduction
Introduction Projector features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. The projector offers the following features: • Selectable password protected function • Compact and portable unit • High quality manual zoom lens •... -
Page 12: Shipping Contents
Shipping contents The projector is shipped with the cables required for connection to a PC and to video equipment. Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. The supplied accessories will be suitable for your region, and may differ from those illustrated. -
Page 13: Optional Accessories
Optional accessories Macintosh adapter Component Video to VGA (D-sub) 250W lamp module adaptor cable Ceiling mount kit RS232 connector Presentation Plus Projector exterior view Front / upper side External control panel (See "External control panel" on page 9 details.) Focus ring and Zoom ring Ventilation grill Front IR remote... -
Page 14: Bottom Side
Bottom side Front adjuster foot Lamp cover Rear adjuster foot Rear adjuster foot Connector panel Refer to "Positioning your projector" on page 12 for more information on making connections to various equipment. IR remote sensor USB socket RGB signal output socket Audio socket &... -
Page 15: Controls And Functions
Controls and functions External control panel Power (Refer to "Start up" on page 22 "Shutdown" on page 27 for more information.) Turns the projector on or off. Source (Refer to "Switching input signal" on page 26 for more information.) Sequentially selects the input signal RGB, Component Video, S-Video or Video. 3 Left Right 4 When the on-screen menu is not activated, #3 and #4 function as Keystone -/+ hot... -
Page 16: Remote Control
Adjusts the size of the image. Rotate clockwise to enlarge the image or rotate counter-clockwise to make the image smaller. Focus ring (Refer to "Fine-tuning the image size and clarity" on page 24 for more information.) Adjusts the focus of the projected image. Remote control Power (Refer to "Start up"... -
Page 17: Remote Control Effective Range
Blank (Refer to "Hiding the image" on page 26 for more information.) Used to hide the screen image. Press Blank again to restore the image. Mode (Refer to "Application Mode" on page 30 for more information.) Depending upon which input signal is selected, there are several picture setup options available. -
Page 18: Positioning Your Projector
Select this location with the projector suspended upside-down from the ceiling behind the screen. Note that a special rear projection screen and the BenQ Projector Ceiling Mounting Kit are required for this installation location. in the Advance > Mirror menu after you turn the projector on. -
Page 19: Obtaining A Preferred Projected Image Size
BenQ has provided a table of 4:3-aspect-ratio screen sizes to assist you in determining the ideal location for your projector. There are two dimensions to consider, the perpendicular horizontal distance from the centre of the screen (projection distance), and the vertical offset height of the projector from the horizontal edge of the screen (offset). -
Page 20: How To Determine The Position Of The Projector For A Given Screen Size
How to determine the position of the projector for a given screen size: Select your screen size. Refer to the table and find the closest match to your screen size in the left columns labelled 'Screen Diameter.' Using this value, look across this row to the right to find the corresponding average distance from screen value in the column labelled 'Average'. - Page 21 Minimum Maximum zoom zoom Screen Center of lens Offset Projection distance Screen Diameter Distance from Screen in mm Vertical Offset in mm Feet Inches Min length Average Max length (with max. (with min. zoom) zoom) 1219 1600 1780 1960 1500 1969 2190 2412...
