- Page 1 Installation and Operating Instructions EHS 6631 P 822 925 344-A-200705-02...
-
Page 2: Dear Customer
Dear Customer, Please read these user instructions carefully and keep them to refer to later. Please pass the user instructions on to any future owner of the appliance. The following symbols are used in the text: Safety instructions Warning! Information that affects your per- sonal safety. -
Page 3: Table Of Contents
Contents Operating Instructions ............. Safety instructions . -
Page 4: Operating Instructions
Operating Instructions Safety instructions Safety during use Please comply with these instructions. If you do not, any damage resulting is not covered • Remove stickers and film from the glass ceramic. by the warranty. • There is the risk of burns from the appliance if used carelessly. -
Page 5: Description Of The Appliance
Description of the Appliance Cooking surface layout Single cooking zone Single cooking zone 1200W 1800W Double ring cooking zone Control panel Single cooking zone 750/2200W 1200W Control panel layout Lock Cooking zone indicators Heat setting selection Timer function with pilot light Timer display Display Outside ring... -
Page 6: Touch Control Sensor Fields
Touch Control sensor fields The appliance is operated using Touch Control sen- sor fields. Functions are controlled by touching sen- sor fields and confirmed by displays and acoustic signals. Touch the sensor fields from above, without covering other sensor fields. Sensor field Function On / Off... -
Page 7: Operating The Appliance
Operating the appliance Switching the appliance on and off Control panel Display Pilot light Switch on Touch for 2 seconds lights up Switch off Touch for 1 second / none goes out After switching on, within approx. 10 seconds a heat setting or a function must be set, other- wise the appliance automatically switches it- self off. -
Page 8: Using The Automatic Warm-Up Function
Using the automatic warm-up function All cooking zones are equpped with an automatic warm up function When setting a heat setting using , when starting from , the cooking zone switch- es to full power for a certain amount of time and then automatically switches back to the heat setting set. -
Page 9: Using The Child Safety Device
Using the child safety device The child safety device prevents unintentional use of the appliance. Setting the child safety device Step Control panel Display/Signal Switch on the appliance (Do not set a heat setting) Touch until the signal sounds Acoustic signal Touch Appliance switches off. -
Page 10: Using The Timer
Using the timer Function Pre-requisite Result after time has elapsed Automatic cut-out With heat setting set Acoustic signal flashes Cooking zone switches off Countdown timer Cooking zones are not switched on Acoustic signal flashes While the countdown timer is activated, no cooking zone can be used. - Page 11 Setting the time Step Control panel Indicator Select cooking zone Pilot light for the cooking zone selected flashes Touch minutes After a few seconds the pilot light flashes more slowly. The time is set. The time counts down. Switching off the timer function Step Control panel Indicator...
-
Page 12: Safety Cut-Out
Safety cut-out Cooking surface • If after switching on the cooking surface, a heat setting is not set for a cooking zone within approx. 10 seconds, the cooking surface automatically switches itself off. • If one or more sensor fields are covered for longer than approx. -
Page 13: Tips On Cooking And Frying
Tips on Cooking and Frying Information on acrylamides According to the latest scientific knowledge, intensive browning of food, especially in prod- ucts containing starch, can constitute a health risk due to acrylamides. Therefore we recom- mend cooking at the lowest possible tempera- tures and not browning foods too much. -
Page 14: Examples Of Cooking Applications
Examples of cooking applications The information given in the following table is for guidance only. Heat Cooking- suitable for Cooking time Tips/Hints setting process Residual heat, Off position Keeping Keeping cooked foods warm as required Cover food warm Hollandaise sauce, Melting 5-25 mins. -
Page 15: Cleaning And Care
Cleaning and Care Take care! Risk of burns from residual heat. Warning! Sharp objects and abrasive cleaning materials will damage the appliance. Clean with water and washing up liquid. Warning! Residues from cleaning agents will damage the appliance. Remove residues with water and washing up liquid. -
Page 16: What To Do If
What to do if … Problem Possible cause Remedy The cooking zones will not switch More than 10 seconds have passed Switch the appliance on again. on or are not functioning since the appliance was switched The child safety device is switched Deactivate the child safety device (See the section “Child safety de- vice”) -
Page 17: Disposal
Disposal Packaging material The packaging materials are environmentally friendly and can be recycled. The plastic com- ponents are identified by markings, e.g. >PE<, >PS<, etc. Please dispose of the packaging materials in the appropriate container at the community waste disposal facilities. Old appliance The symbol on the product or on its pack-... -
Page 18: Installation Instructions
Installation Instructions Electrical Connection Safety instructions The laws, ordinances, directives and standards in Before connecting, check that the nominal voltage of force in the country of use are to be followed (safety the appliance, that is the voltage stated on the rating regulations, proper recycling in accordance with the plate, corresponds to the available supply voltage. -
Page 19: Assembly
Assembly... -
Page 23: Rating Plate
Rating Plate EHS6631P 949 591 877 55HAD03AO 230 V 50 Hz 6,4 kW Electrolux... -
Page 24: Warranty Conditions
Warranty conditions 8. You may not make a claim under this warranty unless the defect claimed is due to faulty or defective parts or workmanship. Electrolux is not liable in the following situations (which are not exhaustive): Warranty (a) The Appliance is damaged by: (i) accident FOR SALES IN AUSTRALIA AND NEW ZEALAND (ii) misuse or abuse, including failure to properly maintain or serv-... -
Page 27: Service
Service In the event of technical faults, please first check whether you can remedy the problem yourself with the help of the operating instructions (section “What to do if…”). If you were not able to remedy the problem yourself, please contact the Customer Care Department or one of our service partners. - Page 28 822 925 344-A-200705-02 Subject to change without notice The Electrolux Group. The world´s No.1 choice. The Electrolux Group is the world´s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more than 150 countries around the world.
