Contents Thank you for buying this Pioneer product. Please read through these instructions so you will know how to operate your model properly. After you have finished reading the instructions, keep this document in a safe place for future reference.
Page 3 Contents The display while driving on the Displaying multiple routes 44 freeway 31 Checking and modifying the current Types of the road stored in the map route database 31 Displaying the route overview 45 Operating the map screen 31 Checking the current itinerary 45 Scrolling the map to the position you Modifying the route calculation want to see 31...
Page 4 Contents Selecting the preferred RDS-TMC service Basic operations of the AV source provider manually 55 Displaying the AV operation screen 71 Selecting a source 71 Registering and connecting a Bluetooth Turning off the AV source 71 device AV source plate display 72 Preparing communication devices 56 Using the radio Registering your Bluetooth devices 56...
Page 5 Contents Reading the screen 83 Language code chart for DVDs 97 Using the touch panel keys 84 Playing music files (from USB or SD) Operating by hardware buttons 84 Starting procedure 98 Playing a DVD-Video Reading the screen 98 Starting procedure 85 Using the touch panel keys (Music) 99 Reading the screen 85 Operating by hardware buttons 99...
Page 6 Contents Reading the screen 114 Other functions 131 Using the touch panel keys 115 Displaying the image of your Operating by hardware buttons 116 application (iPhone) 131 Displaying the image of your Using the SiriusXM tuner application (smartphone) 131 Introducing SiriusXM tuner operations 117 To subscribe to the SiriusXM Satellite Customizing preferences Radio service 117...
Page 7 Contents Setting the criteria of route Setting the illumination color 147 calculation 140 Displaying the icon for setting the rear Setting the use of toll roads 140 display output 148 Setting the use of ferries 140 Displaying the screen for AV system Setting the route calculation by settings 148 learning route 141...
Page 8 Contents Other functions Bluetooth 189 Setting the anti-theft function 163 SiriusXM Radio READY Logo 189 Setting the password 163 HD Radio™ Technology 189 Entering the password 163 SD and SDHC logo 189 WMA/WMV 190 Deleting the password 163 Forgotten password 163 DivX 190 AAC 190 Restoring the navigation system to the...
Page 9: Introduction
The screen examples shown in this manual e.g.) are those for AVIC-Z150BH. The screens may p If the home location has not been stored vary according to the models. yet, set the location first.
Page 10: Notice Regarding Video Viewing
Chapter Introduction “External storage device (USB, SD)” satellite, cable and/or any other media), broad- casting/streaming via internet, intranets and/ The SD memory card, SDHC memory card, or other networks or in other electronic con- microSD card, microSDHC card and USB tent distribution systems, such as pay-audio or memory device are collectively referred to as audio-on-demand applications.
Page 11: Map Coverage
Chapter Introduction p Some data remains. Be sure to read Setting For details about iPod compatibility with this navigation system, refer to the informa- items to be deleted first. tion on our website. = For details, refer to Setting items to be deleted on page 165.
Page 12: Basic Operation
Chapter Basic operation Checking part names and functions This chapter gives information about the names of the parts and the main features using the buttons. AVIC-Z150BH (with the LCD panel closed) AVIC-Z150BH (with the LCD panel open)
Page 13 Chapter Basic operation AVIC-X950BH, AVIC-X850BT, and AVIC-X8510BT 1 LCD screen = For details, refer to Adjusting the re- sponse positions of the touch panel 2 VOL (+/–) button (touch panel calibration) on page 147. Press to adjust the AV (Audio and Video) 4 HOME button source volume.
Page 14: Protecting Your Product Against Theft
Chapter Basic operation ! Press and hold to temporarily clear the CAUTION screen regardless of whether it is the AV ! Do not expose the detachable faceplate to ex- source, the current location screen or cessive shock or disassemble it. the AppRadio Mode screen.
Page 15: Attaching The Detachable Faceplate
Inserting and ejecting a disc Push the lower part of the detachable Inserting a disc (for AVIC-Z150BH) faceplate until you hear a click. If you fail to successfully attach the detach- WARNING...
Page 16: Ejecting A Disc (For Avic-Z150Bh)
! If data loss or corruption occurs on the sto- The disc is loaded, and the LCD panel closes. rage device for any reason, it is usually not possible to recover the data. Pioneer accepts no liability for damages, costs or expenses Ejecting a disc (for AVIC-Z150BH) arising from data loss or corruption.
Page 17: Ejecting An Sd Memory Card (For Avic-Z150Bh)
Basic operation Insert an SD memory card into the SD Ejecting an SD memory card card slot. (for AVIC-Z150BH) Insert it with the label surface face-up and Press and hold the h button. press the card until it clicks and completely The LCD panel opens fully.
Page 18: Plugging And Unplugging A Usb Storage Device
CAUTION ! Pioneer cannot guarantee compatibility with ! To prevent data loss and damage to the sto- all USB mass storage devices and assumes rage device, never remove it from this naviga- no responsibility for any loss of data on media tion system while data is being transferred.
Page 19: Connecting Your Ipod
Chapter Basic operation Connecting your iPod Startup and termination Using the USB interface cable for iPod en- Start the engine to boot up the system. ables you to connect your iPod to the naviga- After a short pause, the splash screen comes tion system.
Page 20: Regular Startup
Chapter Basic operation Read the terms carefully, checking the A message about the map details, and then touch [OK] if you agree to database the conditions. After you start using this navigation system, a message related to map data may be dis- played.
Page 21 Chapter Basic operation...
Page 22: How To Use The Navigation Menu Screens
Chapter Basic operation How to use the navigation menu screens 1 Top Menu Menu which was being displayed last time is displayed. This is the starting menu to access the desired 3 AV operation screen screens and operate various functions. You can also check or cancel your set route from This is the screen that normally appears when this menu.
Page 23: Shortcut Menu
Chapter Basic operation Touch In this manual, the application menu screen and the application operation screen are col- lectively referred to as the AppRadio Mode screen . 7 Application menu screen This navigation system can switch to the ap- plication menu, which you can display and op- erate the application for the iPhone or smartphone on the screen.
Page 24: Using The Touch Panel
Chapter Basic operation Using the touch panel right of the item allows you to see the remain- ing characters. You can operate the product by touching the marks and items (touch panel keys) displayed Operating the on-screen keyboard on the screen directly with your fingers. Using the common touch panel keys 1 Keyboard...
Page 25: Swipe Action
Chapter Basic operation While touching the screen, slide your Allows you to move the cursor to the right or finger toward the function you want to left for a number of characters equivalent to execute and release. the number of touches. b Text box Displays the characters that are entered.
Page 26 The sound mix function is en- abled. Displays the AppRadio (*2) Mode screen. (*1) This function is available on AVIC-Z150BH and AVIC-X950BH. (*2) Displays this screen after releasing your finger from the circle. ! The intersection guidance display and the...
Page 27 (*2) Skips to the next channel. Unmutes the sound. ™ SiriusXM tuner Unmutes the sound. Mutes the sound. Mutes the sound. (*1) A source available on AVIC-X850BT and AVIC- X8510BT. (*2) A source available on AVIC-Z150BH and AVIC- X950BH.
Page 28 Chapter Basic operation Hands-free phoning Operation Action screen Allows you to talk on the Receiving a phone. phone call Ends the call. ! Receiving a phone call Swipe response area...
Page 29: How To Use The Map
Chapter How to use the map Most of the information provided by your navigation system can be seen on the map. You need to be- come familiar with how information appears on the map. How to read the map screen This example shows an example of a 2D map screen.
