Gianni Industries EM-1200 Specification

UL Listed Certified for US and Canada
"Positive Pressure Fire Tests of Door Assemblies,"
ANSI/UL UL 10B and 10C,
uniform building code standard UBC 7-2 (1997).
Features
High reliability
Holding force up to 1200 lbs
Anodized aluminum casing
MOV provides spike and surge protection
Dual voltage 12 or 24 VDC (selectable)
Anti-Residual magnetism function
Statement
The EM-1200 Series are a high quality and safety range
electromagnet locks that are simply and work well in order to
effectively secure doors. These locks are recommended for
applications which require higher levels of access control and
are suitable for fire doors and emergency exit doors.
The locks are designed for single doors and are suitable for
out-swing applications. Installation on in-swing doors and
narrow-style frames requires the use of additional brackets.
With the accessories provided the series can be installed on
metal and wooden doors.
Specification
Operating Voltage: 12/24 VDC
Current Draw: 500mA/12VDC, 250mA/24VDC
(at 20°C)
Operating Temperature: -10~55°C (14~131°F)
Humidity: 0~95% non-condensing.
Holding Force: Up to 1200 lbs (545 Kg)
Dimensions:
Magnet:(L) 267(265), (W) 68, (D) 40 mm
Armature Plate:(L) 185, (W) 61, (D) 16 mm
Mounting Plate:(L) 267(265), (W) 40, (D) 5 mm
Special Finishes for magnet and armature plate: Zinc plated
Epoxy Potting Compound: E87252 (S), UL94V-0
Net Weight : 4.8 Kg
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-EM-1200 Ver. D Published on 2011.09.07
EM-1200 series
Standard Electromagnetic Lock
Regular Installation
Anti-residual statement
Magnet Armature
(Power On)
Anti-residual statement
Our electromagnet locks feature Anti-Residual Magnetism
(ARM) which ensures the door can be opened without any
resistance from left over magnetism imparted to the armature
plate
Warranty
The product is warranted against defects in material and
workmanship while used in normal service for a period of 5
years from the date of sale to the original customer. The GEM
policy is one of continual development and improvement;
therefore GEM reserves the right to change specifications
without notice.
GIANNI INDUSTRIES, INC.
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: inquiry@gianni.com.tw
Website: gianni.tw
Magnet
Armature
(Power Off)
