Summary of Contents for Chauvet DMF-10
- Page 1 User Manual...
-
Page 2: Table Of Contents
Fixture Maintenance ..................13 General Troubleshooting ................14 Contact Procedure ..................15 CHAUVET® Contact Information ..............15 Returning Products to CHAUVET® .............. 15 DMX Primer ....................16 Starting Address ....................16 Fixture Linking (Daisy Chain) ................16 DMX Cabling ....................... 17 DMX Connectors .................... -
Page 3: Before You Begin
For other issues such as missing components or parts, damage not related to shipping, or concealed damage, you should make claims to CHAUVET® within seven (7) days of receiving the merchandise. -
Page 4: Product At A Glance
Please contact the nearest authorized technical assistance center. Keep this User Manual for future consultation. If you sell this product to another user, be sure that they also receive this document. Page 4 of 18 DMF-10 User Manual (Rev. 01e) -
Page 5: Introduction
2. I NTRODUCTION Product Overview Microphone LED Screen Safety Microphone Sensitivity Knob Fuse Holder DMX In Power In DMX Out Power Out DMF-10 User Manual (Rev. 01e) Page 5 of 18... -
Page 6: Product Dimensions
Product Dimensions Page 6 of 18 DMF-10 User Manual (Rev. 01e) -
Page 7: Setup
Although the safety cap does have room for a spare fuse, this product ships with no spare fuse. Always replace a blown fuse with a good fuse of the same type and rating. DMF-10 User Manual (Rev. 01e) Page 7 of 18... -
Page 8: Power Linking
Fixture Power Linking Diagram Other fixtures You can power link up to 24 DMF-10 units on 120 VAC or up to 44 DMF-10 units on 230 VAC. The power linking diagram shown above corresponds to the North American version of this product ONLY! If using this product in other markets, you must consult with the local CHAUVET®... -
Page 9: Mounting
Mounting Before mounting this product, read and follow the safety recommendations indicated in the Safety Notes section (page 2 of this manual). The DMF-10 may be mounted in any position, provided there is adequate room for Orientation ventilation around it. -
Page 10: Operation
Press to activate a menu option or a selected value Menu Map Mode Programming Steps Description Selects the DMX starting address. DMX Mode D001~512 Automatic AUTO Selects Automatic Mode. Mode Sound Active Selects Sound Active Mode. Mode Page 10 of 18 DMF-10 User Manual (Rev. 01e) -
Page 11: Configuration (Dmx)
DMX mode uses. If you choose a starting address that is too high, you could restrict the access to some of the fixture’s channels. The DMF-10 uses up to 6 DMX channels in DMX mode, which defines the highest configurable address to 507. -
Page 12: Configuration (Standalone)
1) Press <MENU> repeatedly until AUTO shows on the display. 2) Press <ENTER>. This mode allows a single DMF-10 unit (the “master”) to control the actions of one or Master/Slave more DMF-10 units (the “slaves”) without the need of a DMX controller. The master unit... -
Page 13: Technical Information
Softly drag any dirt or grime to the outside of the lens. Gently polish the lens until it is free of haze and lint. Always dry the lens carefully after cleaning it. DMF-10 User Manual (Rev. 01e) Page 13 of 18... -
Page 14: General Troubleshooting
DMX amplifier after unit #32 Terminator not connected Install a terminator, as indicated in the DMX Primer section. If you still experience problems after trying the above solutions, contact CHAUVET® Technical Support. Page 14 of 18 DMF-10 User Manual (Rev. 01e) -
Page 15: Contact Procedure
If you live in the UK or Ireland, contact CHAUVET® Europe Ltd.(see below). If you live in any other country, DO NOT contact CHAUVET®. Instead, contact your distributor of record. Refer to our Web site for contact details of distributors outside the US, United Kingdom, or Ireland. -
Page 16: Dmx Primer
The maximum recommended number of fixtures on the same daisy chain is 32. Connecting more than 32 fixtures on one daisy chain without the use of a DMX optically-isolated splitter may result in deterioration of the digital DMX signal. Page 16 of 18 DMF-10 User Manual (Rev. 01e) -
Page 17: Dmx Cabling
You can purchase CHAUVET® certified DMX cables directly from a dealer/distributor or make your own DMX cable. If you choose to make your own DMX cable, you must use a data-grade cable such as... -
Page 18: Technical Specifications
Maximum External Temp. Cooling System Thermal 104° F (40° C) Fan cooled I/O Connectors Connector Type Channel Range 3-pin XLR Sockets Product Name Item Code Item Number Ordering DMF-10 03050398 DMF-10 Page 18 of 18 DMF-10 User Manual (Rev. 01e)