Page 30: Enlarged Map Of The Intersection
Chapter How to use the map p When there is no data of current po- Meaning of guidance flags sition, no information is displayed. Icon Meaning ! The AV source currently selected p Depending on the source currently Destination The checkered flag indicates your desti- chosen, an image is displayed.
Page 31: The Display While Driving On The Freeway
While driving on the freeway, freeway exit lighted in pink) have only basic data and can numbers and freeway signs may be displayed only be used to plot a navigable route. Pioneer in the vicinity of interchanges and exits. navigation will display full route guidance, in- cluding turn-by-turn voice directions and arrow icons.
Page 32: Viewing Information About A Specified Location
Chapter How to use the map Viewing information about a specified location For the locations you have searched using the destination menu, you can display the detailed information as long as the information related to the location is stored in the system. Search for a location using the “Desti- nation”...
Page 33: Switching The View Mode
Chapter How to use the map of the screen and the map on the left side Enables you to call the position if a tele- of the screen. phone number is available. (Pairing with If you touch the map, the map is scrolled cellular phone featuring Bluetooth wireless on the whole screen.
Page 34: Displaying One-Way Street Marks
Chapter How to use the map p Up to 200 items or 100 preinstalled POIs When Heading Up is selected, is dis- played. are displayed on the map. ! North Up: The map display always has north at the Displaying preinstalled POIs on top of the screen.
Page 35: Registering A Scale
Chapter How to use the map Touch the subcategory to display. The indicator of the selected POI lights up and you can continue to select the POI. p The indicator also lights up when several POI are selected. Touching the facility again turns off the indicator and deselects the POI.
Page 36: Searching For And Selecting A Location
Chapter Searching for and selecting a location The basic flow of creating CAUTION your route For safety reasons, these route-setting functions are not available while your vehicle is in motion. 1 Park your vehicle in a safe place and apply To enable these functions, you must stop in a the parking brake.
Page 37: Searching For A Location By Address
Chapter Searching for and selecting a location Touch the key next to “State” and Searching for a location by touch the desired state, province, or terri- address tory on the list. The most frequently used function is Ad- If the location that you want to search for is in dress , in which the address is specified and another state, province, or territory, this the destination is searched.
Page 38: Finding The Location By Specifying The House Number
Chapter Searching for and selecting a location p If the search candidates number reaches Enter the street name and then touch [OK]. 20 or less, the screen automatically changes to the search result screen. Display the “Address Search” screen. Touch [House#]. The Enter House Number screen appears.
Page 39: Searching By Selected City History
Chapter Searching for and selecting a location Touch the desired city name. Enter the house number and then The House Number Selection screen ap- touch [OK]. pears. The House Number Selection screen ap- If the house number you have entered is not pears.
Page 40: Searching For A Poi Directly From The Name Of The Facilities
Chapter Searching for and selecting a location Searching for a POI directly Searching for a nearby POI from the name of the facilities You can search for POIs in your surroundings. p Up to 50 POIs within a 100 miles (160 kilo- p If the search candidates number reaches meters) radius of the vehicle position are 20 or less, the screen automatically...
Page 41: Searching For Pois Around The City
Chapter Searching for and selecting a location p The Category History screen appears if Touch [City]. you have searched for POIs before. # If you touch [History], the City History List p The history can be stored up to 10 genres. screen appears, enabling you to search by pre- You can delete the stored histories collec- viously selected city history.
Page 42: Deleting The Icons Displayed After Searching For A Nearby Poi
Chapter Searching for and selecting a location How to read the “POI List” screen Display the “Destination” screen. = For details of the operations, refer to How to The following information is displayed on the use the navigation menu screens on page POI List screen.
Page 43: Searching For A Location By Coordinates
Chapter Searching for and selecting a location p History can store up to 100 locations. If Touch [East] or [West], and then enter the entries reach the maximum, any further the longitude. entry will overwrite the oldest one. Display the “Destination” screen. = For details of the operations, refer to How to use the navigation menu screens on page Touch [My POIs].
Page 44: After The Location Is Decided
Chapter After the location is decided Setting a route to your # If you touch [Profile], the Route Profile screen appears. destination = For details, refer to Checking the current itin- erary on page 45. Search for a location. # If you touch [Waypoints], the Waypoints = For details, refer to Chapter 4.
Page 45: Checking And Modifying The Current
Chapter Checking and modifying the current route Displaying the route overview While the demonstration guidance is run- ning, [Demo OFF] appears. Touching the p The route overview is only active when the key finishes the demonstration guidance. route is set. 5 Cancel Route You can delete the current route.
Page 46: Modifying The Route Calculation Conditions
Chapter Checking and modifying the current route Modifying the route Determines which condition takes priority for route calculation. calculation conditions Fast*: You can modify the conditions for route calcu- Calculates a route with the shortest travel time lation and recalculate the current route. to your destination as a priority.
Page 47: Editing Waypoints
Chapter Checking and modifying the current route Editing waypoints Search for a location. You can edit waypoints (locations you want to visit on the way to your destination) and recal- culate the route so that it passes through these locations. Adding a waypoint p Up to five waypoints can be set.
Page 48: Sorting Waypoints
Chapter Checking and modifying the current route Touch [Options], and then touch [Way- Touch the waypoint or destination. points]. The Waypoints List screen appears. Touch [Delete]. The Delete screen appears. Select the waypoint that you want to delete. A check mark appears next to the selected waypoint.
Page 49: Finishing The Demonstration Guidance
Chapter Checking and modifying the current route Display the editing route screen. = For details of the operations, refer to How to use the navigation menu screens on page Touch [Demo ON]. Display the map screen. The demonstration guidance will begin. = For details of the operations, refer to How to use the navigation menu screens on page Finishing the demonstration...
Page 50: Editing The Data On The Use Of Navigation
Chapter Editing the data on the use of navigation function Registering and editing Touch the item you want to configure. locations Storing favorite locations Storing your favorite locations as Favorites lets you save the time and effort of re-entering this information. Stored items can be made available on Favorites later.
Page 51: Deleting The Destination History From The List
Chapter Editing the data on the use of navigation function Display the “Edit/Settings” screen. Touch [Delete]. = For details of the operations, refer to How to Select the location you want to delete. use the navigation menu screens on page Touch [Data Edit].
Page 52: Deleting Learned Routes
Chapter Editing the data on the use of navigation function Deleting learned routes The device learns the streets you often use, and the learned streets are preferentially used during a route search. To change a frequently used street, delete the learned route and let the device learn it again.
Page 53: Using Traffic Information
Chapter Using traffic information p This function is available on AVIC-Z150BH Display the “Information” screen. and AVIC-X950BH. = For details of the operations, refer to How to You can check real-time traffic information use the navigation menu screens on page...
Page 54: Checking Traffic Information On The Route
Chapter Using traffic information When you touch [Traffic on Route], the How to read traffic list displayed will be sorted according to information on the map the distance from the vehicle position to The traffic event information displayed on the the traffic information.
Page 55: Checking For Traffic Congestion Automatically
Chapter Using traffic information p If the navigation system detects any closed/ to the current route displayed, and route gui- blocked roads on your current route, Re- dance starts. routing due to road closure. is an- # If you touch [Scroll Map], you can switch the nounced and displayed on the screen.
Page 56: Registering And Connecting A Bluetooth
Chapter Registering and connecting a Bluetooth device ® If your devices feature Bluetooth technology, ! Pairing from your Bluetooth devices p If you try to register more than 5 devices, this navigation system can be connected to your devices wirelessly. This section describes the system will ask you to select one of the how to set up a Bluetooth connection.
