Printing Guide
Loading the 250‑ or 550‑sheet tray
CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately. Keep all other trays
closed until needed.
1
Pull out the tray.
Notes:
•
When loading folio‑, legal‑, or Oficio‑size paper, lift the tray slightly and pull it out completely.
•
Avoid removing trays while a job prints or while Busy appears on the display. Doing so may cause a jam.
2
Squeeze and slide the width guide to the correct position for the size of the paper being loaded until it clicks into place.
Printing Guide
Page 1 of 18

Advertisement

loading

Related Manuals for Lexmark MS810n

Summary of Contents for Lexmark MS810n

  • Page 1 Printing Guide Page 1 of 18 Printing Guide Loading the 250‑ or 550‑sheet tray CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately. Keep all other trays closed until needed. Pull out the tray. Notes: • When loading folio‑, legal‑, or Oficio‑size paper, lift the tray slightly and pull it out completely.
  • Page 2 Printing Guide Page 2 of 18 Note: Use the paper size indicators at the bottom of the tray to help position the guides. Unlock the length guide, and then squeeze and slide the guide to the correct position for the size of the paper being loaded. Notes: •...
  • Page 3 Printing Guide Page 3 of 18 Flex the sheets back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges on a level surface. Load the paper stack with the printable side facedown. Note: Make sure the paper or envelope is loaded properly.
  • Page 4 Printing Guide Page 4 of 18 • If you are loading prepunched paper for use with the staple finisher, then make sure the holes on the long edge of the paper are on the right side of the tray. One‑sided printing Two‑sided printing Note: If the holes on the long edge of the paper are on the left side of the tray, then a jam may occur.
  • Page 5 Printing Guide Page 5 of 18 • Make sure the paper is below the solid line, which is the maximum paper fill indicator. Warning—Potential Damage: Overfilling the tray can cause paper jams.
  • Page 6 Printing Guide Page 6 of 18 • When using card stock, labels, or other types of specialty media, make sure the paper is below the dashed line, which is the alternate paper fill indicator. For custom‑ or Universal‑size paper, adjust the paper guides to lightly touch the sides of the stack, and then lock the length guide.

  • Page 7: Loading The 2100-Sheet Tray

    Printing Guide Page 7 of 18 Loading the 2100‑sheet tray CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately. Keep all other trays closed until needed. Pull out the tray. Adjust the width and length guides. Loading A5‑size paper Pull up and slide the width guide to the position for A5.
  • Page 8 Printing Guide Page 8 of 18 Squeeze and slide the length guide to the position for A5 until it clicks into place. Remove the A5 length guide from its holder. Insert the A5 length guide into its designated slot. Note: Press the A5 length guide until it clicks into place.
  • Page 9 Printing Guide Page 9 of 18 Loading A4‑, letter‑, legal‑, oficio‑, and folio‑size paper Pull up and slide the width guide to the correct position for the size of the paper being loaded. If the A5 length guide is still attached to the length guide, then remove it from its place. If the A5 length guide is not attached, then proceed to step d.
  • Page 10 Printing Guide Page 10 of 18 Put the A5 length guide in its holder. Squeeze the length guide and slide it to the correct position for the size of the paper being loaded until it clicks into place.
  • Page 11 Printing Guide Page 11 of 18 Flex and fan the sheets to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges on a level surface. Load the paper stack with the printable side facedown. Note: Make sure the paper is loaded properly.
  • Page 12 Printing Guide Page 12 of 18 Note: If the holes on the long edge of the paper are on the left side of the tray, then a jam may occur. • Make sure the paper is below the maximum paper fill indicator. Warning—Potential Damage: Overfilling the tray can cause paper jams.

  • Page 13: Loading The Multipurpose Feeder

    Printing Guide Page 13 of 18 From the printer control panel, set the size and type in the Paper menu to match the paper loaded in the tray. Note: Set the correct paper size and type to avoid paper jams and print quality problems. Loading the multipurpose feeder Pull down the multipurpose feeder door.
  • Page 14 Printing Guide Page 14 of 18 Pull the multipurpose feeder extender. Note: Guide the extender gently so that the multipurpose feeder is fully extended and open. Slide the width guide to the correct position for the size of the paper being loaded. Note: Use the paper size indicators on the bottom of the tray to help position the guides.
  • Page 15 Printing Guide Page 15 of 18 Prepare the paper or specialty media for loading. • Flex sheets of paper back and forth to loosen them, and then fan them. Do not fold or crease the paper. Straighten the edges on a level surface. •...
  • Page 16 Printing Guide Page 16 of 18 Without an optional staple finisher With an optional staple finisher One‑sided printing One‑sided printing Two‑sided printing Two‑sided printing • If you are loading prepunched paper for use with the staple finisher, then make sure the holes on the long edge of the paper are on the right side of the tray.
  • Page 17 Printing Guide Page 17 of 18 • Load envelopes with the flap side down and on the left of the multipurpose feeder. Warning—Potential Damage: Never use envelopes with stamps, clasps, snaps, windows, coated linings, or self‑stick adhesives. These envelopes may severely damage the printer. •...

  • Page 18: Setting The Paper Size And Type

    Printing Guide Page 18 of 18 Setting the paper size and type From the printer control panel, navigate to: > Settings > > Paper Menu > > Paper Size/Type > Press the up or down arrow button to select the tray or feeder, and then press Press the up or down arrow button to select the paper size, and then press Press the up or down arrow button to select the paper type, and then press to change the settings.