-
Page 22: Connection
Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. In the connections shown below, some cables may not be included with the projector (see "Shipping contents"... -
Page 23: Connecting A Monitor
• Many laptops do not turn on their external video ports when connected to a projector. Usually a key combo like FN + F3 or CRT/LCD key turns the external display on/off. Locate a function key labeled CRT/LCD or a function key with a monitor symbol on the laptop. -
Page 24: Connecting Video Source Devices
Connecting Video source devices You can connect your projector to various Video source devices that provide any one of the following output sockets: • Component Video • S-Video • Video (composite) You need only connect the projector to a Video source device using just one of the above connecting methods, however each provides a different level of video quality. -
Page 25: Connecting A Component Video Source Device
Connecting a Component Video source device Examine your Video source device to determine if it has a set of unused Component Video output sockets available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device. To connect the projector to a Component Video source device: Take the (optional accessory) Component Video to VGA (D-Sub) adaptor cable and connect the end with 3 RCA type connectors to the Component Video output sockets... -
Page 26: Connecting An S-Video Source Device
Connecting an S-Video source device Examine your Video source device to determine if it has an unused S-Video output socket available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device. To connect the projector to an S-Video source device: Take the supplied S-Video cable and connect one end to the S-Video output socket of the Video source device. -
Page 27: Connecting A Composite Video Source Device
Connecting a composite Video source device Examine your Video source device to determine if it has a set of unused composite Video output sockets available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device. To connect the projector to an composite Video source device: Take the supplied Video cable and connect one end to the composite Video output socket of the Video source device. -
Page 28: Operation
The start up procedure takes about 30 seconds after pressing Power. In the later stage of start up, a default BenQ logo is projected. If you are prompted for a password, press the arrow buttons to select the four password digits, then press Auto. -
Page 29: If You Forget The Password
Press and hold 4 for 5 seconds. The projector will display a coded number on the screen. Seek help from the local BenQ service center to decode the number. You may be required to provide proof of purchase documentation to verify that you are an authorized user of the projector. -
Page 30: Adjusting The Height
Adjusting the height The projector is equipped with 1 quick-release adjuster foot and 2 rear adjuster feet. These adjusters change the image height and projection angle. To adjust the projector: Lift the projector up and press the adjuster button to release the adjuster. -
Page 31: Correcting Keystone
Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen. To correct this, besides adjusting the height of the projector, you will need to manually correct it following ONE of these steps. -
Page 32: Selecting An Application Mode
Selecting an application mode The projector is preset with several predefined application modes so that you can choose one to suit your operating environment and input source picture type. To select a operation mode that suits your need, press Mode. The picture modes available for different types of signals are shown below. -
Page 33: Remote Paging Operations
Remote paging operations You can operate your display software program (on a connected PC) which responds to page up/down commands (like Microsoft PowerPoint) by pressing Page Up and Page Down on the remote control . See "Connecting a computer" on page 16 for details. -
Page 34: Menu Operation
Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected. Functions available when receiving different signal types... Component Sub-Menu Video / S-Video Video Application Mode Application Mode Color Temp Color Temp Keystone Keystone Brightness... -
Page 35: Using The Menus
Using the menus The projector is equipped with on-screen display (OSD) menus for making various adjustments and settings. There are 10 different menu languages. (Refer to "4. Advance menu" on page 34 for more details.) The following example describes the adjustment of the keystone. Press 6 Menu on the projector or Menu Adjust keystone values by pressing 3 Left / Right 4 on... -
Page 36: Picture Menu
1. Picture menu • Some picture adjustments are available only when certain input sources are in use. Unavailable adjustments are not shown on the screen. • Any custom selected values for Color Temp, Brightness, Contrast, and Color will be reset if you subsequently select an Application mode after adjusting any of their values. FUNCTION DESCRIPTION Pre-defined application modes are provided so you can optimize your... - Page 37 4 color temperature* settings are available. This value will be reset if you subsequently select an Application mode. T1: With the highest color temperature, T1 makes the image appear the most bluish white than other settings. T2: Makes images appear bluish white. Color Temp T3: Maintains normal colorings for white.