Page 57 # If you touch [Search], the system starts lished from the navigation system. searching for Bluetooth devices waiting for con- p Only the Android device (for AVIC-Z150BH nection, and displays them in the list format and AVIC-X950BH) can be performed the when any devices are detected.
Page 58: Pairing From Your Bluetooth Devices
Bluetooth connection is estab- Touch [Registration]. lished from the navigation system. The Device List screen appears. p Only the Android device (for AVIC-Z150BH Touch [Register from device]. and AVIC-X950BH) can be performed the The navigation system waits for a Bluetooth smartphone cooperation function wireless technology connection.
Page 59: Deleting A Registered Device
Chapter Registering and connecting a Bluetooth device Allows you to proceed to the next step. Bluetooth audio player or smartphone, this ! No: navigation system needs to set another de- The device is registered in the navigation vice for priority connecting. system.
Page 60: Setting For Priority Connecting
Chapter Registering and connecting a Bluetooth device p To cancel the connection to your device, Touch the name of the device that you want to connect. touch [Cancel]. p If connection fails, check whether your de- vice is waiting for a connection and then retry.
Page 61: Using Hands-Free Phoning
Chapter Using hands-free phoning 4 Strength of the Bluetooth connection be- CAUTION tween the navigation system and the device For your safety, avoid talking on the phone as 5 Name of the connected cellular phone much as possible while driving. If your cellular phone features Bluetooth tech- Making a phone call nology, this navigation system can be con-...
Page 62: Calling A Number In The Phone Book
Chapter Using hands-free phoning Touch the number keys to enter the Calling a number in the phone phone number. book You can select and call a contact from the phone book entries transferred to the naviga- tion system. p Before using this function, you need to transfer the phone book entries stored in your cellular phone to the navigation sys- tem.
Page 63: Dialing From The History
Chapter Using hands-free phoning Touch the desired name on the list. Switches the contact entries to first/last name display and sorts the entries by order Touch the desired entry on the list to of first name. make a call. ! Last: A call confirmation message appears.
Page 64: Redialing A Call
Chapter Using hands-free phoning Redialing a call Touch next to the POI that you want to call. You can call again to the number that was The Details screen appears. sent last. Touch to make a call. Display the “Phone” screen. Dialing starts.
Page 65: Receiving A Phone Call
Chapter Using hands-free phoning Receiving a phone call Touch to end the call. You can perform hands-free answering by using the navigation system. Answering an incoming call The system informs you that it is receiving a call by displaying a message and producing a ring sound.
Page 66: Deleting Registered Contacts
Chapter Using hands-free phoning p If you connect a cellular phone featuring cellular phone, it will be transferred an auto-synchronization function, the anew. phone book transfer or synchronization will ! Additional: be automatically performed. If the telephone number is added to the p A maximum of 1 000 entries can be trans- cellular phone, it will be transferred ferred per cellular phone.
Page 67: Deleting The History Information
You can change the device name to be dis- Touch [Edit/Delete] on the “Phone” played on your cellular phone. (Default is screen. PIONEER NAVI .) The Edit/Delete screen appears. = For details, refer to Displaying the phone Display the “Phone” screen.
Page 68: Editing The Password
Chapter Using hands-free phoning Touch to delete the current name, not use the Bluetooth wireless technology, we and enter the new name using the key- recommend selecting Off . board. Display the “Phone” screen. = For details, refer to Displaying the phone menu on page 61.
Page 69: Setting The Automatic Rejection Function
Chapter Using hands-free phoning ! Off (default): ! The line-of-sight distance between this na- No automatic response. Respond manually. vigation system and your cellular phone ! Immediately: must be 10 meters or less when sending Answers immediately. and receiving voice and data via Bluetooth ! After 3 seconds: technology.
Page 70 Chapter Using hands-free phoning ! The registered name appears if the phone number of the received call is already regis- tered in the phone book. When one phone number is registered under different names, the name that comes first in the phone book is displayed.
Page 71: Basic Operations Of The Av Source
! AV input 2 (AV2) p (*1) A source available on AVIC-X850BT Turning off the AV source and AVIC-X8510BT. p (*2) A source available on AVIC-Z150BH Turn off the AV source to stop playing or re- and AVIC-X950BH. ceiving the AV source.
Page 72: Av Source Plate Display
Chapter Basic operations of the AV source AV source plate display If you select a station or song with the track up/down button while the map screen is still displayed, the AV source plate appears on the top of the map screen. The AV source plate displays the status of the currently played AV source.
Page 73: Using The Radio
Chapter Using the radio p This function is available on AVIC-X850BT 4 Band indicator and AVIC-X8510BT. Shows which band the radio is tuned to: FM1, You can listen to the radio using the naviga- FM2, FM3 or AM. 5 Preset number indicator tion system.
Page 74: Storing And Recalling Broadcast Frequencies
Chapter Using the radio 6 Stores the strongest broadcast frequen- Storing and recalling broadcast cies frequencies = For details, refer to Storing the strongest With a touch of any of the preset tuning keys broadcast frequencies on page 74. ( 1 to 6 ), you can easily store up to six 7 Performs manual tuning broadcast frequencies for later recall (also To tune manually, touch...
Page 75: Using Advanced Functions
Chapter Using the radio % Touch [BSM] to begin a search. A message appears. While the message is dis- playing, the six strongest broadcast frequen- cies will be stored under the preset tuning keys 1 to 6 in order of their signal strength. When this is complete, the message disap- pears.
Page 76: Hd Radio Reception
Chapter ™ HD Radio reception p This function is available on AVIC-Z150BH and AVIC-X950BH. You can listen to the radio by using the naviga- Adjacent to traditional main stations are extra local FM channels. These HD2/HD3 Channels provide new, origi- tion system.
Page 77: Using The Touch Panel Keys
Chapter ™ HD Radio reception 2 Multicasting indicator 9 Blending mode indicator = For details, refer to Switching the recep- Shows the number of multicast channels in tion mode on page 80. the current frequency. 3 Current time a Preset number indicator 4 Band indicator Shows the selected preset item b Frequency indicator...
Page 78 Chapter ™ HD Radio reception 2 Scrolls the text If a digital broadcast is not yet received, If not all the characters can be displayed with- tuning up or down seeks the next or pre- in the displayed area, touching the key to the vious analog station.
Page 79: Storing And Recalling Broadcast Frequencies
Chapter ™ HD Radio reception Storing and recalling broadcast Storing song information frequencies to an iPod (iTunes Tagging) With a touch of any of the preset tuning keys You can store the song information to the ( 1 to 6 ), you can easily store up to six iPod, when the navigation system has received broadcast frequencies for later recall (also the song information.
Page 80: Using Advanced Functions
Chapter ™ HD Radio reception Switching the seek mode When it is complete, turns off and is displayed. You can select the method of seek tuning. p The song information for up to 50 songs on the “Digital Radio” screen. Touch can be stored on this navigation system.
Page 81: Playing Audio Cds
Chapter Playing audio CDs You can play a normal music CD using the Shows the title of the track currently built-in drive of the navigation system. This playing (when available). section describes how. : Artist name Shows the artist name of the track cur- rently playing (when available).
Page 82: Using The Touch Panel Keys
Chapter Playing audio CDs Using the touch panel keys All tracks in the disc can be played at random by only touching a single key. p If you turn the random play on when the repeat play range is set to , the repeat play range changes to automatically.
