Lexmark MS810n Manual

Disassembly of Waste Electrical and Electronic Equipment (WEEE) Manual
EU Waste Electronic and Electrical Equipment Directive require producers to provide information of the different electronic
and electrical materials and components found in their products at its end-of-life, and disassembly references to treatment
and recycling facilities.
The disassembly information for this product has been prepared for use by a recognized treatment or recycling facility and
is not intended to be used by others.
1. Product information
2. Materials and components list for selective treatment
3. Disassembly tools
4. Disassembly references
The following information is intended only for the use of treatment and recycling facilities.
All disassembly instructions should be performed with the power switch in the OFF position. Disconnect the power cord
from the wall outlet and from the printer before continuing. If there are any other devices attached to the printer, then turn
them off as well, and unplug any cables going into the printer.
1. Product information
Model name(s)—Indicate all model name(s) within the product family
Model name
Lexmark MS810 series –
Lexmark MS810n, Lexmark MS810dn, Lexmark MS810dtn, Lexmark MS810de (Lexmark M5155, Lexmark
M5163), Lexmark MS811n, Lexmark MS811dn, Lexmark MS811dtn, Lexmark MS812dn, Lexmark MS812dtn,
Lexmark MS812de (Lexmark M5170)
* Add rows as needed
2. Materials and components list for selective treatment
Items
Polychlorinated biphenyls (PCB) containing capacitors
Mercury containing components, such as switches or
backlighting lamps
Batteries
Printed circuit boards greater than 10 cm
Toner cartridges, liquid and pasty, as well as colour
toner
Doc No.:
Quantity
0
0
1
2
8
1
Rev. 001
Notes
N/A
N/A
Lithium Manganese Dioxide coin cell
located on the system controller card
Plus one (1) for MS810dtn, MS811dtn,
MS812dtn models (locations illustrated
in 4.2)
Located inside front cover
Page 1 of 17
