Table 5. Development Kit Feature Set Summary

Processor
Chipset
Memory
External
Graphics
Video
PCI
PCI
Express*
On-Board
LAN
BIOS (SPI)
ATA/
Storage
22 323094
Description
®
Intel Core™ i5
®
Intel 5 Series Chipset
Two DDR3 DIMM slots
PCIe* Slot
24-bit dual channel LVDS
Interface
Display Ports
CRT
HDMI
Three 5V PCI slots supported
through PCI extension card.
8 PCIe lanes
®
Intel 82577 Gigabit Ethernet PHY
2x SPI flash devices
6 SATA Ports
Comments
Soldered to board
1071 pin BGA footprint
Maximum 8GB of DDR Memory (RAM) of
ECC and non-ECC using 2Gb
Supports DDR3 frequency of up to
1066MT/s
Notes:
4Gb (x16 width only) technology support is
under investigation
One x16 PCIe slot supported.
2x8 PCIe* supported through Nowata Add-
in card.
eDP supported through PCI graphics add-in
card
Connectors and cables from previous
development kits can be used.
3 – Display port Lanes on Chipset. 1 On-
Board DP Connector. Other 2 ports can be
supported through PCI graphics add-in card.
On Board right-angled CRT Connector
Similar to the earlier platforms
1 On-Board HDMI Connector (Optional
Routing through Display Port D of Chipset).
Three additional HDMI ports are available
through the Eaglemont 2 external card.
PCI revision 2.3 compliant (33MHz)
No PCI slots on motherboard, only one
goldfinger on board.
PCI Express 2.0 base revision compliance
Five lanes to x1 PCIe ports
One lane to LAN
Two Lanes to Docking
Support for multi vendor SPI
Support multi package (SOIC-8 and
SOIC-16)
2 Cable Connector and 1 Direct Connect
Connector. 2 eSATA connectors and 1 to
docking. RAID 0/1 support.