Page 83: Playing Music Files On Rom
Chapter Playing music files on ROM 3 Current time You can play a disc that contains compressed 4 File type indicator audio files using the built-in drive of the navi- gation system. This section describes these Shows the type of audio files. 5 Current file information operations.
Page 84: Using The Touch Panel Keys
Chapter Playing music files on ROM Using the touch panel keys = For details, refer to Playback condition indicator on page 83. 5 Displays the “Phone” screen = For details, refer to Displaying the phone menu on page 61. 6 Plays files in random order The files in the current repeat play range can be played at random by only touching a single key.
Page 85: Playing A Dvd-Video
Chapter Playing a DVD-Video You can play a DVD-Video using the built-in Shows the elapsed playing time within the drive of the navigation system. This section de- current title. 6 Digital sound format indicator scribes operations for playing a DVD-Video. Shows which digital sound format (surround sound format) has been selected.
Page 86: Using The Touch Panel Keys
Chapter Playing a DVD-Video Using the touch panel keys = For details, refer to Swipe action on page Playback screen (page 1) 5 Sets a repeat play range 1 2 3 The repeat play range can be changed by only touching a single key.
Page 87: Resuming Playback (Bookmark)
Chapter Playing a DVD-Video f Changing the wide screen mode Resuming playback (Bookmark) = For details, refer to Changing the wide The Bookmark function lets you resume play- screen mode on page 89. back from a selected scene the next time the g Switches the audio language disc is loaded.
Page 88: Direct Number Search
Chapter Playing a DVD-Video Using the DVD menu by touch ! To select 100 minutes 05 seconds, touch [1], [0], [0], [5], [sec] and [Enter] in order. panel keys p To cancel an input number, touch If items on the DVD menu appear, the touch To cancel the input numbers, touch and panel keys may overlay them.
Page 89: Slow Motion Playback
Chapter Playing a DVD-Video Slow motion playback horizontally toward the ends of the picture, enabling you to enjoy a 4:3 picture without This lets you slow down playback speed. sensing any disparity, even on a wide Touch and hold [r] until is dis- screen.
Page 90: Reading The Screen
Chapter Playing a DivX video You can play a DivX disc using the built-in Shows the file name currently playing. 6 Current folder name indicator drive of the navigation system. This section de- scribes those operations. Shows the folder name currently playing. 7 Digital sound format indicator Shows the digital sound format (surround Starting procedure...
Page 91: Playing A Divx Video
Chapter Playing a DivX video p A dash ( ) is displayed if there is no cor- 7 Searches for a desired scene and starts responding information. playback from a specified time = For details, refer to Starting playback Touching a folder on the list shows its content. from a specified time on page 92.
Page 92: Slow Motion Playback
Chapter Playing a DivX video Slow motion playback Changing the wide screen mode This lets you slow down playback speed. You can set the screen size of video. p The default setting is Full . % Touch and hold [r] until is dis- on the “DivX”...
Page 93: Playing Divx ® Vod Content
Chapter Playing a DivX video p Images may be unclear when Cinema or Operating by hardware Zoom is selected. buttons p Remember that use of this system for com- mercial or public viewing purposes may Pressing the TRK button constitute an infringement on the author s You can skip files forward or backward.
Page 94: Dvd-Video Or Divx Setup
Chapter DVD-Video or DivX setup Display the “DVD/DivX® Setup” screen. This chapter describes how to configure the DVD-Video/DivX playback. = For details, refer to Displaying DVD/DivX® Setup menu on page 94. Touch [Subtitle Language], [Audio Lan- Displaying DVD/DivX® guage] or [Menu Language]. Setup menu Each language menu is displayed and the cur- rently set language is selected.
Page 95: Setting The Aspect Ratio
Chapter DVD-Video or DivX setup Setting the aspect ratio Setting the code number and level When you first use this function, register your There are two kinds of displays. A wide screen code number. If you do not register a code display has a width-to-height ratio (TV aspect) number, the parental lock will not operate.
Page 96: Setting The Auto Play
Chapter DVD-Video or DivX setup p The DivX subtitles will be displayed even Setting the auto play when the subtitle file setting is on if no cor- When a DVD disc with a DVD menu is in- responding subtitle files exist. serted, this unit will cancel the DVD menu p Up to three subtitle lines can be displayed automatically and start playback from the first...
Page 97: Language Code Chart For Dvds
Chapter DVD-Video or DivX setup Language code chart for DVDs Two-letter Two-letter Two-letter code, Language code, Language code, Language input code input code input code aa, 0101 Afar ie, 0905 Interlingue rn, 1814 Rundi ab, 0102 Abkhazian ik, 0911 Inupiaq ro, 1815 Romanian af, 0106...
Page 98: Reading The Screen
Chapter Playing music files (from USB or SD) Reading the screen You can play compressed audio files stored in the external storage device (USB, SD). p When you play audio files stored on a USB storage device, a USB interface cable for iPod (sold separately) is required for con- nection.
Page 99: Playing Music Files (From Usb Or Sd)
Chapter Playing music files (from USB or SD) Playing files in random order Touching a folder on the list shows its content. You can play a file on the list by touching it. Indicator Meaning Does not play files in random order. Plays all audio files in the current re- peat play range in random order.
Page 100: Playing Video Files (From Usb Or Sd)
Chapter Playing video files (from USB or SD) Reading the screen You can play video files stored in the external storage device (USB, SD). p When you play video files stored on a USB storage device, a USB interface cable for iPod (sold separately) is required for con- nection.
Page 101: Using The Touch Panel Keys (Video)
Chapter Playing video files (from USB or SD) 5 Operates some functions by swipe action Shows the elapsed playing time within the p When the video is displayed in full current file. screen mode, the whole screen be- comes a swipe response area. Using the touch panel keys = For details, refer to Swipe action on page (Video)
Page 102: Operating By Hardware Buttons
Chapter Playing video files (from USB or SD) ! To select 100 minutes 05 seconds, touch [1], [0], [0], [5], [sec] and [Enter] in order. p To cancel an input number, touch To cancel the input numbers, touch and hold Operating by hardware buttons Pressing the TRK button...
Page 103: Using An Ipod (Ipod)
Chapter Using an iPod (iPod) Reading the screen Using the USB interface cable for iPod en- ables you to connect your iPod to the naviga- Music tion system. p A USB interface cable for iPod (sold sepa- rately) is required for connection. Starting procedure Display the AV operation screen.
Page 104: Using The Touch Panel Keys
Chapter Using an iPod (iPod) Setting the shuffle play Shows the file name currently playing (when available). Indicator Meaning : Artist name (podcast title) Shows the artist name currently playing. Cancels the shuffle play. When a podcast is played, the podcast title is displayed (when available).
Page 105: Changing The Wide Screen Mode
Chapter Using an iPod (iPod) p This touch panel key is only available The shuffle play setting can be changed by when there are both audio and video file only touching a single key. = For details, refer to Playback condition in your iPod.
Page 106: Operating By Hardware Buttons
Chapter Using an iPod (iPod) The picture is enlarged slightly at the center and the amount of enlargement increases horizontally toward the ends of the picture, enabling you to enjoy a 4:3 picture without sensing any disparity, even on a wide screen.
Page 107: Streaming Pandora ® And Using Aha Radio
® ! Pandora separately) is required for connection to ! Aha Radio this navigation system (for AVIC-Z150BH p Be sure to read Using app-based connected and AVIC-X950BH). content before you perform this operation. ! The device is connected to this navigation = For details, refer to Using app-based con- system via Bluetooth.
