INSTALLATIONS

Introduction

Product Description

® ®
MAT-880 Pentium M 5.25" embedded board incorporates the Intel
advanced 855GME Chipset that supports processors from 900MHz to
1.6MHz in both 478 or 479-ball Micro-FCBGA package with a front
size bus of 400MHz.
Graphics display functionality is provided by the integrated-chipset
VGA controller that supports CRT display and LVDS interface with
24-bit panel specifications. Ethernet connectivity comes from the
ICH4-integrated Ethernet 10/100 Ethernet controller and a secondary
LAN using an Intel 82541GI Gigabit Ethernet.
Two DDR DIMM sockets supports up to 2GB of memory. Four COM
ports are supported, with COM3 and COM4 with a Fintek F81216D I/O
controller. There are two IDE connectors – IDE1 supporting
UDMA33/66/100 and IDE2 with UDMA33 while supporting a CF Type
II socket for its slave channel.
Other I/O features include two Serial ATA ports, 4-in 4-oout digital I/O
and four USB ports using pin headers. Expansion slots composed of one
PCI and one Mini PCI slot. The 5.25" disk-size board uses a 20-pin ATX
power.
This board represents the perfect choice for those who want superior
performance for various low-power embedded applications.
MAT-880 User' s Manual 1