-
Page 38: Pro-Picture Menu
2. Pro-Picture menu Some picture adjustments are available only when certain input sources are in use. Unavailable adjustments are not shown on the screen. FUNCTION DESCRIPTION Automatically resizes the input signal pixel resolution to the native resolution of the projector. On: The pixel resolution of the input signal is converted to the native resolution of the projector (1024 x 768). -
Page 39: Setting Menu
3. Setting menu FUNCTION DESCRIPTION Toggles projector audio between on and off. Mute Adjusts audio volume level. The default volume level is 5. Volume Sets the length of time the OSD will remain active after your last button OSD Time press. -
Page 40: Advance Menu
Japanese and Korean. Enables the user to select which logo screen will display during projector User Logo start-up. Three modes are available: Default (BenQ logo), black screen or blue screen. A mode for extreme environments like high altitude or high temperature. - Page 41 Use this mode to reduce system noise and reduce power consumption by 20%. If this mode is activated, the light output will be reduced and result in darker projected images. Economic Mode Setting the projector in Economic mode does not extend the lamp timer automatic shutdown feature.
-
Page 42: Information Menu
5. Information menu This menu shows you the current operating status of the projector. Some picture adjustments are available only when certain input sources are in use. Unavailable adjustments are not shown on the screen. FUNCTION DESCRIPTION Shows the current signal source. Source Shows the native resolution of the input signal. -
Page 43: Maintenance
Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing. -
Page 44: Lamp Information
Lamp information Warning message When the Lamp indicator lights up red or a message appears suggesting it is time to replace the lamp, please install a new lamp or consult your dealer. An old lamp may cause a malfunction in the projector and in some instances the lamp may explode. Setting the projector in Economic mode (See "5. - Page 45 • This lamp contains mercury. Consult your local hazardous waste regulations to dispose of this lamp in a proper manner. Step 1. Turn the power off and disconnect the projector from the wall socket. Step 2. Turn the projector over. Then loosen the screws and remove the lamp cover.
-
Page 46: Temperature Information
Step 8. Restart the projector. Do not turn the power on with the lamp cover removed. Step 9. Resetting the lamp counter Do not reset if the lamp is not replaced as this could cause damage. i. Press and hold the Exit 5 button on the projector for 5 seconds to display the total used lamp time. - Page 47 The projector is under normal operation. Light Status & Description Power Temp Lamp Lamp events (1) The projector needs 110 seconds to cool down. Or (2) Please contact your dealer for assistance. Thermal events The projector has shutdown automatically. If you try to re-start the projector, it will shutdown again.
-
Page 48: Service Information
RS 232 connector ..........50.J0Y01.501 Ordering parts or getting information For product information, product assistance, service information, or to order accessories, please visit the BenQ Corporation website at http://www.BenQ.com. Maintenance... -
Page 49: Safety Instructions For Ceiling Mounting Of Your Benq Projector
Safety instructions for ceiling mounting of your BenQ projector We want you to have a pleasant experience using your BenQ projector, so we need to bring this safety matter to your attention to prevent damage to person and property. If you intend to mount your projector on the ceiling, we strongly recommend that you use a proper fitting BenQ projector ceiling mount kit and that you ensure it is securely and safely installed. -
Page 50: Troubleshooting
Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC inlet on the There is no power from the power projector, and plug the power cord into the cable. power outlet. If the power outlet has a switch, make sure that it is switched on. -
Page 51: Specifications
Specifications Projector specifications All specifications are subject to change without notice. General Product name Digital Projector Model name PB6240 Optical Resolution 1024 x 768 XGA Display system 1-CHIP DMD Lens F/Number F=2.4 to 2.6, f= 24.0 to 29.1 mm Lamp... -
Page 52: Timing Chart
Timing chart Supported timing for PC input Horizontal Vertical Pixel Resolution Frequency Frequency Frequency Mode (kHz) (Hz) (MHz) 640 x 400 31.47 70.089 25.176 640 x 400_70 31.469 59.940 25.175 VGA_60 37.861 72.809 31.500 VGA_72 640 x 480 37.500 75.000 31.500 VGA_75 43.269... -
Page 53: Dimensions
Dimensions Unit: mm Specifications... -
Page 54: Warranty
Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ’s only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). -
Page 55: Regulation Statements
Regulation Statements FCC statement CLASS B: This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. - Page 56 <Memo> Regulation Statements...