Page 108: For Smartphone Users
Bluetooth devices on page 56. Unlock your smartphone. Connect your smartphone to this pro- duct via the separately sold App Connectiv- ity Kit (CD-AH200) (for AVIC-Z150BH and AVIC-X950BH). = For details of the operations, refer to the In- stallation Manual.
Page 109: Streaming Pandora
! Certain functionality of the Pandora service is sponding information. not available when accessing the service 4 Album artwork through the Pioneer navigation system, in- Album art of the current track is displayed if it cluding, but not limited to, creating new sta- is available.
Page 110: Using The Touch Panel Keys
Chapter ® Streaming Pandora and using Aha Radio Using the touch panel keys You can sort the items in the list in order of dates the items were cre- ated. 2 Recalls equalizer curves = For details, refer to Using the equalizer on page 151.
Page 111: Using Aha Radio
Aha Radio content on this navigation system. Because the application for the iPhone or smartphone is not provided by Pioneer, the re- quired version of the application may not yet be available at the time of purchase of the na- vigation system.
Page 112: Using The Touch Panel Keys
Chapter ® Streaming Pandora and using Aha Radio Using the touch panel keys Touching this key displays the list of your avail- able Aha Radio stations. Touch the desired Aha Radio station to change Aha Radio sources. 3 Recalls equalizer curves = For details, refer to Using the equalizer on page 151.
Page 113: Viewing Information About A Specified Location
Chapter ® Streaming Pandora and using Aha Radio tion information, a maximum of 30 POI Indicator Meaning icons are displayed on the map screen. Touching the key dislikes the cur- p The POI icons on the map will not disap- rent content.
Page 114: Using The Bluetooth Audio Player
Chapter Using the Bluetooth audio player Starting procedure You can control the Bluetooth audio player. p Before using the Bluetooth audio player, Pull out the connecting cable for using you must register and connect the device the AppRadio Mode. to this navigation system. p You cannot use Bluetooth audio player = For details, refer to Registering your when the connecting cable for using the...
Page 115: Using The Touch Panel Keys
Chapter Using the Bluetooth audio player 4 Battery status of the Bluetooth device ! Play time indicator p Depending on the Bluetooth device, this Shows the elapsed playing time within icon may not appear. the current file. p In the following cases, file information 5 Connection status indicator Shows whether the device featuring Bluetooth will only be displayed after a file starts...
Page 116: Operating By Hardware Buttons
Chapter Using the Bluetooth audio player 3 Switches the screen displays Pressing and holding the TRK button Each touch of this key, switches between the You can perform fast reverse or fast for- file information screen and the list selection ward.
Page 117: Using The Siriusxm Tuner Introducing Siriusxm Tuner Operations
Chapter Using the SiriusXM tuner Introducing SiriusXM tuner ! Call SiriusXM Listener Care at 1-866-635- 2349 to activate. operations ! To activate SiriusXM Canada service go to You can use this unit to control a SiriusXM www.xmradio.ca and click on ACTIVATE Connect Vehicle Tuner, which is sold sepa- RADIO in the top right corner, or call rately.
Page 118: Using The Touch Panel Keys
Chapter Using the SiriusXM tuner 2 Current time Indicator Meaning 3 Band indicator Displays the number of song infor- Shows which band the radio is tuned to: mation items stored in the naviga- SXM1, SXM2 or SXM3. tion system. 4 Current channel information The icon is displayed on all AV opera- Shows the detailed information of the broad- tion screens.
Page 119 Chapter Using the SiriusXM tuner = For details, refer to Using the “Replay ™ ” 4 Recalls equalizer curves = For details, refer to Using the equalizer function on page 120. on page 151. f Performs manual tuning 5 Displays the “Function” menu The channels move up or down one at a time.
Page 120: Storing Broadcast Channels
Chapter Using the SiriusXM tuner Storing broadcast channels Selecting a channel from the list With a touch of any of the preset tuning keys You can select a channel from the channel list ( 1 to 6 ), you can easily store up to six category.
Page 121: Using The Tune Scan
Chapter Using the SiriusXM tuner Touch panel Action keys Returns to the start of the current program. Touching again will skip back to the previous program. Jumps to the next program. Touching [d] or [e] switches be- [d] or [e] tween playback and pause.
Page 122 Chapter Using the SiriusXM tuner Using the Content Alerts When enabled, the Parental Control feature re- quires you to enter a passcode to tune to the function (such as Song Alerts, locked channels. Artist Alerts and Game Alerts) While listening to SiriusXM Satellite Radio, Setting the passcode you can be alerted when your favorite songs, on the “SiriusXM”...
Page 123: Storing Song Information To An Ipod (Itunes Tagging)
Chapter Using the SiriusXM tuner Touch the keyword you want to be Touch the league you want. alerted. Touch the team you want. The alert indicator is highlighted, and the alert The team settings are enabled. setting is enabled. p If you touch the indicator highlighted, the alert setting is canceled.
Page 124: Operating By Hardware Buttons
Chapter Using the SiriusXM tuner = For details, refer to Song info reception in- dicator on page 118. Touch Information on the song on air is stored in the navigation system. While the information is being acquired, is displayed. When it is complete, turns off and is displayed.
Page 125: Using Av1
Chapter Using AV input Using AV2 You can display the video image output by the device connected to the navigation system. You can display the video image output by the For details of the connection method, refer to equipment connected to video input 2. the Installation Manual.
Page 126: Changing The Wide Screen Mode
Chapter Using AV input 4 Displays the “Phone” screen screen) picture where captions lie outside = For details, refer to Displaying the phone the frame. menu on page 61. ! Zoom 5 Changing the wide screen mode A 4:3 picture is enlarged in the same pro- = For details, refer to Changing the wide portion both vertically and horizontally;...
Page 127 Pioneer website: nected content on page 191. http://www.pioneerelectronics.com http://www.pioneerelectronics.ca ! Pioneer is not liable for any issues that may Additional cables are also required to con- arise from incorrect or flawed app-based nect the iPhone 5/iPod touch (5th genera- content.
Page 128: Starting Procedure
Touch [Apps]. For smartphone users A message, which notifies you that your p This description is for AVIC-Z150BH and iPhone can launch the application, appears AVIC-X950BH. on screen. ! The following conditions apply to the use of A message, which asks you whether you want this function.
Page 129: For Smartphone Users
For smartphone users screen appears on this navigation system. p The [Apps] key icon and Bluetooth icon p This description is for AVIC-Z150BH and vary according to the condition of AVIC-X950BH. Bluetooth connection as follows:...
Page 130: Using The Keyboard
Chapter Using AppRadio Mode 4 Hides the keyboard and text can now Using the keyboard be entered using the keyboard of iPhone CAUTION 5 Changes the iPhone keyboard layout For your safety, the keyboard functionality is only p The iPhone keyboard layouts that can be available when the vehicle is stopped and the selected by tapping depends on the...
Page 131: Other Functions
Launch an application on your iPhone. An image of the application appears on the screen. Press the HOME button to return to the “Top Menu” screen. Displaying the image of your application (smartphone) p This function is available on AVIC-Z150BH and AVIC-X950BH.
Page 132: Customizing Preferences Displaying The Information Screen
Chapter Customizing preferences Displaying the information screen Press the HOME button to display the “Top Menu” screen. Touch The Information screen appears. Touch the item you want to configure. 1 Speed Pulse The Speed Pulse value detected by the navi- gation system is shown.
Page 133: Checking Sensor Learning Status And Driving Status
Chapter Customizing preferences p When the GPS antenna is connected to Checking sensor learning this navigation system, OK is dis- status and driving status played. p The navigation system can automatically When the GPS antenna is not con- use its sensor memory based on the outer nected to this navigation system, NOK dimensions of the tires.
Page 134: Clearing Status
Chapter Customizing preferences p When tires have been changed or Checking the device number chains fitted, turning on the Speed Display the “Information” screen. Pulse allows the system to detect the = For details, refer to Displaying the informa- fact that the tire diameter has changed, tion screen on page 132.
Page 135: Displaying The Adjustment And Correction Screen
Chapter Customizing preferences Display the “Volume/Position Adjust- Touch [Home]. If the home location has not been stored yet, a ment” screen. confirmation message appears. = For details, refer to Displaying the adjust- ment and correction screen on page 135. Touch [Yes]. The registration is complete.
Page 136: Switching The Muting/Attenuation Level
Chapter Customizing preferences Switching the muting/ Touch [+] or [–] to set their volume. attenuation level You can select the muting/attenuation level of Mute Timing . This setting is also effective for a mute signal that has been received from the MUTE lead connected to the navigation unit.
Page 137: Displaying The Screen For Navigation Function Settings
Chapter Customizing preferences Switching the road on Touch the item you want to configure. which you are driving When you are driving in the area where an or- dinary road and toll road run parallel, and if the system calculates your vehicle position to be on a road opposite from the one on which you are actually driving, you can switch your vehicle position to the right road, i.e.
Page 138: Displaying The 3D Landmarks
Displaying the 3D landmarks p The 3D landmarks and this setting are only Setting the barrier graphic for available on AVIC-Z150BH. the city map You can select whether to display the 3D land- marks on the map.
Page 139: Setting The Map Color Change Between Day And Night
Chapter Customizing preferences Does not display the barrier graphic for the Displays the track log on the screen. city map. When the vehicle position or cur- ! Off: sor enters the area where no city map data Does not displays the track log on the is available, a normal map is displayed in screen.
Page 140: Setting The Current Street Name Display
Chapter Customizing preferences Setting the current street name ! Main Road: Calculates a route that passes major arter- display ial roads as a priority. Selects whether to display or hide the street name (or city name) that your vehicle is travel- Setting the use of toll roads ing along.
Page 141: Setting The Route Calculation By Learning Route
Setting the route calculation bridges with traffic restrictions during a cer- allowing for traffic congestion tain time. p This function is available on AVIC-Z150BH ! Off: and AVIC-X950BH. Calculates a route while ignoring traffic re- This navigation system can calculate a route strictions.
Page 142: Automatically Using The Auto Reroute Function
Setting the auto reroute function automatically using the auto to avoid traffic congestion reroute function p This function is available on AVIC-Z150BH p This function is available on AVIC-Z150BH and AVIC-X950BH. and AVIC-X950BH. This navigation system can calculate a route...
Page 143: Setting The Auto-Zoom Display
Chapter Customizing preferences Setting the auto-zoom display Setting the App operation screen interruption This setting enables switching to an enlarged map around the point where your vehicle is You can set whether to automatically switch to approaching an intersection, entrance/exit of the navigation screen from the AppRadio freeway or a junction.
Page 144: Changing The Unit Between Km And Miles
Customizing preferences 10mph, 20mph, 25mph (default), 30mph, Displaying the traffic 40mph notification icon ! km: p This function is available on AVIC-Z150BH 20km/h, 30km/h, 40km/h (default), and AVIC-X950BH. 50km/h, 60km/h Selects whether to display or hide the traffic Major Ordinary Road notification icons on the map when incidents ! mile or Mile&Yard:...
Page 145: Changing The Preinstalled Splash Screen
Chapter Customizing preferences Display the “System Settings” screen. Touch the item you want to configure. = For details, refer to Displaying the screen for system settings on page 144. Touch [Time Settings]. The Time Settings screen appears. To set the time difference, touch [+] or [–], [On] or [Off], or [12H] or [24H].
Page 146: Changing To The Splash Screen Stored On The Sd Memory Card
Chapter Customizing preferences # If you touch [Show Image], you can confirm a ! Yes: selected image via full screen preview. Touch the Starts importing the files into the navigation screen to return to the Select Splash Screen . system. ! No: Touch [OK].
Page 147: Touch Panel (Touch Panel Calibration)
Chapter Customizing preferences Adjusting the response Selecting the color from the preset colors positions of the touch panel Display the “System Settings” screen. (touch panel calibration) = For details, refer to Displaying the screen for If you feel that the touch panel keys on the system settings on page 144.
Page 148: Displaying The Icon For Setting The Rear Display Output
Chapter Customizing preferences Touch [Custom]. Touch [Rear Monitor Output]. The Illumination Color screen appears. The Rear Monitor Output Setting Screen screen appears. Touch to adjust the values for Red, Green and Blue to create a favorite Touch [On] or [Off]. color.
Page 149: Setting Video Input 1 (Av1)
Chapter Customizing preferences Setting video input 1 (AV1) Changing the screen size of SD/ USB video You can use outside video equipment such as portable players connected to this product Changes the screen size of video. If a video file with this setting.
Page 150: Displaying Your Divx Vod Deregistration Code
Chapter Customizing preferences p If a registration code has already been acti- Touch vated, it cannot be displayed. Touch [Registration Code]. Your 10-digit registration code is displayed. p Make a note of the code as you will need it when you register with a DivX VOD provider. Displaying your DivX VOD deregistration code The Edit/Settings screen appears.
Page 151: Adjusting Loudness
Chapter Customizing preferences Using the equalizer = For details, refer to Setting the rear output on page 158. The equalizer lets you adjust equalization to match the vehicle interior acoustic character- Touch to adjust front/rear istics as desired. speaker balance. Each time you touch , the front/rear Recalling equalizer curves...
Page 152 Chapter Customizing preferences The difference between “Custom1” and Touch [EQ Menu]. “Custom2” ! A separate Custom1 curve can be cre- ated for each source. If you make adjust- ments when a curve S.Bass (Super Bass) , Powerful , Natural , Vocal , Flat , or Custom1 is selected, the equalizer curve settings will be memorized in Custom1 .
Page 153: Adjusting Source Levels
Chapter Customizing preferences p You cannot select [SLA] when the FM tuner Touch the frequency for which you want to adjust the level. is selected as the AV source. Compare the FM tuner volume level with the level of the source you wish to ad- just.
Page 154: Using The Subwoofer Output
Chapter Customizing preferences Each touch of changes the Enhancing bass (Bass Booster) cut-off frequencies as follows: You can enhance bass sounds that are often 50Hz 63Hz 80Hz 100Hz 125Hz muted by driving noise. Display the “AV Sound Settings” Using the subwoofer output screen.
Page 155: Before Operating The Auto Eq Function
Previous settings for Auto EQ will be over- ! When this navigation system is connected to a power amp with input level control, written. p For AVIC-Z150BH users Auto EQ may be impossible if the power amp s input level is set below the standard level.
Page 156 Chapter Customizing preferences Press the HOME button to display the Do not press the h button to open or close “Top Menu” screen. the panel when you are using the micro- phone. Touch Stop the vehicle in a quiet place, close The Edit/Settings screen appears.
Page 157: Displaying The Screen For App Settings
Chapter Customizing preferences Display the “App Settings” screen. 15 Store the microphone carefully in the glove compartment or another safe place. = For details of the operations, refer to Dis- If the microphone is subjected to direct sun- playing the screen for app settings on page light for an extended period, high tempera- 157.
Page 158: Setting The Rear Output
Chapter Customizing preferences Touch the desired language. Adjusting the picture After the language is selected, the previous screen returns. CAUTION For safety reasons, you cannot use some of these navigation functions while your vehicle is in mo- Setting the rear output tion.
Page 159: Selecting The Video For Rear Display
Chapter Customizing preferences p The adjustments of Brightness and Selecting the video for rear Contrast are stored separately when your display vehicle s headlights are off (daytime) and You can choose either to show the same when your vehicle s headlights are on image as the front screen or to show the se- (nighttime).
Page 160: Replicating The Settings
Chapter Customizing preferences p Touching Insert an SD memory card into the SD closes the pop-up screen. p When Mirror AV is selected, the following card slot. restrictions are applied to rear display. = For details of the operation, refer to Insert- When selecting Rear View in the map ing and ejecting an SD memory card on page 16.
Page 161: Setting For Rear View Camera
When the polarity of the connected lead is positive while the shift lever is in the RE- CAUTION VERSE (R) position. Pioneer recommends the use of a camera which ! GND: outputs mirror reversed images, otherwise the When the polarity of the connected lead is screen image may appear reversed.
Page 162 Chapter Customizing preferences Touch to select a point. ! Before getting out of the car to place the markings, be sure to turn the ignition switch off (ACC OFF). ! The range projected by the rear view camera is limited. Also, the vehicle width and distance guidelines displayed on the rear view camera image may differ from the actual vehicle width and distance.
Page 163: Setting The Anti-Theft Function
Touch [OK]. Enter a password hint. p Up to 24 characters can be entered for a Forgotten password hint. Contact the nearest authorized Pioneer Ser- Touch [OK]. vice Station. The Password Confirmation screen ap- pears. p If you want to change the password cur- rently set, enter the current password and then enter the new one.
Page 164: Restoring The Navigation System To The Default Or Factory Settings
Chapter Other functions Restoring the navigation Touch the item you want to initialize. system to the default or factory settings You can restore settings or recorded content to the default or factory settings. Various methods are used to clear user data, and the situations and the cleared content differ in each case.
Page 165: Setting Items To Be Deleted
Chapter Other functions Setting items to be deleted The items to be deleted vary depending on the reset method. The items listed in the following table will be restored to the default or factory settings. Any items not listed below will be retained. : The setting will be retained.
Page 166 Chapter Other functions Setting items to be deleted Method 1 Method 2 Method 3 Track log All settings in the AV Sound Settings screen Wide screen mode Sound mix function Playback method of AV source All settings in the Function screen Dimmer Picture Adjustment Other settings...
Page 167: Appendix Troubleshooting
If you have problems operating your navigation system, refer to this section. The most common problems are listed below, along with likely causes and solutions. If a solution to your problem cannot be found here, contact your dealer or the nearest authorized Pioneer service facility. Problems with the navigation screen...
Page 168 Appendix Appendix Symptom Cause Action (Reference) You cannot position your vehicle Something is covering the GPS an- Do not cover the GPS antenna with spray on the map without a significant tenna. paint or vehicle wax, because this may block positioning error.
Page 169 Appendix Appendix Symptom Cause Action (Reference) Rear display picture disappears. The source disc being listened to in Before ejecting the disc, switch the source. the navigation system has been This problem may occur when certain con- ejected. nection methods are used. There is a problem with the rear dis- Check the rear display and its connection.
Page 170 Appendix Appendix Symptom Cause Action (Reference) No video output from the con- The AV1 Input or AV2 Input set- Correct the settings. (Page 125) nected equipment. ting is incorrect. The audio or video skips. The navigation system is not firmly Secure the navigation system firmly.
Page 171 Appendix Appendix Symptom Cause Action (Reference) Sound from the iPod cannot be The audio output direction may Use the iPod to change the audio output di- heard. switch automatically when the rection. Bluetooth and USB connections are used at the same time. Problems with the phone screen Symptom Cause...
Page 172: Messages For Navigation Functions
Route calculation has failed be- ! Change the destination. possible. cause of a malfunction in the map ! Consult the Pioneer Local dealer if this mes- data, software, or hardware. sage persists. Route calculation not possi- The destination is too far.
Page 173: Messages For Av Functions
If the error persists, record the error message and contact your dealer or your nearest Pioneer service center. The messages in ( ) will appear on the rear display.
Page 174 Check the tuner connection and battery vol- connection is incorrect. tage. If the message fails to disappear even after the engine is switched off/on, contact your dealer or the nearest authorized Pioneer service center for assistance. No Signal The SiriusXM Connect Vehicle Tuner...
Page 175: Messages For Bluetooth Functions
When problems occur with Bluetooth functions, an error message appears on the display. Refer to the table below to identify the problem, then take the suggested corrective action. If the error persists, record the error message and contact your dealer or your nearest Pioneer service center. Message...
Page 176: Positioning Technology
The position of the speed detection circuit vary depending on the vehicle model. For The Global Positioning System (GPS) uses a details, consult your authorized Pioneer network of satellites orbiting the Earth. Each dealer or an installation professional. of the satellites, which orbit at a height of...
Page 177: Handling Large Errors
Appendix Appendix Map matching When positioning by GPS is As mentioned, the positioning systems used impossible by this navigation system are susceptible to ! GPS positioning is disabled if signals can- certain errors. Their calculations may, on occa- not be received from more than two GPS sion, place you in a location on the map where satellites.
Page 178: Conditions Likely To Cause Noticeable Positioning Errors
Appendix Appendix Conditions likely to cause ! If you drive in zigzags. noticeable positioning errors For various reasons, such as the state of the road you are traveling on and the reception status of the GPS signal, the actual position of your vehicle may differ from the position dis- played on the map screen.
Page 179 Appendix Appendix ! If you are on a steep mountain road with ! If trees or other obstacles block the GPS many height changes. signals for a considerable period. ! If you drive very slowly, or in a start-and- ! If you enter or exit a multi-storey parking lot stop manner, as in a traffic congestion.
Page 180: Route Setting Information
Appendix Appendix Route setting information current heading. In such cases, you are in- structed to turn around, so please turn Route search specifications around safely by following the actual traffic rules. Your navigation system sets a route to your ! In some cases, a route may begin on the destination by applying certain built-in rules to opposite side of a railway or river from your the map data.
Page 181: Built-In Drive And Care
Appendix Appendix Built-in drive and care one hour. Also, wipe any damp discs with a soft cloth. ! Use only conventional, fully circular discs. ! Playback of discs may not be possible be- Do not use shaped discs. cause of disc characteristics, disc format, recorded application, playback environ- ment, storage conditions and so on.
Page 182: Avchd Recorded Discs
Appendix Appendix is a trademark of DVD Format/Logo Licensing Corporation. p It is not possible to play DVD-Audio discs. This DVD drive may not be able to play all discs bearing the marks shown above. AVCHD recorded discs This unit is not compatible with discs recorded Detailed information for in AVCHD (Advanced Video Codec High Defi- playable media...
Page 183 Appendix Appendix CD-R/CD-RW discs tion, playback environment, storage conditions, and so on. ! Unfinalized discs cannot be played back. ! It may not be possible to playback CD-R/ CD-RW discs recorded on a music CD re- USB storage device compatibility corder or a personal computer because of = For details about USB storage device com- disc characteristics, scratches or dirt on...
Page 184 Appendix Appendix Notes specific to DivX files ! The character code for the subtitle file should comply with ISO-8859-1. Using char- ! Only DivX files downloaded from DivX part- acters other than ISO-8859-1 may cause the ner sites are guaranteed for proper opera- characters to be displayed incorrectly.
Page 185: Media Compatibility Chart
Appendix Appendix Media compatibility chart General DVD-R/-R SL/-R USB storage de- Media CD-R/-RW SD memory card DL/DVD-RW vice ! ISO9660 level 1 ! ISO9660 level 1 ! ISO9660 level 2 ! ISO9660 level 2 File system FAT16/FAT32 ! Romeo, Joliet ! Romeo, Joliet ! UDF 1.02/1.50/ ! UDF 1.02/1.50/...
Page 186 Appendix Appendix WMA compatibility DVD-R/-R SL/-R USB storage de- Media CD-R/-RW SD memory card DL/DVD-RW vice File extension .wma Bit rate 5 kbps to 320 kbps (CBR), VBR Sampling frequency 8 kHz to 48 kHz Note: The navigation system is not compatible with the following: ™...
Page 187 Appendix Appendix DivX compatibility DVD-R/-R SL/-R USB storage de- Media CD-R/-RW SD memory card DL/DVD-RW vice File extension .avi/.divx Home Theater Ver. 3.11/Ver. 4.x/Ver. 5.x/ Profile (DivX version) Ver. 6.x Compatible audio codec MP3, Dolby Digital DivX files on the external storage device Bit rate (MP3) 8 kbps to 320 kbps (CBR), VBR (USB, SD) cannot be played.
Page 188 Appendix Appendix Video files compatibility (USB, SD) File extension .avi .mp4 .m4v .wmv Format MPEG-4 MPEG-4 H.264 MPEG-4 Compatible video MPEG-4 MPEG-4 H.264 MPEG-4 codec Linear PCM Compatible audio (LPCM) codec Maximum resolu- 400 pixels x 240 pixels tion Bit rate: Bit rate: Bit rate: Bit rate:...
Page 189: Bluetooth
Bluetooth SIG, Inc. and any use of such marks by microSDHC Logo is a trademark of SD-3C, PIONEER CORPORATION is under license. LLC. Other trademarks and trade names are those of their respective owners.
Page 190: Wma/Wmv
ROM and DVD-R/RW/ROM discs. Keeping the CAUTION same terminology as DVD video, individual ! Pioneer accepts no responsibility for data lost DivX video files are called Titles . Keep in from an iPod, even if that data is lost while mind that when naming flies/titles on a CD-R/ using the navigation system.
Page 191: Itunes
Requirements to access app-based connected content services such as Pandora internet radio Aha, Aha Radio and the Aha and Aha Radio and Aha Radio using the Pioneer navigation sys- logos are either the trademarks or the regis- tem: tered trademarks of Harman International In- ! Latest version of the Pioneer compatible con- dustries, Incorporated.
Page 192: Using The Lcd Screen Correctly
The LCD screen can visible. In that case, please consult your scratch easily. dealer or the nearest authorized Pioneer Service Station. Liquid crystal display (LCD) screen ! If the LCD screen is near the vent of an air conditioner, make sure that air from the air conditioner is not blowing on it.
Page 193: Display Information
Appendix Appendix Display information Destination menu Phone menu Page Page Address Dial Pad Spell Name Contacts List My POIs 42, 50 Call History Favorites Redial History 42, 51 Bluetooth Settings Home Incoming Call Settings. Near Me Edit/Delete Near Dest. Around City Information menu Coordinates Page...
Page 194: Edit/Settings Menu
Appendix Appendix Edit/Settings menu Navi Settings menu Map Display Page Page Data Edit Road Color Navi Settings 2D-Locked Scroll AV Settings 150, 154, 158 3D Land Mark Source Settings City Map App Settings City Map Barrier Vol./Pos. Adj. Day/Night Display System Settings Display Travel Log Trav Log Auto Del.
Page 195: Av Settings Menu
Appendix Appendix AV Settings menu Page Distance/ETA Auto Reroute Close Up View AV Guide Mode App Guide Mode Minor Ordinary Road Major Ordinary Road Page Freeway AV Sound Settings km / mile FAD/BAL (Balance) Loudness EQ Menu Sub Woofer Bass Booster Sonic Center Control Traffic Info Auto EQ Measurement...
Page 196: Setting According To Source Menu
Appendix Appendix Setting according to source menu App Settings menu Page Page AV Input App Connection Settings AV1 Input App Keyboard Settings AV2 Input SD/USB Settings System Settings menu SD Video Output Settings USB Video Output Settings DVD/DivX® Setup Subtitle Language Audio Language Menu Language Multi Angle...
Page 197: Bluetooth Settings Menu
Appendix Appendix Bluetooth Settings menu Page Registration Change Device Delete Device Device Name Passkey Bluetooth On/Off...
Page 198: Glossary
Appendix Appendix Glossary DivX DivX is a popular media technology created by DivX, LLC, a subsidiary of Rovi Corporation. AAC is short for Advanced Audio Coding and DivX media files contain highly compressed refers to an audio compression technology video with high visual quality that maintains a standard used with MPEG-2 and MPEG-4.
Page 199 Appendix Appendix ISO 9660 format Multi-audio (Multilingual dialog) This is the international standard for the for- Some videos feature dialog recorded in multi- mat logic of DVD/CD-ROM folders and files. ple languages or audio recorded in multiple For the ISO9660 format, there are regulations tracks.
Page 200 Appendix Appendix Region number Waypoint DVD players and DVD discs feature region A location that you choose to visit before your numbers indicating the area in which they destination; a journey can be built up from were purchased. Playback of a DVD is not pos- multiple waypoints and the destination.
Page 201: Specifications
AVIC-X8510BT ....6.1 inch wide/16:9 3/4 in.) Effective display area: AVIC-X950BH AVIC-Z150BH ....155.2 mm × 81.3 mm Chassis ..... 178 mm × 100 mm × AVIC-X950BH ....135 mm × 70.8 mm 167 mm AVIC-X850BT ....135 mm × 70.8 mm (7 in.
Page 202 USB class ........Mass storage class HPF: Decoding format ...... MP3/WMA/AAC/WAVE/ Frequency ......50 Hz/63 Hz/80 Hz/100 Hz/ H.264/MPEG4/WMV 125 Hz SD (AVIC-Z150BH) Slope ........12 dB/oct Subwoofer: SD memory card, SDHC memory card Frequency ......50 Hz/63 Hz/80 Hz/100 Hz/ Compatible physical format 125 Hz ...........
Page 203 Appendix Appendix AM tuner AVIC-Z150BH, AVIC-X950BH Frequency range .... 530 kHz to 1 710 kHz (10 kHz) Usable sensitivity ... 25 µV (S/N: 20 dB) Signal-to-noise ratio ..80 dB (digital broadcasting) (IHF-A network) 62 dB (analog broadcasting) (IHF-A network) AVIC-X850BT, AVIC-X8510BT Frequency range ....
Page 204 253 Alexandra Road, #04-01, Singapore 159936 TEL: 65-6472-7555 PIONEER ELECTRONICS AUSTRALIA PTY. LTD. 5 Arco Lane, Heatherton, Victoria, 3202, Australia TEL: (03) 9586-6300 PIONEER ELECTRONICS DE MEXICO, S.A. de C.V. Blvd.Manuel Avila Camacho 138 10 piso Col.Lomas de Chapultepec, Mexico, D.F. 11000 TEL: 55-9178-4270 先鋒股份有限公司...

This manual is also suitable for:

Avic-x950bh Avic-x850bt Avic-x8510bt

Pioneer AVIC-Z150BH Operation Manual

Quick Links

Related Manuals for Pioneer AVIC-Z150BH

Summary of Contents for Pioneer AVIC-Z150BH
